Quick Details
-
Ink Type:
-
Eco Solvent Ink
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
Summit
-
Voltage:
-
220V
-
Dimensions(L*W*H):
-
4.5*0.85*1.42m
-
Weight:
-
280 KG
-
Core Components:
-
Board System
-
Model:
-
SMT3202-ES
-
Print head:
-
Esp DX5
-
Printhead height:
-
2-3mm
-
Printing size:
-
3200mm
-
Height Adjust:
-
Automatic
-
Media Type:
-
Sticker, Banner, One way vision,Tarpaulin
-
Ink type:
-
Eco Solvent ink
-
Ink color:
-
CMYK
-
RIP Software:
-
Ultraprint/Maintop
-
Function:
-
Automatic Printing
Quick Details
-
Print Dimension:
-
3200mm
-
Condition:
-
New
-
Color & Page:
-
Multicolor
-
Ink Type:
-
Eco Solvent Ink
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
Summit
-
Voltage:
-
220V
-
Dimensions(L*W*H):
-
4.5*0.85*1.42m
-
Weight:
-
280 KG
-
Core Components:
-
Board System
-
Model:
-
SMT3202-ES
-
Print head:
-
Esp DX5
-
Printhead height:
-
2-3mm
-
Printing size:
-
3200mm
-
Height Adjust:
-
Automatic
-
Media Type:
-
Sticker, Banner, One way vision,Tarpaulin
-
Ink type:
-
Eco Solvent ink
-
Ink color:
-
CMYK
-
RIP Software:
-
Ultraprint/Maintop
-
Function:
-
Automatic Printing
Product Description
Specification
|
Model
|
SMT3202-ES
|
|
Printheads
|
Epson DX5*2
|
|
Ink Type
|
Eco Solvent Ink, Sublimation Ink, Water based ink
|
|
Printing Size
|
3.2m
|
|
Print Height
|
2mm-3mm
|
|
Ink Colors
|
4 colors(C,M,Y,K)
|
|
Printing Materials
|
Vinyl, Flex, Polyester, Backlit Frontlit Banner, Window Film, Reflective Banner, Etc
|
|
Data Interface
|
USB2.0 High Speed Interface Transfer System
|
|
Working Environment
|
Temperature 15oC-30oC
|
|
|
Humidity 40%-60%
|
|
Power
|
50-60HZ 400W-1600W
|
|
|
AC220V±10% / AC110V±10%
|
|
Operating System
|
Windows XP, Windows 7, Windows 8
|
|
Dimension
|
4.5*0.85*1.42m
|
|
Weight
|
280KG
|
|
Added Value
|
2 Liters Big Capacity CISS system
|
|
|
Auto Feeding & Take-up Media System
|
|
|
Infrared Heating system & Front Dry Fans
|
|
|
LED Strip light for Carriage Position
|
|
RIP software
|
Ultraprint/Maintop
|
|
Operating Environment
|
Temperature: 20-28°C / Humidity: 40%-60%
|
|
File Format
|
BMP, JPG, PDF, TIIF
|
|
Media type
|
Sticker, Banner, One way vision,Tarpaulin etc
|
|
Voltage
|
220V AC 50/60HZ
|
|
Interface
|
USB3.0
|
