Quick Details
-
Warranty:
-
1year
-
Max Cutting Height:
-
n/a
-
Place of Origin:
-
SHN
-
Brand Name:
-
RIMA
-
Model Number:
-
SFR4200+EM100/150
Quick Details
-
Grade:
-
Industrial
-
Voltage:
-
NO
-
Feature:
-
Single Cylinder, Steel Chasis
-
Warranty:
-
1year
-
Max Cutting Height:
-
n/a
-
Place of Origin:
-
SHN
-
Brand Name:
-
RIMA
-
Model Number:
-
SFR4200+EM100/150
Product Description
Specification
|
Model
|
SFR4200
|
|
|
Side reach from centerline(Max)
|
165”(4200mm)
|
|
|
Head rotation
|
210 degrees
|
|
|
Cut height from ground(Max)
|
189”(4800mm)
|
|
|
Cut depth @ 60 degree slope(Max)
|
57”(1450mm)
|
|
|
Arm weight
|
372kg
|
|
|
Controls
|
Remote
|
|
|
Max flow rate(Min)
|
16GPM(60L)
|
|
|
Max pressure
|
3500PSI(24Mpa)
|
|
|
|
|
|
|
Model
|
EM100
|
EM150
|
|
Cutting Width
|
1000mm
|
1500mm
|
|
Excavator
|
1.5-3ton
|
3-6ton
|
|
No. of Blade
|
24pcs-Hamber blade
(or 48pcs"Y") |
28pcs-Hamber blade
(or 56pcs"Y") |
|
Motor Displacement
|
25L/min (Inside release)
|
30L/min (Out release)
|
|
Motor Speed
|
2200r/min
|
2200r/min
|
|
Working Pressure
|
20-25Mpa
|
20-25Mpa
|
|
Packing Size
|
1300x735x470mm
|
1800x735x470mm
|
|
Weight
|
142/170kg
|
194/225kg
|
