AGV Helicopter Automatic Towing Trolley Tractor Remote Control With 50cm Lift Device

AGV Helicopter Automatic Towing Trolley Tractor Remote Control With 50cm Lift Device

FOB Reference Price: Get Latest Price

≥1 Pieces

US $11000

≥10 Pieces

US $10000

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Brand Name:: ZHLUN

Product Name:: Tow Trailer AGV

Size:: 2714*905*579mm

Traction Weight:: 2T

Running speed:: 1m/min

Function:: Traction

Drive type:: 1 Drive wheel + 2 caster

Max. lifting height:: 486mm

Feature:: Automatic walking

Application:: Industrial Filed

Quick Details

Warranty:: 1 Year

Weight (KG):: 800

Place of Origin:: Guangdong, China

Brand Name:: ZHLUN

Product Name:: Tow Trailer AGV

Size:: 2714*905*579mm

Traction Weight:: 2T

Running speed:: 1m/min

Function:: Traction

Drive type:: 1 Drive wheel + 2 caster

Max. lifting height:: 486mm

Feature:: Automatic walking

Application:: Industrial Filed

Product Overview

Aircraft towing AGV

ZL-T12-380 is a towing autonomous mobile robot which autonomously conveys items by pulling them to previously set locations to achieve efficient handling for your operations. This product performs to transport up to 2000kg of loads. AGV operation is usually completely automated, but if frequent human interaction is required, they can be designed for manual operation as well.

Magnetic navigation automates it and sets up transport tasks, one robot can meet the needs of conveying materials from different production lines in the same factory area.

The product adopts our highly reliable chassis and standard roller module to ensure the reliability of the product.

At the same time, we also provide customers with a variety of navigation types to choose from.

Remote Control / Navigation Methods

Product Specification

Basic	Dimensions (LWH)	mm	2714905579
		Load surface dimensions	mm (L*W)	N/A
		Self-weight	KG	＜800
		Maximum traction	KG	2000
Athletic	Maximum speed	m/s	1.5 m/s
		Working speed	m/s	1 m/s
		Turning radius	mm	600
		Climbing ability	/	3°-5°
		Obstacle clearance height	mm	10
		Over gap width	mm	30
		Ground clearance	mm	30
		Site location accuracy	mm	±10
		Precise docking accuracy	mm	±5
Battery	Battery capacity	/	48V 80Ah
		Continuous working time	hours	10
		Battery lifetime	/	DOD≥80% 1800
		Charging method	/	Automatic + Manual
		Charging time	hours	4
