Quick Details
-
Specification:
-
6mm-25mm
-
Length:
-
5m-50m
-
Thickness:
-
3mm
-
Standard:
-
ISO 15500-17; 8031
-
Color:
-
Red
-
Product name:
-
cng hose
-
Application:
-
Deliver compressed natural gas at high pressure
-
Feature:
-
High Pressure
-
Usage:
-
Natural gas;
-
Name:
-
Compressed natural gas hose
-
Certification:
-
ISO CE
-
Type:
-
Round Pipe
-
Size:
-
6-25mm
-
MOQ:
-
1000 Meters
Quick Details
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
vipoo
-
Model Number:
-
cng-01
-
Specification:
-
6mm-25mm
-
Length:
-
5m-50m
-
Thickness:
-
3mm
-
Standard:
-
ISO 15500-17; 8031
-
Color:
-
Red
-
Product name:
-
cng hose
-
Application:
-
Deliver compressed natural gas at high pressure
-
Feature:
-
High Pressure
-
Usage:
-
Natural gas;
-
Name:
-
Compressed natural gas hose
-
Certification:
-
ISO CE
-
Type:
-
Round Pipe
-
Size:
-
6-25mm
-
MOQ:
-
1000 Meters
|
Place of Origin
|
CN；HENAN
|
|
Model Number
|
CNG HOSE
|
|
Brand Name
|
VIPOORUBBER
|
|
Product name
|
CNG compressed natural gas hose
|
|
Inner layer
|
Conductive polyamide
|
|
Reinforcement layer
|
High tenacity fiber braid reinforcement
|
|
Outer layer
|
Abrasion-resistant red polyurethane
|
|
Size
|
6mm -25mm
|
|
Temperature range
|
-40℃- 82℃
|
|
Working pressure
|
5000psi
|
|
Electrical conductivity
|
resistivity is lower than 0.12 M Ω/M, in accordance with ISO 8031 standard
|
|
Application
|
Specially designed for conveying high pressure compressed natural gas (CNG)
|
|
criterion
|
ISO 15500-17, SAE 100R8, ISO 8031
|
|
OEM
|
customized
|
|
TYPE
|
ID
|
OD
|
Bending radius
|
W.P
|
B.P
|
Weight
|
|
|
（mm）
|
（mm）
|
（mm）
|
（psi）
|
（psi）
|
（kg/m）
|
|
111006
|
6.4
|
12.5
|
45
|
5000
|
20000
|
0.105
|
|
111008
|
8.0
|
15.0
|
60
|
5000
|
20000
|
0.142
|
|
111010
|
9.7
|
16.5
|
75
|
5000
|
20000
|
0.155
|
|
111012
|
13.0
|
22.0
|
95
|
5000
|
20000
|
0.245
|
|
111020
|
19.2
|
29.0
|
185
|
5000
|
20000
|
0.360
|
|
111025
|
25.6
|
38.0
|
230
|
5000
|
20000
|
0.510
|
CNG hose increasingly used in the loading and unloading connection pipeline system between CNG cylinder pry truck, decompression station and steam filling station. The product is quick to install and easy to use.
CNG hose assembly has ball valve, quick connection and flange connection, so it can be used to easily adjust the distance of loading and unloading truck. The product has strong pressure applicability.
Scope of application: 1.0mpa ~25MPa, can fully meet the majority of users to the use of equipment pressure requirements.
Multiple workstations work together to improve timeliness,
achieve the best standards,
and deliver the fastest.
Packaging is according to the international transport standards for packaging, if necessary,can be customized
Customizable logo
Customizable logo
After the production of the goods is completed, the goods will be delivered in order of the order
The completion time of the goods depends on the size of the order quantity: 5-30 working days
The completion time of the goods depends on the size of the order quantity: 5-30 working days
Henan vipoorubber co., LTD., has 30 years of experience in production and sales
Main production and manufacturing rubber hose (tube flange dredging, sediment delivery hose (water), absorption), sand blasting hose, concrete pump pipe, oxygen acetylene hose, chemical resistant hose, PVC hose, fuel hose, hydraulic hose, steel wire braided hose,
Industrial hose
,steel wire winding), high-pressure hose, peristaltic pump hose, garden hose expansion, hose connectors and other products, we are industry and trade integration company, has its own factory, a professional research and development technical team and efficient staff conscientiously.
