Quick Details
-
Production Capacity:
-
high
-
Place of Origin:
-
Anhui, China
-
Brand Name:
-
JINKA
-
Voltage:
-
220V
-
Dimension(L*W*H):
-
as to machine details
-
Weight:
-
800 kg
-
Marketing Type:
-
New Product 2023
-
CNC:
-
SD
Quick Details
-
Type:
-
Stone Cutting Machine
-
Power:
-
2.2KW
-
Cutting thickness (max):
-
50mm
-
Production Capacity:
-
high
-
Place of Origin:
-
Anhui, China
-
Brand Name:
-
JINKA
-
Voltage:
-
220V
-
Dimension(L*W*H):
-
as to machine details
-
Weight:
-
800 kg
-
Marketing Type:
-
New Product 2023
-
CNC:
-
SD
Product Features
* Adopt linear guide rail,double row and four row soft sliders ,large bearing capacity ,stable operation,high precision,long life,precise
* The whole machine adopts steel structure,good rigidity and not easy to deform
* Constant power spindle motor, strong cutting force and high efficiency.
* Tool cooling system,effectively improving tool
* CNC control system,with power-off memory function,when power-off,knife- can continuous engraving funtion.
* Compatible with all advanced CAM software :Type3/Artcam/CAXA/UG/Pro-E/Mastercam/JD/Ucancam and act.
* The whole machine adopts steel structure,good rigidity and not easy to deform
* Constant power spindle motor, strong cutting force and high efficiency.
* Tool cooling system,effectively improving tool
* CNC control system,with power-off memory function,when power-off,knife- can continuous engraving funtion.
* Compatible with all advanced CAM software :Type3/Artcam/CAXA/UG/Pro-E/Mastercam/JD/Ucancam and act.
Application
application.
MARBLE ,FIGURE STONE,GRANITE, BLUESTONE, JADE, EMERALD ,CRYSTAL ,AGATE, INK STONE, COPPER, ALUMINUM AND ETC.
Technical Parameters
|
MODEL
|
JK-4040
|
SD-3020EX
|
|
|
TABLE SIZE
|
400*400MM
|
3000*2000MM
|
|
|
FEED HEIGHT
|
70mm
|
|
|
|
MAX IDLE SPEED
|
6M/MIN
|
|
|
|
MAX WORKING SPEED
|
6M/MIN
|
|
|
|
SPINDLE POWER
|
220V2.2KW WATER COOLED SPINDLE
|
|
|
|
SPINDLE SPEED
|
6000-24000RPM
|
|
|
|
WORKING VOLTAGE
|
AC220V50HZ
|
|
|
|
TOOL
|
Φ 3.175/4/6/MM
|
|
|
|
FILE FORMAT
|
G CODE/HPGH
|
|
|
|
POSITIONING ACCURACY
|
± .3mm
|
|
|
|
REPEATABILITY POSITIONING ACCURACY
|
± 0.02mm
|
|
|
|
CONTROL SYSTEM
|
NC STUDIO
|
|
|
