Quick Details
-
Type:
-
Coaxial
-
Component:
-
48/0.12±0.005mmAL wire+PVC6.8±0.1mm (70 ℃),
-
Roll:
-
100 or 305m per roll
Quick Details
-
Brand Name:
-
YOUXIN
-
Model Number:
-
RG6 Coaxial cable
-
Place of Origin:
-
Zhejiang, China
-
Type:
-
Coaxial
-
Component:
-
48/0.12±0.005mmAL wire+PVC6.8±0.1mm (70 ℃),
-
Roll:
-
100 or 305m per roll
|
Series |
Structure |
||||
|
Conductor mm |
Dielectric OD (mm) |
Shielding |
Jacket Nom Dia. (mm) |
Jacket Material/Colour |
|
|
RG 6/U |
1.02 Solid BC |
PE(Physical Foam) Φ4.8 |
1.Aluminimum mylar 2.Braidding: 96/0.12(TC) |
Φ7.0 |
PVC White |
|
1.02 Solid BC |
PE(Physical Foam) Φ4.8 |
1.Aluminimum mylar 2.Braidding: 64/0.12(TC) |
Φ6.9 |
PVC White |
|
|
1.02 Solid BC |
PE(Physical Foam) Φ4.8 |
1.Aluminimum mylar 2Braidding: 48/0.12(TC) |
Φ6.9 |
PVC White |
|
|
1.02 Solid BC |
PE(Physical Foam) Φ4.8 |
1.Aluminimum mylar 2Braidding: 80/0.12(AL) |
Φ7.0 |
PVC White |
|
|
1.02 Solid BC |
PE(Physical Foam) Φ4.8 |
1.Aluminimum mylar 2Braidding: 64/0.12(AL) |
Φ6.9 |
PVC White |
|
|
1.02(CCS) |
PE(Physical Foam)Φ4.8 |
1.Aluminimum mylar 2Braidding: 48/0.12(AL) |
Φ6.8 |
PVC White |
|
|
1.02 Solid BC |
PE(Physical Foam) Φ4.8 |
1.Aluminimum mylar 2.Braidding: 64/0.12(TC) 3.Aluminimum mylar 4.Braidding: 96/0.12(TC) |
Φ7.5 |
PVC White |
|
|
1.02 Solid BC |
PE(Physical Foam) Φ4.8 |
1.Aluminimum mylar 2.Braidding: 48/0.12(TC) 3.Aluminimum mylar 4.Braidding: 64/0.12(TC) |
Φ7.4 |
PVC White |
|
|
1.02 Solid BC |
PE(Physical Foam) Φ4.8 |
1.Aluminimum mylar 2.Braidding: 64/0.12(AL) 3.Aluminimum mylar 4.Braidding: 96/0.12(AL) |
Φ7.4 |
PVC White |
|
|
1.02 Solid BC |
PE(Physical Foam) Φ4.8 |
1.Aluminimum mylar 2.Braidding: 48/0.12(AL) 3.Aluminimum mylar 4.Braidding: 64/0.12(AL) |
Φ7.4 |
PVC White |
|
|
1.02(CCS) |
PE(Physical Foam) Φ4.8 |
1.Aluminimum mylar 2.Braidding: 48/0.12(AL) 3.Aluminimum mylar 4.Braidding: 48/0.12(AL) |
Φ7.3 |
PVC White |
|
|
