Quick Details
-
Tube Length(ft):
-
4ft
-
Input Voltage(V):
-
85-265VAC
-
CRI (Ra>):
-
88
-
Working Temperature(℃):
-
-20 - 60
-
Working Lifetime(Hour):
-
50000
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
zxleds
-
Model Number:
-
led linear
-
product:
-
led linear lights
-
Power:
-
20/40/60/80
-
Length:
-
2ft/3ft/4ft/5ft/6ft/8ft
-
Beam angle:
-
120 Degree
-
LED Light Source:
-
SMD2835
-
Installation:
-
Hanging
-
Power factor:
-
PF>0.9
-
Feature:
-
Seamless
-
Driver:
-
Constant Current
Quick Details
-
Warranty(Years):
-
3
-
Lamp Luminous Efficiency(lm/w):
-
85
-
Lamp Body Material:
-
Aluminum Alloy
-
Tube Length(ft):
-
4ft
-
Input Voltage(V):
-
85-265VAC
-
CRI (Ra>):
-
88
-
Working Temperature(℃):
-
-20 - 60
-
Working Lifetime(Hour):
-
50000
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
zxleds
-
Model Number:
-
led linear
-
product:
-
led linear lights
-
Power:
-
20/40/60/80
-
Length:
-
2ft/3ft/4ft/5ft/6ft/8ft
-
Beam angle:
-
120 Degree
-
LED Light Source:
-
SMD2835
-
Installation:
-
Hanging
-
Power factor:
-
PF>0.9
-
Feature:
-
Seamless
-
Driver:
-
Constant Current
|
Measurement:
|
|
|
|
Product name
|
LED Linear Light - 5065
|
|
|
Product Model No
|
LS5065-PZ
|
|
|
Housing material
|
6063-T5
|
|
|
Surface treatment
|
Powder coated or Brushed aluminum
|
|
|
CCT
|
3000K,4000K,6000K
|
|
|
LEDs
|
2835SMD (SANAN chip)
|
|
|
LEDs Life Span
|
50000H
|
|
|
Input Voltage
|
100-277V/200-240V 50/60HZ
|
|
|
Power supplier
|
Flicker-free
|
|
|
Luminous Efficacy(lm/w)
|
100lm/W
|
|
|
Color Render (CRI)
|
RA≥80 or RA≥90
|
|
|
Power factory(PF)
|
≥0.9
|
|
|
Optional features :
|
0-10V dimming, DALI dimming,CCT dimming
|
|
|
IP Rated
|
IP20
|
|
|
Beam Angle
|
120° (Degree Beam Angle)
34° Reflector cup
|
|
|
Working Temp(℃)
|
Surrounding Ambiance Temperature -25°~40°Degree Celsius
|
|
|
Body Material
|
aluminum,PC,ABS
|
|
|
Color Option(shell)
|
Silver,White,Black
|
|
|
Certification
|
CE, RoHS
|
|
|
Limited Warranty
|
3 Years
|
|
|
Model
|
Size
|
Watts
|
Voltage
|
CRI
|
|
5065LS20W06-PZ
|
L605*W50*H65
|
20W
|
AC200-240V/100-277v
|
Ra>80
|
|
5065LS40W12-PZ
|
L1200*W50*H65
|
40W
|
AC200-240V/100-277v
|
Ra>80
|
|
5065LS60W18-PZ
|
L1795*W50*H65
|
60W
|
AC200-240V/100-277v
|
Ra>80
|
|
5065LS80W24-PZ
|
L2390*W50*H65
|
80W
|
AC200-240V/100-277v
|
Ra>80
|
1.Connect with seamless, form with line shape.
2.Product can be used hanging ,surface mounted, recessed installation.
3.Cap with PC plastic moulding , connect with PC cover with seamless which let the light can't run out.
4.Aluminum PCB with no-facula design, connection by rotate installing which conveniently and easily.
5.PC cover transmitting rate reach 86%, luminous reach 110lm/w.
6.IC driver. No flicker, No glaring.CIR ≥ 80.PF ≥ 0.9 and corrosion.
6.Product passed TUV SAA CE FCC ROSH certifications.
Seamless and linkable.
|
model
|
pcs/carton
|
outer box size
|
weight/carton
|
|
7575LS20W06
|
9PCS
|
655×282×184mm
|
18KG
|
|
7575LS40W12
|
9PCS
|
1250×282×184mm
|
31 KG
|
|
7575LS60W18
|
6PCS
|
1847×282×122mm
|
31KG
|
|
7575LS80W24
|
6PCS
|
2444×282×122mm
|
37.5KG
|
Use in shopping mall, office, school, leisure site, garage, factory, school, supermarket, hospital, store
etc.
