- Product Details
- {{item.text}}
Quick Details
-
Circulation Type:
-
Indirect / Closed Loop (Active)
-
Capacity:
-
160
-
Place of Origin:
-
China
-
Brand Name:
-
JIAJIARE SOLAR
-
Model Number:
-
JJR-GSWH-160
-
Out tanks:
-
Galvanized steel
-
inner tank:
-
SUS304 2B food grade
-
frame:
-
low angel
-
tube:
-
three layer vacuum tubes
-
color:
-
As you like
-
Max temperature:
-
96 degree
-
Certification:
-
EN12976 ISO9001-2008
Quick Details
-
Warranty:
-
2 years
-
Application:
-
Car, RV, Outdoor, Hotel, Garage, Commercial, Household
-
Type:
-
Evacuated Tube
-
Circulation Type:
-
Indirect / Closed Loop (Active)
-
Capacity:
-
160
-
Place of Origin:
-
China
-
Brand Name:
-
JIAJIARE SOLAR
-
Model Number:
-
JJR-GSWH-160
-
Out tanks:
-
Galvanized steel
-
inner tank:
-
SUS304 2B food grade
-
frame:
-
low angel
-
tube:
-
three layer vacuum tubes
-
color:
-
As you like
-
Max temperature:
-
96 degree
-
Certification:
-
EN12976 ISO9001-2008
1). Production usage :Acquire hot water for home use.
2 ).Range of the application :
1.hot water home use,
2.hot water projects,
3.swimming pool.
3). Products Advantages :
1. CCC,CE,ISO Certificated.European stardard.
2. SUS 304 Food grade tank .Absolutely safe.
3.Use the sun energy,very cheap and absolutely envirenmental.
4.5 years long wrranty.
5.quick delivery, with in 10 or 15 days with container quantity.
4). Products specification :
|
Water tank |
Inner tank: stainless steel SUS304-2B,0.4mm thickness, 360mm |
|
Outer tank: Galvanized steel,0.4mm thickness , 460mm |
|
|
Insulation: polyurethane foaming, 50mm thickness |
|
|
Working pressure: 4 Bar |
|
|
Heat preservation: 72 hours |
|
|
Capacity:100/120/150/180/200/240/300/360L |
|
|
Vacuum tube |
Structure: all-glass double-tube co-axial structure |
|
Material: high borosilicate glass 3.3 |
|
|
Coating: ALN/AIN-SS/CU |
|
|
Sediment method: 3 target magnetron sputtering plating |
|
|
External pipe: Φ58mm, Internal pipe: Φ47mm, Length:1800mm, |
|
|
Vacuum tightness: P≤5.0*10-3Pa |
|
|
Absorption Rate: 93%~96% (AM1.5) |
|
|
Emission Rate: 4%~6% (80°C±1.5°C) |
|
|
Frame |
Galvanized steel,1.5mm thickness, 100mm*100mm |
|
Angle: 27 º .38 º . 45° |
|
|
Accessories |
Mg Bar: direct plug and screwed |
|
1500 kw electrical heater as back up |
|
|
controller:TK-5 |
|
|
Warranty |
5 - years |
1)Port: Shanghai or Ningbo
2)Selling package:all export carton.
3)Transport package:Samples use the wooden box, other use the export cartons
4)Shipping:Small LCL and high value suggest the air transport . FCL use the sea vayage.
1).Free sample service: One or two samples below 100L will be free to our clietns.
Terms;Clietns pay the samples first , we will cut the samples value in the next order.
2).OEM service:we are a solar water manufacturer, we provide the free OEM for the container quantity clients, no matter
20 feet container or 40HQ container.
3).After service:
1.Tech support:we will provide all the tech support ,including the instal manual the advatisment, the repairments and selling.
2.Refunding and exchanging: we will provide the free refund and exchange for the broken products in the warranty.but we will make some evaluation before we make the complement.
3.Anual visit: we will make a viist to our client to have a local vist ans meeting to make our business better.
