Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Niuera
-
Model Number:
-
X-EH-30K-TX-01
-
Output Frequency:
-
45-65Hz
-
Size:
-
300x437x84mm, 300x437x84mm
-
Weight:
-
15KG, ≤15kg
-
Input voltage range:
-
260-485VAC
-
Input current:
-
<60A
-
Peak efficiency:
-
≥96%
-
Power Factor:
-
≥ 0.99
-
Constant power range:
-
30KW(300-1000V)
-
Communication interface:
-
CAN MAX.60
-
Fan Noise:
-
< 65dB (1 m from the device)
-
Certificate:
-
CE, UL
Quick Details
-
Output Current:
-
0~100A, 0-100A
-
Network:
-
CAN
-
Customized support:
-
YES
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Niuera
-
Model Number:
-
X-EH-30K-TX-01
-
Output Frequency:
-
45-65Hz
-
Size:
-
300x437x84mm, 300x437x84mm
-
Weight:
-
15KG, ≤15kg
-
Input voltage range:
-
260-485VAC
-
Input current:
-
<60A
-
Peak efficiency:
-
≥96%
-
Power Factor:
-
≥ 0.99
-
Constant power range:
-
30KW(300-1000V)
-
Communication interface:
-
CAN MAX.60
-
Fan Noise:
-
< 65dB (1 m from the device)
-
Certificate:
-
CE, UL
Product Parameters
|
Input
|
Input Voltage Range
|
260~485V AC
|
|
|
Input Frequency
|
45~65Hz
|
|
|
Input Current
|
＜60A
|
|
|
Peak Efficiency
|
≥96%
|
|
Output
|
Constant Power Range
|
30KW (300~1000V)
|
|
|
Output Voltage
|
150-1000 VDC
|
|
|
Output Current Range
|
0~100A
|
|
|
Communication Interface
|
CAN, Max.60
|
|
|
Size (W*D*H)
|
300*437*84mm
|
|
|
Weight
|
≤15kg
|
|
|
Fan Noise
|
＜65dB (1m from the device)
|
|
|
Ambient Temperature
|
-40℃~75℃; The derated function is used when the temperature is above 55℃
|
|
|
Storage Temperature
|
-40℃~85℃; Humidity:5%~90% no condensation
|
|
|
Short Circuit Protection
|
No module output after short-circuit protection, lock after four times automatic restarts
|
|
|
Output Overvoltage Protection Point
|
1010V±10V (manual recovery, starts locking mode after four times overvoltage)
|
|
|
Overtemperature Protection
|
Automatic protection starts when detection temperature reaches the preset value; After protection,there is no output. After
recovery, you need to start the system by running a command |
