Package Size: 115*80*15cm;
Explore More Products
- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Panel Dimensions:
-
900*800*3mm
-
Panel Efficiency:
-
23.70%
-
Product name:
-
100W 120W 600W 800W 1000w Balcony Flexible PV Solar Panels
-
Peak power Pm(W):
-
120W
-
Maximum working voltage:
-
18V
-
Maximum working current:
-
6.67A
-
Flexibility:
-
180 degrees
-
Weight:
-
2.16kg
-
Front cover(material/thickness):
-
ETFE/0.03mm
-
Frame(material/collor):
-
No
-
Junction box protection degree:
-
≥IP65
-
No. of cells:
-
36 series
Quick Details
-
Cell size:
-
182mmx182mm
-
Brand Name:
-
FGET
-
Model Number:
-
120W-FG02A
-
Place of Origin:
-
Guangdong, China
-
Panel Dimensions:
-
900*800*3mm
-
Panel Efficiency:
-
23.70%
-
Product name:
-
100W 120W 600W 800W 1000w Balcony Flexible PV Solar Panels
-
Peak power Pm(W):
-
120W
-
Maximum working voltage:
-
18V
-
Maximum working current:
-
6.67A
-
Flexibility:
-
180 degrees
-
Weight:
-
2.16kg
-
Front cover(material/thickness):
-
ETFE/0.03mm
-
Frame(material/collor):
-
No
-
Junction box protection degree:
-
≥IP65
-
No. of cells:
-
36 series
Product Description
Wholesale Solar Module 100W 120W 300w 400w 500w 600W 800W 1000w Balcony Flexible PV Solar Panels with CE TUV
* Durability: state-of-the-art technology.
* Solar Cell: Made of Grade A PERC 9BB monocrystalline solar cells.
* Premium EFTE Film – This film features superior light transmission and weather resistant performance.
* Shade tolerant.
* Tabletop: Durable fiberglass tabletop with better heat dissipation and heat resistant PET/TPT tabletop.
* Ultra-thin: only 3mm thick.
* Installation: can be fixed with adhesive, grommets, zip ties or Velcro.
* Net Weight: 9 lbs/4 kg .
* Back sheet: black fiberglass
* J-Box: IP 68 rated with 90cm/3ft cables.
*
WiFi
Real time monitoring.
* High efficiency up to
99%
* Come with built-in WIFI module, so that it can communicate with router directly
* Waterproof IP65，
10 years warranty
Super Factory
Product Description
Specification
|
Electrical Characteristics @ STC
|
Flexible-FB120
|
Flexible-FB120
|
|
|
Peak Power Watts-PMAX
|
Wp*
|
120
|
|
|
Power Output Tolerance-PMAX
|
W
|
0/+5
|
|
|
Maximum Power Voltage-VMPP
|
V
|
19.8
|
|
|
Maximum Power Current-IMPP
|
A
|
6.06
|
|
|
Open Circuit Voltage-VOC
|
V
|
24.51
|
|
|
Short Circuit Current-ISC
|
A
|
6.41
|
|
|
Module Efficiency ηm
|
%
|
0.20
|
|
|
Maximum System Voltage
|
V
|
100
|
|
|
Temperature Coefficient of Pmax
|
%/°C
|
-0.34
|
|
|
Temperature Coefficient of Voc %
|
/°C
|
-0.27
|
|
|
Temperature Coefficient of Isc
|
%/°C
|
0.04
|
|
|
Mechanical Characteristics
|
|
|
|
|
Cell Orientation
|
36cells4*9
|
|
|
|
Dimensions
|
900mm*800mm*3mm(L×W×H)
|
|
|
|
Weight
|
2.8±3%kg
|
|
|
|
Sureface
|
ETFE
|
|
|
|
Color
|
Full Black
|
|
|
|
J-Box
|
20A IP67 or IP68 rated
|
|
|
|
Cables
|
PV Cable 4.0mm²
|
|
|
|
Connector
|
28 QC4/TS4
|
|
|
|
Packaging
|
|
|
|
Product packaging
Solar Panel Size: 900*690*3mm
Case Show
About Us
FAQ
Q1: How to choose the right
Balcony
Solar Power System
?
A1: Tell us your demand, then our sales will recommend a suitable system for you.
Q2: What's the difference between Mono and Poly panel?
A2: Monocrystalline solar panels have the highest efficiency rates since they are made out of the highest-grade silicon. The process used to make polycrystalline silicon is simpler a
Q3: How about the delivery time?
A3: 7 days for sample; 15 days for bulk order.
Q4: What is the warranty for solar panels?
A4: 10 years warranty on FGET-Solar panel.
Q5: How to solve the technical problem?
A5: 24 hours after-service consultancy just for you and to make your problem to solve easily.
A1: Tell us your demand, then our sales will recommend a suitable system for you.
Q2: What's the difference between Mono and Poly panel?
A2: Monocrystalline solar panels have the highest efficiency rates since they are made out of the highest-grade silicon. The process used to make polycrystalline silicon is simpler a
nd costs less. The amount of waste silicon is less compared to monocrystalline.
Q3: How about the delivery time?
A3: 7 days for sample; 15 days for bulk order.
Q4: What is the warranty for solar panels?
A4: 10 years warranty on FGET-Solar panel.
Q5: How to solve the technical problem?
A5: 24 hours after-service consultancy just for you and to make your problem to solve easily.
Wholesale Solar Module 100W 120W 300w 400w 500w 600W 800W 1000w Balcony Flexible PV Solar Panels with CE TUV
