Quick Details
-
Brand Name:
-
Rang Dong
-
Model Number:
-
TR70 ; TR80; TR100; TR120; TR140
-
CRI (Ra>):
-
80/90/Sunlike
-
Lamp Luminous Efficiency(lm/w):
-
85/90/95/100/120
-
Lamp Luminous Flux(lm):
-
1020 - 5000
-
Color Rendering Index(Ra):
-
80/90/Sunlike
-
Power (W):
-
12/14/20/30/40/50
-
Power Factor:
-
0.5/0.7/0.9
-
Luminous Efficacy (lm/W):
-
85/90/95/100/120
-
CCT (K):
-
3000/4000/5000/ 5700/6500
-
CRI:
-
80/90/Sunlike
-
Lifespan (hrs):
-
15000/20000/25000
-
Voltage (V):
-
100-277/120/220-240
-
Certificates:
-
CE, KC, RoHS
-
Dimension DxH (mm):
-
100x185/120x208/70x128/80x143/100x185/140x225
Quick Details
-
Color Temperature(CCT):
-
3000/4000/5000/ 5700/6500
-
Input Voltage(V):
-
100-277/120/220-240
-
Place of Origin:
-
Hanoi, Vietnam
-
Brand Name:
-
Rang Dong
-
Model Number:
-
TR70 ; TR80; TR100; TR120; TR140
-
CRI (Ra>):
-
80/90/Sunlike
-
Lamp Luminous Efficiency(lm/w):
-
85/90/95/100/120
-
Lamp Luminous Flux(lm):
-
1020 - 5000
-
Color Rendering Index(Ra):
-
80/90/Sunlike
-
Power (W):
-
12/14/20/30/40/50
-
Power Factor:
-
0.5/0.7/0.9
-
Luminous Efficacy (lm/W):
-
85/90/95/100/120
-
CCT (K):
-
3000/4000/5000/ 5700/6500
-
CRI:
-
80/90/Sunlike
-
Lifespan (hrs):
-
15000/20000/25000
-
Voltage (V):
-
100-277/120/220-240
-
Certificates:
-
CE, KC, RoHS
-
Dimension DxH (mm):
-
100x185/120x208/70x128/80x143/100x185/140x225
Product Features
- High-quality LEDs provided by Samsung/ Seoul Semiconductor/ Nichia/ Lumiled with excellent performance
- High luminous efficacy up to 120 lm/W
- Heat-conductive PBT over moulded aluminium housing with perfect heat dissipation
- PC cover with high lighting transmittance and desired lighting distribution
- CE, KC, UL certified
- Long lifespan: 20,000 hours, saving the maintenance cost
Applications
- Home, hall, store, warehouse, factory and etc.
Products Details
Product Specifications
|
Model
|
Dimension
LxWxH (mm)
|
Power
(W)
|
Voltage (V)
|
Power factor
|
Luminous flux
(lm)
|
Luminous efficacy
(lm/W)
|
CCT (K)
|
Lifespan
(hrs)
|
|
TR100N2/27W
|
100x185
|
27
|
220-240
|
0.9
|
2300/2500
|
85/92
|
3000/6500
|
25,000
|
|
TR100/30W
|
100x185
|
30
|
220-240
|
0.5
|
2700/2850
|
90/95
|
3000/6500
|
15,000
|
|
TR120N2/36W
|
120x208
|
36
|
220-240
|
0.9
|
3200/3600
|
88/100
|
3000/6500
|
25,000
|
|
TR120/40W
|
120x208
|
40
|
220-240
|
0.5
|
3600/3800
|
90/95
|
3000/6500
|
15,000
|
|
TR70N2/12W.H
|
70x128
|
12
|
120/220-240/
100-277
|
0.5/0.7/0.9
|
1020/1080 1140/1200
|
85/90 95/100
|
3000/4000/5000/
5700/6500
|
20,000
|
|
TR70N1/14W.H
|
70x128
|
14
|
120/220-240/
100-277
|
0.5/0.7/0.9
|
1190/1260 1330/1400
|
85/90 95/100
|
3000/4000/5000/
5700/6500
|
20,000
|
|
TR80N1/20W.H
|
80x143
|
20
|
120/220-240/
100-277
|
0.5/0.7/0.9
|
1700/1800 1900/2000
|
85/90 95/100
|
3000/4000/5000/
5700/6500
|
20,000
|
|
TR100N1/30W.H
|
100x185
|
30
|
120/220-240/
100-277
|
0.5/0.7/0.9
|
2550/2700 2850/3000
|
85/90 95/100
|
3000/4000/5000/
5700/6500
|
20,000
|
|
TR120N1/40W .H
|
120x208
|
40
|
120/220-240/
100-277
|
0.5/0.7/0.9
|
3400/3600 3800/4000
|
85/90 95/100
|
3000/4000/5000/
5700/6500
|
20,000
|
|
TR140N1/50W.H
|
140x225
|
50
|
120/220-240/100-277
|
0.5/0.7/0.9
|
4250/4500 4750/5000
|
85/90 95/100
|
3000/4000/5000/
5700/6500
|
20,000
|
Capacity:
13.5 million pieces per year
Customizable:
Power (12/14/20/27/30/36/40/50W), Voltage (120/220-240/100-277), PF(0.5/0.7/0.9), lm/W (up to 120), CCT (3000/4000/5000/5700/6500K), CRI (80/90/Sunlike), lifespan, etc.
Luminous Intensity Distribution
Packing and Transportation
|
Type of lamps
|
Quantity in master box (pcs)
|
Estimated quantity/20'DC (pcs)
|
Estimated quantity/40'HC (pcs)
|
|||
|
TR70 12W/14W
|
24
|
64728
|
148656
|
|||
|
TR80 20W
|
24
|
39744
|
91272
|
|||
|
TR100 27W/3W
|
24
|
28080
|
64488
|
|||
|
TR120 36W/40W
|
12
|
15468
|
35508
|
|||
|
TR140 50W
|
12
|
8784
|
20172
|
|||
|
Customizable according to customer’s request
|
|
|
|
|||
Exported market: South Korea, EU, etc.
