Quick Details
-
Table Travel (Z) (mm):
-
50 mm
-
Max. Table Load(kg):
-
380
-
Travel (W-axis) (mm):
-
0 mm
-
Range of Spindle Speed(r.p.m):
-
1000 r.p.m
-
Spindle Motor Power(kW):
-
1.8
-
Production Capacity:
-
50 Sets / Month
-
Place of Origin:
-
Shaanxi, China
-
Brand Name:
-
Tendtool
-
Voltage:
-
380V
-
Dimension(L*W*H):
-
1560X1135X2180
-
Weight (T):
-
1.18 T
-
Product type:
-
Valve seat Boring Machine
-
Name:
-
Engine Boring
-
Functions:
-
Machining
-
Color:
-
Red
-
Application:
-
Valve
-
Usage:
-
Automobile
-
Packing:
-
Standard export
-
Power(W):
-
1.8KW
-
After-sales Service Provided:
-
Video technical support
-
After Warranty Service:
-
Video technical support, Field maintenance and repair service
-
Local Service Location:
-
Malaysia, Romania
-
Certification:
-
ISO CE
Quick Details
-
Table Size (mm):
-
930x1130
-
Table Travel (X) (mm):
-
930 mm
-
Table Travel (Y) (mm):
-
630 mm
-
Table Travel (Z) (mm):
-
50 mm
-
Max. Table Load(kg):
-
380
-
Travel (W-axis) (mm):
-
0 mm
-
Range of Spindle Speed(r.p.m):
-
1000 r.p.m
-
Spindle Motor Power(kW):
-
1.8
-
Production Capacity:
-
50 Sets / Month
-
Place of Origin:
-
Shaanxi, China
-
Brand Name:
-
Tendtool
-
Voltage:
-
380V
-
Dimension(L*W*H):
-
1560X1135X2180
-
Weight (T):
-
1.18 T
-
Product type:
-
Valve seat Boring Machine
-
Name:
-
Engine Boring
-
Functions:
-
Machining
-
Color:
-
Red
-
Application:
-
Valve
-
Usage:
-
Automobile
-
Packing:
-
Standard export
-
Power(W):
-
1.8KW
-
After-sales Service Provided:
-
Video technical support
-
After Warranty Service:
-
Video technical support, Field maintenance and repair service
-
Local Service Location:
-
Malaysia, Romania
-
Certification:
-
ISO CE
Valve Seat Boring Machine
| Model | TX90 | |
| Machine capabilities | ||
| Max.length of the cylinder head | mm/inch | Unlimited |
| Max.width of the cylinder head | mm/inch | 500/19.7 |
| Max.height of the cylinder head | mm/inch | 450/17.7 |
| Crosswise work piece tilting | degrees | +4 . ~-15 . |
| Machining capacity dia. (min-max) | ∅mm/inch | 16-90/0.6-3.5 |
| Work head diaplacement | ||
| Lengthwise | mm/inch | 930/7 |
| Crosswise | mm/inch | 40/16 |
| Sphere-Cylinder travel | mm/inch | 9/0.4 |
| Spindle | ||
| Max. spindle incination | degrees | 5 |
| Spindle Travel | mm/inch | 200/8 |
| Power of the spindle | kw | 2.2 |
| Spindle rotation speed | rpm | 0-1000 |
| Alimentations | 380V/50Hz 3Ph | |
| Electric | 220V/60Hz 3Ph | |
| Air pressure | bar/psi | 6/87 |
| Net weight ( approx. ) | kgs/lbs | 1050/2310 |
| Machine space requirements | ||
| length | mm/inch | 1440/56.7 |
| Width | mm/inch | 1050/41.3 |
| Height | mm/inch | 2170/85.4 |
