- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
OEM
-
Model Number:
-
OP-1205000
-
Output Frequency:
-
N/A
-
Output Current:
-
5A
-
Size:
-
11cm x 7.8cmx 3.6cm(4.3in x 3.1in x 1.4in)
-
Working temperature:
-
-10°C to 60 °C
Quick Details
-
Input Voltage:
-
AC100-240V
-
Output Voltage:
-
12V
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
OEM
-
Model Number:
-
OP-1205000
-
Output Frequency:
-
N/A
-
Output Current:
-
5A
-
Size:
-
11cm x 7.8cmx 3.6cm(4.3in x 3.1in x 1.4in)
-
Working temperature:
-
-10°C to 60 °C
Specification
12Volt 5A 60W LED Lighting Mining Single Output Switching Power Supply Adapter Transformers With CE Power Strip
1. Universal switching mode power supply. Input: AC 110V~ 220V, 50 / 60Hz ; Output: DC 12V,
Max 5A 60W. Two output ports. Each port outputs 0~5A automatically, 5A max in total for 2
ports. The default output voltage is 12V, but it can be regulated by 10%, from 10.8V to 13.2V.
2. It can supply with all currents less than 5A, such as 1A, 1.5A, 2A, 2.5A, 3A, 3.5A, 4A, 4.5A, 5A.
For example, if your device draws 3.8A, then 3.8A will be supplied. If draws more than 5A,
only 5A will be supplied and power supply will be damaged soon. NEVER OVERLOAD !
3. Certified by FCC CE . We focus on producing high quality power transformers. Automatically
over-current cut-off, over-voltage cut-off, over -temperature cut-off, short circuit protection.
Low noise, no spontaneous combustion, no explosion, no fire hazard, stable output, safe to
use.
4.
It is widely use to driving 12V LED strip light, flood light, commercial lighting project, wireless
router, ADSL cats, HUB, home security cameras, audio/ video devices, 3D printer, CCTV DVR
NVR Surveillance System, LCD/LED monitor screen, webcam router, speaker or other 12V
devices less than 60W.
Parameter：
Input: AC 110V/220V，50/60Hz
Output Voltage: DC 12V ( Regulated by 10% )
Output Current: Max 5A
Output Wattage:Max 60W
Size: 11cm/4.3in x 7.8cm/3.1in x 3.6cm/1.4in
Material:aluminum, electronic components
Safety Compliance: FCC / CE
Fix Screw Hole Diameter: 2.5mm (0.1inch)
Working temperature: -10°C to 60 °C
Environmental humidity: 10%-95%
Weight: 0.44 lb / 200g
Package included:
1x 12V 5A power supply (power cord is not included)
Kindly note：
It comes without installation instruction, power cord, on/off switch and screws. Professional installation of licensed electrician is highly recommended.
High voltage inside, NEVER remove the cover. Not waterproof, indoor use only.
Make sure your device match the 12V voltage and wattage less than 60W. Please don’t run it overload.
We recommend you to use this 12V 5A 60W power supply to power devices less than 48W.
Connection instruction
L : AC Live Wire
N : AC Neutral wire
〨: Ground
+V:DC 12V+
-V: DC 12V-
+V ADJ: Adjust output voltage by 10%
