Quick Details
-
Model Number:
-
BNT500 400~800VA
-
Weight:
-
3.55~4.9 kg
-
Color:
-
Black
-
Capacity:
-
400VA 600VA 800 VA
-
Waveform:
-
Mains mode: pure sine wave; Battery mode: simulated sine wave
-
Transfer time:
-
2 ~ 7 ms (typical), 10 ms (max.)
-
Battery recharge time:
-
6 ~ 8 h
-
Humidity:
-
20 ~ 90% RH @ 0 ~ 40℃ (non-condensing)
-
Noise level:
-
≤ 40 dB (1 m)
-
DC voltage:
-
12 V
-
OEM:
-
Yes
-
Certification:
-
CE
Quick Details
-
Warranty:
-
1 year
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Banatton
-
Model Number:
-
BNT500 400~800VA
-
Weight:
-
3.55~4.9 kg
-
Color:
-
Black
-
Capacity:
-
400VA 600VA 800 VA
-
Waveform:
-
Mains mode: pure sine wave; Battery mode: simulated sine wave
-
Transfer time:
-
2 ~ 7 ms (typical), 10 ms (max.)
-
Battery recharge time:
-
6 ~ 8 h
-
Humidity:
-
20 ~ 90% RH @ 0 ~ 40℃ (non-condensing)
-
Noise level:
-
≤ 40 dB (1 m)
-
DC voltage:
-
12 V
-
OEM:
-
Yes
-
Certification:
-
CE
Features:
1. Excellent microprocessor control optimizes reliability;
2. Built super smart charger, shorten charging time;
3. Boost and buck AVR for voltage stabilization;
4. Simulated sine wave;
5. Auto restart while AC is recovering;
6. Power-onself test;
7. Built-in self-diagnostic function;
8. Off mode charging function;
9. Intelligent battery management;
10. Optional no-load shut down;
11. Humanized alarm system;
12. Compatible with generator set (optional);
13. Optional RS232/USB communication port and RJ11/RJ45 protection.
Panel Information:
| Technical Parameters | ||||||
| MODEL | BNT540 | BNT560 | BNT580 | BNT5100 | BNT5150 | BNT5200 |
| Capacity | 400 VA | 600 VA | 800 VA | 1000 VA | 1500 VA | 2000 VA |
| 240 W | 360 W | 480 W | 600 W | 900 W | 1200 W | |
| INPUT | ||||||
| Voltage | 100 V / 110 V / 120 V: 80 ~ 150 Vac; | |||||
| 220 V / 230 V / 240 V: 162 ~ 295 Vac (220 V: 145 ~ 295 Vac optional) | ||||||
| Frequency | 50 / 60 Hz ± 10% (auto-sense) | |||||
| OUTPUT | ||||||
| Voltage | 100 V / 110 V / 120 Vac ± 10% or 220 V / 230 V / 240 Vac ± 10% | |||||
| Frequency | 50 / 60 Hz ± 1% (auto-sense) | |||||
| Waveform | Mains mode: pure sine wave; | |||||
| Battery mode: simulated sine wave | ||||||
| Transfer time | 2 ~ 7 ms (typical), 10 ms (max.) | |||||
| BATTERIES | ||||||
| DC voltage | 12 V | 24 V | ||||
| Configuration | 12 V / 5.0 Ah × 1 | 12 V / 7.0 Ah × 1 | 12 V / 9.0 Ah × 1 | 12 V / 7.0 Ah × 2 | 12V / 9.0 Ah × 2 | 12 V / 9.0 Ah × 2 |
| Recharge time | 6 ~ 8 h | |||||
| OTHERS | ||||||
| Protections | Short circuit - battery overcharge – overdischarge – overload - surge | |||||
| Communications | USB / RS232 / SNMP (optional) | |||||
| Humidity | 20 ~ 90% RH @ 0 ~ 40℃ (non-condensing) | |||||
| Noise level | ≤ 40 dB (1 m) | |||||
| Net weight (kg) | 3.55 | 4.2 | 4.9 | 8.2 | 10.4 | 10.6 |
| Dimensions (D × W × H) (mm) | 279 × 101 × 142 | 320 × 130 ×182 | ||||
We can apply the following adapters
Our services:
1. OEM&ODM services acceptable.
2. Lots of cooperated agent for shipping by sea or by air.
3. 1year warranty, if it is quality problem, we will provide the parts for free.
Little hint:
1. In the warranty period the machine has a problem, please contact the sales staff, we will be responsible for customer service.
2. Exceed the warranty period, improper operation and man-made damage, we will still give help and support, we will provide spare parts at a cost price.
3. According to the customer's needs, we can provide unconventional, but the cost may be slightly higher than the traditional machine.
