Quick Details
-
Warranty:
-
20years
-
Certification:
-
CE
-
Output Voltage:
-
48V/96V/120V/220V
-
rotor diameter:
-
2.2m
-
Capacity:
-
5000w
-
Start wind speed:
-
1.5m/s
-
Product name:
-
Vertical Wind Power
-
Application:
-
Wind Power System
-
Rated Voltage:
-
96V/120V/220/240V
-
Start-up wind speed:
-
2.5m/s
-
Rated wind speed:
-
11m/s
-
Generator type:
-
Outer Rotor Generator
-
Blade Material:
-
Aluminum Alloy
-
Keywords:
-
Home Wind Power Generator
-
Survival wind speed:
-
45.0m/s
-
Type:
-
H-type
Quick Details
-
Place of Origin:
-
Anhui, China
-
Brand Name:
-
Sunway
-
Model Number:
-
SW-5000H
-
Warranty:
-
20years
-
Certification:
-
CE
-
Output Voltage:
-
48V/96V/120V/220V
-
rotor diameter:
-
2.2m
-
Capacity:
-
5000w
-
Start wind speed:
-
1.5m/s
-
Product name:
-
Vertical Wind Power
-
Application:
-
Wind Power System
-
Rated Voltage:
-
96V/120V/220/240V
-
Start-up wind speed:
-
2.5m/s
-
Rated wind speed:
-
11m/s
-
Generator type:
-
Outer Rotor Generator
-
Blade Material:
-
Aluminum Alloy
-
Keywords:
-
Home Wind Power Generator
-
Survival wind speed:
-
45.0m/s
-
Type:
-
H-type
A vertical- wind turbine does not need to adjust to the wind direction when it changes, which is a major advantage over a horizontal- wind turbine. This not only simplifies the structural design but also reduces the gyroscopic force on the wind rotor.
Product Description
A vertical- wind turbine (VAWT) is a type of wind turbine where the main rotor shaft is set vertically, as opposed to the more common horizontal- wind turbines (HAWT), which have a horizontal main shaft.In a VAWT, the rotor blades are attached to the central vertical shaft and the turbine can spin regardless of the wind direction.
The blades can have a variety of shapes, such as straight, curved or twisted, and can be made from various materials including aluminum, fiberglass or carbon fiber.
VAWTs have several advantages over HAWTs, including simpler design and construction, and they can be installed in areas with lower wind speeds. Additionally, they produce less noise and vibration, and are less harmful to birds and bats.
However, VAWTs also have some disadvantages, including lower efficiency compared to HAWTs, due to the vertical orientation of the rotor blades, and a higher cost of maintenance due to the more complex mechanism of the turbine.
The blades can have a variety of shapes, such as straight, curved or twisted, and can be made from various materials including aluminum, fiberglass or carbon fiber.
VAWTs have several advantages over HAWTs, including simpler design and construction, and they can be installed in areas with lower wind speeds. Additionally, they produce less noise and vibration, and are less harmful to birds and bats.
However, VAWTs also have some disadvantages, including lower efficiency compared to HAWTs, due to the vertical orientation of the rotor blades, and a higher cost of maintenance due to the more complex mechanism of the turbine.
Advantages of wind energy
* Clean energy
* Clean energy
Wind energy is one of the cleanest energy sources. Generating energy using wind turbines does not emit any greenhouse gases.
* Renewable
Wind energy is a renewable energy resource, meaning that the source of energy is not depleted when it is used. So, as we use wind energy we don’t decrease the amount of wind available.
*Space efficient
Wind turbines can’t be placed too close to one another, which is what makes solar farms so large. The wind turbines
themselve,however, don’t take up that much space.
*Low-cost energy
Wind is free! Turbines also have relatively low operating costs once they are erected, and need little maintenance.
* Renewable
Wind energy is a renewable energy resource, meaning that the source of energy is not depleted when it is used. So, as we use wind energy we don’t decrease the amount of wind available.
*Space efficient
Wind turbines can’t be placed too close to one another, which is what makes solar farms so large. The wind turbines
themselve,however, don’t take up that much space.
*Low-cost energy
Wind is free! Turbines also have relatively low operating costs once they are erected, and need little maintenance.
Product Parameter
|
Model
|
SW-2000H
|
SW-3000H
|
SW-5000H
|
SW-10KH
|
|||
|
Rated Power(W)
|
2000
|
3000
|
5000
|
10000
|
|||
|
Maximum power(W)
|
2100
|
3200
|
5200
|
11000
|
|||
|
Rated voltage(V)
|
48v/96v/120v/220v/240v
|
|
96v/120v/220v/240v
|
120v/220v/240v/380v
|
|||
|
Start-up wind speed(m/s)
|
2.5
|
2.5
|
2.5
|
2.5
|
|||
|
Rated wind speed(m/s)
|
11
|
11
|
11
|
11
|
|||
|
Survival wind speed(m/s)
|
45
|
45
|
45
|
45
|
|||
|
Wheel diameter(m)
|
1.55
|
2
|
2.2
|
3.9
|
|||
|
Blades height
|
2.4m
|
3m
|
4.2m
|
5m
|
|||
|
Number of blades
|
5
|
|
|
|
|||
|
Blades material
|
Aluminum alloy
|
|
|
|
|||
|
Generator type
|
Outer rotor generator
|
|
|
|
|||
|
Magnet material
|
NdFeB
|
|
|
|
|||
|
Control system
|
Electromagnet
|
|
|
|
|||
|
Speed regulation
|
Automatically windward
|
|
|
|
|||
|
Working temperature
|
-40°C-80°C
|
|
|
|
|||
Product Details
Application
Product Packaging
If you purchase wind generator from us, wind turbine will be packed with wooden; If you purchase solar and wind hybrid system from us, wind generator packed with wooden,controller and inverter will be packed with carton, solar panel will be packed with pallet.
