Quick Details
-
Warranty(Year):
-
3-Year
-
Color Temperature(CCT):
-
4100K (Neutral White), 3000K/4000K/6500K
-
Lamp Luminous Flux(lm):
-
8000
-
CRI (Ra>):
-
80
-
Working Temperature(℃):
-
-35 - 65
-
Working Lifetime(Hour):
-
50000
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
JIYUANLUX OEM/ODM
-
Model Number:
-
led panel 62x62
-
Product name:
-
LED Backlit panel 60x60 60x120cm 600x600 600x1200mm 1x4 2x2 2x4ft Di
-
Power:
-
20W/36W/48W/40W/72W/80W/100W
-
Size:
-
300*300mm;300*600mm;600*600mm;600*1200mm
-
LED Chip:
-
SMD 2835
-
Installation Way:
-
Reccessed/surface/suspend
-
Material:
-
Aluminium housing
-
UGR:
-
<19
-
PF:
-
0.9
Quick Details
-
Lamp Luminous Efficiency(lm/w):
-
125
-
Application:
-
Office Building, Office/Shopping Mall
-
Lamp Body Material:
-
High-quality Aluminum + PMMA
-
Warranty(Year):
-
3-Year
-
Color Temperature(CCT):
-
4100K (Neutral White), 3000K/4000K/6500K
-
Lamp Luminous Flux(lm):
-
8000
-
CRI (Ra>):
-
80
-
Working Temperature(℃):
-
-35 - 65
-
Working Lifetime(Hour):
-
50000
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
JIYUANLUX OEM/ODM
-
Model Number:
-
led panel 62x62
-
Product name:
-
LED Backlit panel 60x60 60x120cm 600x600 600x1200mm 1x4 2x2 2x4ft Di
-
Power:
-
20W/36W/48W/40W/72W/80W/100W
-
Size:
-
300*300mm;300*600mm;600*600mm;600*1200mm
-
LED Chip:
-
SMD 2835
-
Installation Way:
-
Reccessed/surface/suspend
-
Material:
-
Aluminium housing
-
UGR:
-
<19
-
PF:
-
0.9
Product Description
|
Product Code
|
Size (mm)
|
Watt
|
Light Efficiency
|
Specifications:
● LED Type: SMD2835 LED
● CCT: 4100K (Neutral White), 3000K/4000K/6500K ● Color Rendering Index(CRI):>80Ra ● System Efficiency: >95% ● LED Brightness Decay:<5%/6000hrs ● Input Voltage: AC 85-265V ● Power Frequency: 50/60Hz ● Life span: >50000Hrs ● URG<19 |
|
BP-6060-A1
|
600*600*30
|
30W
|
100-135lm/W
|
|
|
BP-6060-A2
|
600*600*30
|
42W
|
100-135lm/W
|
|
|
BP-6060-A3
|
600*600*30
|
48W
|
100-135lm/W
|
|
|
BP-6060-A4
|
600*600*30
|
60W
|
100-135lm/W
|
|
|
BP-6060-A5
|
600*600*30
|
72W
|
100-135lm/W
|
|
|
BP-60120-A1
|
600*1200*30
|
48W
|
100-135lm/W
|
|
|
BP-60120-A2
|
600*1200*30
|
60W
|
100-135lm/W
|
|
|
BP-60120-A3
|
600*1200*30
|
72W
|
100-135lm/W
|
|
|
BP-60120-A4
|
600*1200*30
|
80W
|
100-135lm/W
|
|
|
BP-60120-A5
|
600*1200*30
|
100W
|
100-135lm/W
|
|
|
BP-30120-A1
|
300*1200*30
|
36W
|
100-135lm/W
|
|
|
BP-30120-A2
|
300*1200*30
|
48W
|
100-135lm/W
|
|
|
BP-30120-A3
|
300*1200*30
|
60W
|
100-135lm/W
|
|
|
BP-3060-A1
|
300*600*30
|
36W
|
100-135lm/W
|
|
|
BP-6262-A2
|
620*620*30
|
48W
|
100-135lm/W
|
|
