Quick Details
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
BAOFENG
-
Model Number:
-
BF-F8 Plus
-
Dimensions:
-
100 x 52 x 32 mm
-
Frequency Range:
-
136-174 / 400-480MHz
-
Weight ( with antenna & + battery):
-
250g(including battery, antenna)
-
Output Power:
-
4 W/1W
-
operate temprture:
-
-30-- +60
-
Battery:
-
1800mAh
-
Frequency Stability:
-
±2.5ppm
-
Channel Step:
-
5/6.25/12.5/25KHz
-
Adjacent Channel Power:
-
≤-65dB(Wide) / ≤-60dB(Narrow)
-
color:
-
black
-
Current:
-
≤1.6A(5W)
Quick Details
-
Talk Range:
-
3-8 km depends on envoriment
-
Terminal style:
-
Handheld
-
Storage Channel:
-
128
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
BAOFENG
-
Model Number:
-
BF-F8 Plus
-
Dimensions:
-
100 x 52 x 32 mm
-
Frequency Range:
-
136-174 / 400-480MHz
-
Weight ( with antenna & + battery):
-
250g(including battery, antenna)
-
Output Power:
-
4 W/1W
-
operate temprture:
-
-30-- +60
-
Battery:
-
1800mAh
-
Frequency Stability:
-
±2.5ppm
-
Channel Step:
-
5/6.25/12.5/25KHz
-
Adjacent Channel Power:
-
≤-65dB(Wide) / ≤-60dB(Narrow)
-
color:
-
black
-
Current:
-
≤1.6A(5W)
Product Description
FEATURES:
Frequency Range: 136-174 / 400-520MHz
Dual-Band Display, Dual Freq. Display, Dual-Standby
Output Power: 4 /1Watts(Max 5W)
128 Channels
50 CTCSS and 104 CDCSS
Built-in VOX Function
1750Hz Brust Tone
FM Radio (65.0MHz-108.0MHz)
LED Flashlight
Large LCD Display
High/Low RF Power Switchable
25KHz/12.5KHz Switchable
Emergency Alert
Low Battery Alert
Battery Saver
Time-out Timer
Keypad Lock
Monitor Channel
Channel Step: 2.5/5/6.25/10/12.5/25KHz
ROGER SET
Frequency Range: 136-174 / 400-520MHz
Dual-Band Display, Dual Freq. Display, Dual-Standby
Output Power: 4 /1Watts(Max 5W)
128 Channels
50 CTCSS and 104 CDCSS
Built-in VOX Function
1750Hz Brust Tone
FM Radio (65.0MHz-108.0MHz)
LED Flashlight
Large LCD Display
High/Low RF Power Switchable
25KHz/12.5KHz Switchable
Emergency Alert
Low Battery Alert
Battery Saver
Time-out Timer
Keypad Lock
Monitor Channel
Channel Step: 2.5/5/6.25/10/12.5/25KHz
ROGER SET
UNIT CONTAIN:
1 x BF-F8 PLUS (VHF136-174Mhz UHF 400-480Mhz)
1 x 7.4V 1800mah Li-ion Battery Pack
1 x DUAL BAND SMA-FEMALE Antenna
1 x Belt Clip
1 x ENG Manual
1 x Desktop Charger ( 100V ~ 240V )+(2pin USA or 3pin UK or 2pin EURO or 2pin Australia)
1 x PTT Earpiece for free
1 x BF-F8 PLUS (VHF136-174Mhz UHF 400-480Mhz)
1 x 7.4V 1800mah Li-ion Battery Pack
1 x DUAL BAND SMA-FEMALE Antenna
1 x Belt Clip
1 x ENG Manual
1 x Desktop Charger ( 100V ~ 240V )+(2pin USA or 3pin UK or 2pin EURO or 2pin Australia)
1 x PTT Earpiece for free
|
Item number
|
BF-F8 PLUS
|
|
|
General
|
|
|
|
Frequency Range
|
65-108MHz(FM Receive only)
|
|
|
|
136-174MHZ and 400-520MHZ (TX/RX)
|
|
|
Channel No.
|
128
|
|
|
Frequency Stability
|
±2.5ppm
|
|
|
Antenna
|
High gain DualBand antenna
|
|
|
Antenna Impedance
|
50Ω
|
|
|
Operating Voltage
|
DC 7.4V
|
|
|
Mode of operation
|
Simple or semi-duplex
|
|
|
Dimension(W x H x D)
|
100 x 52 x 32 mm
|
|
|
Weight
|
250g(including battery, antenna)
|
|
|
Transmitter
|
|
|
|
Output power
|
4W / 1W (Max 5W)
|
|
|
Modulation Mode
|
16kΦF3E / 11kΦF3E
|
|
|
Maximum deviation
|
<5kHz(Wide) / <2.5kHz(Narrow)
|
|
|
Spurious Radiation
|
<7μW
|
|
|
Adjacent Ch. power
|
≤-65dB(Wide) / ≤-60dB(Narrow)
|
|
|
Pre-emphasis characteristics
|
6dB
|
|
|
Current
|
≤1.6A(5W)
|
|
|
CTCSS/DCS deviation
|
0.5±0.1kHz(Wide) / 0.3±0.1kHz(Narrow)
|
|
|
Intermediation sensitivity
|
8-12mv
|
|
|
Intermediation distortion
|
<10%
|
|
