- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
Unionwell
-
Model Number:
-
GPS100 Series
-
Max. Current:
-
16A
-
Max. Working Pressure:
-
4000Pa
-
Operating Pressure Range:
-
25-1500 Pa
-
Switching Pressure Rahnge:
-
10 Pa Min.
-
Operating Temperature:
-
-40-+90℃
-
Certification:
-
ISO9001 & TS16949
-
Switching Rating:
-
0.1A/ 3A /5A /16A 125/250VAC
-
Function/circuit:
-
SPDT (or SPST-NO, NC for option
-
Measured Media:
-
Air
-
Application:
-
Water Pump
-
Product name:
-
GPS100 series
-
Media:
-
Air
Quick Details
-
Whether the smart:
-
NO
-
Max. Voltage:
-
250VAC
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Unionwell
-
Model Number:
-
GPS100 Series
-
Max. Current:
-
16A
-
Max. Working Pressure:
-
4000Pa
-
Operating Pressure Range:
-
25-1500 Pa
-
Switching Pressure Rahnge:
-
10 Pa Min.
-
Operating Temperature:
-
-40-+90℃
-
Certification:
-
ISO9001 & TS16949
-
Switching Rating:
-
0.1A/ 3A /5A /16A 125/250VAC
-
Function/circuit:
-
SPDT (or SPST-NO, NC for option
-
Measured Media:
-
Air
-
Application:
-
Water Pump
-
Product name:
-
GPS100 series
-
Media:
-
Air
Greetech hot selling air pressure switch for stove
Specification:
|
Set-Point Range |
10-1500pa |
|
Operating Pressure Range |
25-1500pa |
|
Switch Pressure Range |
10pa Min |
|
Rating |
0.1A 125/250VAC; 3A 125/250VAC; 5A 125/250VAC; 16A 125/250VAC |
|
Circuit Configuration |
SPDT,SPST-NO,SPST-NC |
|
Measured Media |
Air |
|
Operating Temperature |
-40℃-+90℃ |
Drawing
Application
More about packaging details:
|
No. |
Greetech Product |
Inner Box |
Shipper Carton |
MPQ |
||||||
|
Inner box size(mm) |
Q'ty/(pcs) |
Total GW(kgs) |
Carton size(mm) |
Q'ty/ctn
|
Total GW(kgs) |
MOQ (pcs) |
L/T (Days) |
Total GW(kgs) |
||
|
1 |
G3 series(terminal type) |
310x215x135 |
3,360 |
3.9 |
440x325x300 |
13,440 |
15.3 |
1,000 |
15 |
1.2 |
|
2 |
G5 series |
310x250x120 |
600 |
5.5 |
330x270x270 |
1,200 |
10.8 |
1,000 |
15 |
9.0 |
|
3 |
G5W11 series |
310x215x135 |
200 |
4.8 |
440x325x300 |
800 |
19.2 |
100 |
10 |
2.5 |
|
4 |
G6 series |
290x192x40 |
500 |
1.3 |
400x305x220 |
5,000 |
12.5 |
1,000 |
15 |
2.7 |
|
5 |
G9 series(terminal type) |
290x192x40 |
500 |
1.3 |
400x305x220 |
5,000 |
12.5 |
1,000 |
15 |
2.7 |
|
6 |
G91 series |
290x192x40 |
500 |
1.3 |
400x305x220 |
5,000 |
12.5 |
1,000 |
15 |
2.7 |
|
7 |
G10 series |
290x192x40 |
600 |
1.3 |
400x305x220 |
6,000 |
12.5 |
1,000 |
15 |
2.7 |
|
8 |
GT02 series |
210x155x55 |
300 |
1.2 |
440x325x285 |
6,000 |
12.0 |
6,000 |
15 |
12.0 |
|
9 |
GPS100 series |
/ |
/ |
/ |
330*270*270 |
60 |
6.1 |
60 |
10 |
6.1 |
|
10 |
Switch with wire leads |
310x215x135 |
100 |
1.8 |
440x325x300 |
800 |
14.5 |
800 |
20 |
14.5 |
shipping:
