Quick Details
-
Power Supply:
-
AC110-220V
-
Temperature:
-
-35 to 65 degrees
-
Humidity:
-
<95%, without concretion
-
Passage Width:
-
<=600mm
-
Passing Speed:
-
40 persons/min
-
Power Consumption:
-
100W
-
Input Interface:
-
+12V electrical signal or impulse signal
-
Communication Interface:
-
RS485 (Distance:<=1200m)
-
Material:
-
304 stainless steel
-
certificate:
-
CE,FCC and Rohs
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Hezhong
-
Model Number:
-
HZ-1300
-
Power Supply:
-
AC110-220V
-
Temperature:
-
-35 to 65 degrees
-
Humidity:
-
<95%, without concretion
-
Passage Width:
-
<=600mm
-
Passing Speed:
-
40 persons/min
-
Power Consumption:
-
100W
-
Input Interface:
-
+12V electrical signal or impulse signal
-
Communication Interface:
-
RS485 (Distance:<=1200m)
-
Material:
-
304 stainless steel
-
certificate:
-
CE,FCC and Rohs
304 Stainless Fingerprint or RFID card Steel Dual Passage Full Height Turnstile
The full height turnstile is designed with unique, strong, and durable mechanical to provide unsupervised access control for office or building which realize intelligent pedestrian control and management. .The impenetrable construction eliminates any un-authorized access to restricted areas. To gain authorized passage through the turnstile, the user must present a valid card for the access control system. Upon presentation of the valid card. The turnstile will unlock and allow the user to pass through the direction requested. And the turnstile can also work with push button, fingerprint and face recognition access control system.
This full-height turnstiles designs with tailored stainless steel make its elegance-looking,durable and anti-oxidation .Considering unique requests, we built-in standard electrical interface to best-fit customer easier using magnetic card, barcode, RFID cards integrated .This system provides civilized, well-organized pass management .
Considering Fire emergency happen, the system built-in unique fire-control interface, turnstile will be in free enter/exit working mode when power off.
1) Automatically low noise mechanism core equipped, highly cost-performance
2) Sense positioning, reducing mechanical impact make lifetime longer
3) Operating efficiency, 1~2 seconds open & close
4) Lowest Noise : No matter in operating or outside control, Noise control under 30db
5) Self-checking and Alarm warning for maintain
6) Resetting: System cancel authorized pass if passenger delayed pass
Anti-following : prevent illegal passing
Anti-clamp :The wings will stopped during in external block, the wings reset again after default delay
9) The rotary wings will be locked automatically if the system do not receive IR signal
10) Multi-passage for variety application demands , cover 99% needs on earth
11) Programmable signal separate control : pass time,pass speed etc. parameter
12) RS232/RS485 interface meet all kind of communications or wireless connection
Compatible IC/ID card ,flexible couple
Long-distance management through COMPUTER
15) Customize Options: LED display, Voice guide, Warning Lamps, Indicator Lights guide, Audible &Visible Alarm
Control & Interfaces
1, Card readers
2, Metal detection
3, Electronic/LCD counters
4, Fail-open or fail-secure locking
5, Push-button and wireless remotes
6, Manual key override both directions
7, Indicator lights
| Power Supply |
AC220/110V±10%, 50/60HZ
|
| Temperature | -45°C---75°C |
| Humidity | <95%, without concretion |
| Passage Width | <=600mm |
| Passing Speed | 40 persons/min |
| Power Consumption | 100W |
| Input Interface | +12V electrical signal or impulse signal |
| width | more than 100ms |
| drive current | >10mA |
| Communication Interface | RS485 (Distance:<=1200m) |
| Material | 304 stainless steel |
| Dimension | 1460*1600*2300 mm |
|
Communication
Connection
|
RS485 Communication Interface or TCP/IP inter face |
| Protection grade | IP44 |
Packaging Detail: Wooden box
Delivery detail: within 10 working days after payment confirmed
Installation and commissioning
The metal tripod turnstile with integrated design, only 10 minutes to complete the installation or dismantling, installation and commissioning were equipped with operating instructions.
Use
1. Office space: commercial buildings, government offices, etc;
2.Science unit: universities, research institutes, libraries, etc;
3. Commercial service establishments: supermarkets, shopping malls, hotels, clubs, banks, etc;
4. Leisure and entertainment: parks, scenic areas, playgrounds, etc;
5. Transportation Sites: bus, train, subway stations, airports and so on.
Service
1. Any inquiries will be replied within 24 hours
2. Professional maufacturer. Welcome to visit our factory.
3. OEM/ODM available
You can have your own fashionable design at reasonable& competitive price
5. High quality:
1.) All products are stictly checked in warehouse before packing
2.) All products are well-packed before shipping
3.) All products have 2 years warranty
6.Payment:
T/T, Western Union, Paypal, Moneygram can be accepted
7. short lead time:
Sample order in stock, and 3--7 days for bulk production
8. Shipping:
Cooperate well with DHL, EMS, UPS, FEDEX, China Air Post
You can also choose your own shipping forwarder
