Quick Details
-
Panel Size:
-
Customized
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
CH01-A
-
Cabinet Size(mm):
-
500*500mm and 500*1000mm
-
Brightness:
-
6000cd/sqm
-
Refresh Rate:
-
>3840Hz
-
Display Function:
-
Video
-
delivery time:
-
7 to 20 days
-
Screen Dimension:
-
Customized
-
LED Configuration:
-
SMD 3-in-1
-
Cabinet material:
-
die-casting aluminum
-
Grey scale:
-
16 bit
-
Cabinet Weight(±0.25kg):
-
7.5kg
Quick Details
-
Application:
-
Indoor, Outdoor
-
Brand Name:
-
CHUANGYI
-
Color:
-
full color
-
Panel Size:
-
Customized
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
CH01-A
-
Cabinet Size(mm):
-
500*500mm and 500*1000mm
-
Brightness:
-
6000cd/sqm
-
Refresh Rate:
-
>3840Hz
-
Display Function:
-
Video
-
delivery time:
-
7 to 20 days
-
Screen Dimension:
-
Customized
-
LED Configuration:
-
SMD 3-in-1
-
Cabinet material:
-
die-casting aluminum
-
Grey scale:
-
16 bit
-
Cabinet Weight(±0.25kg):
-
7.5kg
Product Specification
|
Pixel Pitch(mm)
|
2.6
|
2.97
|
3.91
|
4.81
|
|||
|
Pixel Density(dot/㎡)
|
147456
|
112896
|
65536
|
43264
|
|||
|
LED Type
|
SMD1515
|
SMD2121
|
SMD2121
|
SMD2121
|
|||
|
Module Size(mm*mm)
|
250*250
|
250*250
|
250*250
|
250*250
|
|||
|
Cabinet Size(mm)
|
500x500x85
|
500x500x85
|
500x500x85
|
500x500x85
|
|||
|
Cabinet Weight(±0.25kg)
|
7.5
|
7.5
|
7.5
|
7.5
|
|||
|
Cabinet Resolution
|
192x192dots
|
168x168dots
|
128x128dots
|
104x104dots
|
|||
|
application scenarios
|
indoor
|
indoor
|
indoor
|
indoor
|
|||
|
Brightness(nits)
|
800~1000
|
800~1000
|
800~1000
|
800~1000
|
|||
|
Scan
|
1/32
|
1/28
|
1/32
|
1/13
|
|||
|
Gray Scale
|
16
|
16
|
16
|
16
|
|||
|
Life Span (h)
|
≥100000h
|
≥100000h
|
≥100000h
|
≥100000h
|
|||
|
Avg power (w/㎡)
|
240
|
240
|
240
|
240
|
|||
|
Max power (w/㎡)
|
800
|
800
|
800
|
800
|
|||
|
Cabinet Material
|
Die-casting Aluminum
|
|
|
|
|||
|
Service Access
|
Front & Rear
|
|
|
|
|||
|
Refresh Rate (Hz)
|
1920 / 3840
|
|
|
|
|||
|
Viewing Angle (H/V)
|
140°/140°(±10°)
|
|
|
|
|||
|
IP Rate
|
IP24
|
|
|
|
|||
|
Operation Temperature
|
-40°C ~ 45°C
|
|
|
|
|||
|
Input Voltage (AC)
|
100V to 240V
|
|
|
|
|||
