Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Vision Datum
-
Model Number:
-
Mars720S-300GC
-
Video Compression Format:
-
/
-
Data Storage Options:
-
pc
-
Application:
-
golf swing, ball trajectory analysis
-
Resolution:
-
720*540/640*480
-
Frame Rate:
-
300fps/815fps/1000fps
-
Optical Size:
-
1/4"
-
Lens Interface:
-
Standard C-Mount
-
Interface:
-
Gigabit Ethernet (1000 Mbit/s)
-
Output Color:
-
Color/Mono
-
Pixel Size (μm2):
-
4.8
-
Operating System:
-
Windows, Linux,Arm
-
Dimension (L x W x H):
-
42.0 *29.0 * 29.0 mm(65g)
Quick Details
-
Special Features:
-
Global CMOS GigE Camera
-
Function:
-
Motion capture, High speed, Slow motion
-
Customized support:
-
Online technical support, OEM, ODM
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Vision Datum
-
Model Number:
-
Mars720S-300GC
-
Video Compression Format:
-
/
-
Data Storage Options:
-
pc
-
Application:
-
golf swing, ball trajectory analysis
-
Resolution:
-
720*540/640*480
-
Frame Rate:
-
300fps/815fps/1000fps
-
Optical Size:
-
1/4"
-
Lens Interface:
-
Standard C-Mount
-
Interface:
-
Gigabit Ethernet (1000 Mbit/s)
-
Output Color:
-
Color/Mono
-
Pixel Size (μm2):
-
4.8
-
Operating System:
-
Windows, Linux,Arm
-
Dimension (L x W x H):
-
42.0 *29.0 * 29.0 mm(65g)
LEO2 cameras support Four-sided Installation and larger temperature width design.
"-Lite": Small shell;
"-HR": Higher dynamic range;
"-p": supports lossless compression;
|
Model
|
Sensor
|
Frame Rate
|
Shutter Type
|
Interface
|
Lens Mount
|
|
MARS720S-300GC
|
IMX 287
|
300fps
|
Global
|
GigE
|
C
|
|
MARS720S-300GM
|
IMX 287
|
300fps
|
Global
|
GigE
|
C
|
|
MARS640-815UC
|
PYTHON 300
|
815fps
|
Global
|
USB3.0
|
C
|
|
MARS640-815UM
|
PYTHON 300
|
815fps
|
Global
|
USB3.0
|
C
|
|
Resolution
|
720 px x 540 px/640 px x 480 px
|
|
Image Color
|
Color/Mono
|
|
Image Format
|
Monochrome:Mono8/10/10p/12/12p Color:Mono 8/10/12,Bayer RG 8/10/10p/12/12p,YUV422Packed,YUV422_YUYV_Packed,RGB 8,BGR 8
|
|
Operating System
|
Windows,Linux
|
|
Driver
|
Mars Series Camera Secondary Development Kit（iCentral）or Third-party Software meeting with USB3 Vision Protocol
|
|
Synchronization
|
● Soft Trigger
● Hardware Trigger ● Free Run |
|
Conformity
|
GigE/USB3 Vision,GenICam
|
