Quick Details
-
Brand Name:
-
BEFANBY
-
Product Name:
-
150 tons heavy duty customized steerable norail transfer cart
-
Application:
-
Industrial Filed, foundry industry
-
Color:
-
Yellow/Customized
-
Power supply:
-
Battery driven, dc motor, soft start
-
Running speed:
-
0-20m/min
-
Running distance:
-
According to customers' demand
-
Certificates:
-
CE ISO SGS
-
Structure:
-
Steel box beam structure
-
Wheel:
-
Inside cast steel+outside polyurethane wheel
-
Safety Facilities:
-
E-stop/Dead man stop, etc
Quick Details
-
Warranty:
-
2 years
-
Weight (KG):
-
1000
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
BEFANBY
-
Product Name:
-
150 tons heavy duty customized steerable norail transfer cart
-
Application:
-
Industrial Filed, foundry industry
-
Color:
-
Yellow/Customized
-
Power supply:
-
Battery driven, dc motor, soft start
-
Running speed:
-
0-20m/min
-
Running distance:
-
According to customers' demand
-
Certificates:
-
CE ISO SGS
-
Structure:
-
Steel box beam structure
-
Wheel:
-
Inside cast steel+outside polyurethane wheel
-
Safety Facilities:
-
E-stop/Dead man stop, etc
Products Description
150 tons heavy duty customized steerable norail transfer cart
The battery power trackless transfer cart is an alternative transfer cart for rail transfer cars. It overcomes many inconvenience of rail-type electric transfer carts. The trackless electric transfer carts can finish free-turning without rail in the workshop and workshop. There is no need to lay rails, so it does not affect traffic, does not hinder production, and the flat car is more flexible, the operation is more humanized.
Features for transfer cart:
1. It is not restricted by the track and can travel on the ground.It can turn 360 degrees.
2. Suitable for all kinds of environments.It can be used indoors or outdoors in high temperature explosion-proof and other environments.
3. Suitable for long distance operation.
4. Customized for you.Custom table size, operating speed,load,etc.Meet your requirements.
5. Equipped with safety warning and automatic stop device.
Details Images
Product Parameter
|
Modle
|
BWP-2T
|
BWP-10T
|
BWP-30T
|
BWP-50T
|
BWP-80T
|
BWP-100T
|
|||||
|
Table Size (m)
|
2.0*1.5*0.45
|
2.3*2.0*0.55
|
3.5*2.2*0.7
|
5.5*2.6*0.8
|
6.5*2.8*0.95
|
6.6*3.0*1.2
|
|||||
|
Power
|
Maintenance Free Battery
|
|
|
|
|
|
|||||
|
Wheel Base
|
1080mm
|
1650mm
|
1650mm
|
2000mm
|
1950mm
|
2000mm
|
|||||
|
Wheel Dia.
|
250mm
|
350mm
|
450mm
|
600mm
|
600mm
|
600mm
|
|||||
|
Running Speed
|
0-20m/min
|
0-20m/min
|
0-20m/min
|
0-20m/min
|
0-20m/min
|
0-20m/min
|
|||||
|
Motor Power
|
2*1.2kw
|
2*2.2kw
|
2*5.5kw
|
2*7.5kw
|
30kw
|
40kw
|
|||||
|
Battery Capacity
|
250Ah
|
250Ah
|
450Ah
|
500Ah
|
800Ah
|
1000Ah
|
|||||
|
Battery Volatge
|
24v
|
48v
|
48v
|
48v
|
72v
|
72v
|
|||||
|
Max Wheel Load
|
14.4Kn
|
42.6Kn
|
110.4Kn
|
174Kn
|
185Kn
|
190Kn
|
|||||
|
Reference weight
|
2.3t
|
4.2t
|
6.8t
|
8t
|
14.6t
|
26.8t
|
|||||
Remark:
the technical parameter of the trackless transfer car only can be make reference above.All can be customized manufacturing as per your true demand. please contact us if any doubt. Our professional engineer will help you solve the transfer problems in any time.
Function
Shipping
Our Company
Related Products
FAQ
Q
What is the size and load of the motorized transfer cart?
A
The size and load of our the motorized transfer cart are customized design according to your requirement.
Q
How should I operate the motorized transfer cart?
A
The motorized transfer cart is controlled by pendant & remote radio control. The controller could be a push button or joy-sticker.
Q
Whether there is professional technician assist our installation?
A
Yep, we have professional installation teams, who have gone to many countries to assist the installation. If you need we send technician to your factory, please let us know in advance. So we can arrange technicians.
Q
Can you help us arrange the shipment?
A
Yep, we have professional and independent Logistics & Document department. They will be responsible for arrange the logistics. Just communicate with our sales about the destination port.
