Quick Details
-
Warranty:
-
12 years workmanship warranty, 25 years
-
Brand Name:
-
PNG Solar
-
Model Number:
-
PNG550-144M(182)
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
2279*1134*35mm
-
Cell Type:
-
Mono166x83mm
-
Solar cell:
-
A-grade
-
Junction Box:
-
IP68 Rated
-
Glass:
-
3.2mm Tempered Low Iron
-
Frame:
-
Anodized Aluminium Alloy
-
Cable:
-
4mm ^2 300mm PV Cable
-
Weight:
-
28kg
-
Certificates:
-
TUV CE PID ISO
-
Application:
-
Commercial,Industrial,Home
Quick Details
-
Cell size:
-
182mmx182mm
-
Type:
-
PERC, Half Cell, Bifacial, Double-glass, All Black
-
Panel Efficiency:
-
21.5%
-
Warranty:
-
12 years workmanship warranty, 25 years
-
Brand Name:
-
PNG Solar
-
Model Number:
-
PNG550-144M(182)
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
2279*1134*35mm
-
Cell Type:
-
Mono166x83mm
-
Solar cell:
-
A-grade
-
Junction Box:
-
IP68 Rated
-
Glass:
-
3.2mm Tempered Low Iron
-
Frame:
-
Anodized Aluminium Alloy
-
Cable:
-
4mm ^2 300mm PV Cable
-
Weight:
-
28kg
-
Certificates:
-
TUV CE PID ISO
-
Application:
-
Commercial,Industrial,Home
Product Description
ELECTRICAL DATA(STC)
|
Module Type
|
PNG535-144M
|
|
PNG540-144M
|
|
PNG545-144M
|
|
PNG550-144M
|
|
||||||||
|
Rated output(Pmp/Wp)
|
535
|
|
540
|
|
545
|
|
550
|
|
||||||||
|
Maximum power voltage(Vmp/V)
|
41.0
|
|
41.2
|
|
41.4
|
|
41.6
|
|
||||||||
|
Maximum power current(Imp/A)
|
13.05
|
|
13.11
|
|
13.17
|
|
13.23
|
|
||||||||
|
Open circuit voltage(Voc/V)
|
49.2
|
|
49.4
|
|
49.6
|
|
49.8
|
|
||||||||
|
Short circuit current (Isc/A)
|
13.81
|
|
13.87
|
|
13.93
|
|
13.99
|
|
||||||||
|
Module efficiency (%)
|
20.6%
|
|
20.8%
|
|
21.0%
|
|
21.2%
|
|
||||||||
|
Power tolerance (W)
|
0~+5
|
|
0~+5
|
|
0~+5
|
|
0~+5
|
|
||||||||
|
Standard Test Condition（STC）: Irradiance 1000W/m², Cell Tempera ture 25℃, AM1.5
|
|
|
|
|
|
|
|
|
||||||||
|
Module Type
|
PNG535-144M
|
PNG540-144M
|
PNG545-144M
|
PNG550-144M
|
||||
|
Rated output(Pmp/Wp)
|
398.9
|
402.7
|
406.6
|
410.5
|
||||
|
Maximum power voltage(Vmp/V)
|
38.2
|
38.4
|
38.6
|
38.8
|
||||
|
Maximum power current(Imp/A)
|
10.44
|
10.49
|
10.54
|
10.58
|
||||
|
Open circuit voltage(Voc/V)
|
46.1
|
46.3
|
46.4
|
46.6
|
||||
|
Short circuit current (Isc/A)
|
11.13
|
11.18
|
11.23
|
11.28
|
||||
|
Nominal Module Operating Temperature（NMOT): Irradiance 800W/m²,Ambient Temperature 20℃, AM1.5, Wind Speed 1m/s
|
|
|
|
|
||||
|
|
|
|
|
|
||||
