Quick Details
-
Brand Name:
-
ODI/HSGQ
-
Use:
-
FTTX Network solution
-
Warranty Time:
-
1 year
-
Product name:
-
SFP+ Module
-
Wavelength:
-
Tx1270nm/Rx1310nm
-
Supply Voltage:
-
-0.5 ~+3.6 V
-
Storage Temperature:
-
-40 ~+85 ℃
-
Operating Temperature:
-
0~ +70 ℃
-
Certification:
-
CE RoHS FCC
-
Distance:
-
60km
-
Color:
-
silver
-
MOQ:
-
1 Pcs
-
Application:
-
FTTH FTTB FTTC
Quick Details
-
Type:
-
Fiber Optic Transceivers
-
Model Number:
-
SFP-10G-60ER-31
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
ODI/HSGQ
-
Use:
-
FTTX Network solution
-
Warranty Time:
-
1 year
-
Product name:
-
SFP+ Module
-
Wavelength:
-
Tx1270nm/Rx1310nm
-
Supply Voltage:
-
-0.5 ~+3.6 V
-
Storage Temperature:
-
-40 ~+85 ℃
-
Operating Temperature:
-
0~ +70 ℃
-
Certification:
-
CE RoHS FCC
-
Distance:
-
60km
-
Color:
-
silver
-
MOQ:
-
1 Pcs
-
Application:
-
FTTH FTTB FTTC
Product Description
ODI 10G 60KM DWDM SFP+ Transmitter Receiver LC DDM compatible with Extreme switch optical sfp transceiver
1. Single Power Supply 3.3V
2. Small Form-factor Pluggable (SFP)
3. Digital diagnostic monitor compatible with SFF-8472
4. Compliant with ITU-T G.984.2
5. Integrated WDM filter for dual wavelength Operate at 1490 Tx/ 1310nm Rx
6. 1490nm DFB continuos-mode transmitter
7. 1310nm burst-mode APD-TIA receiver
8. LVTTL transmitter disable input and transmitter fault output
9. Hot pluggable capability
10. LVPECL compatible data input/output interface
11. SC Receptacle optical connector
12. compliant with ROHS standard
Applications
Gigabit Ethernet Passive Optical Networks (GPON CLASS B+) –OLT side
Gigabit Ethernet Passive Optical Networks (GPON CLASS B+) –OLT side
Specification
Absolute maximum ratings
|
Parameter
|
Symbol
|
Min.
|
Max.
|
Unit
|
|
Storage Temperature
|
TS
|
-40
|
+85
|
℃
|
|
Operating Temperature
|
Top
|
0
|
+70
|
℃
|
|
Supply Voltage
|
VCC
|
-0.5
|
+3.6
|
V
|
|
Power Supply Current
|
ICC
|
-
|
400
|
mA
|
|
Voltage at any Input Pin
|
VIN
|
0
|
Vcc
|
V
|
