Quick Details
-
Model Number:
-
acrylic swimming pool
-
Materials:
-
100% Purity Acrylic, Plexi glass, PMMA
-
Color:
-
Clear, 93% Light transmission
-
Shape:
-
Flat, L-Shape, U-Shape, Curved, Cylinder
-
Application:
-
Pool Side, Pool Window, Pool Floor, acrylic Pool
-
Warranty:
-
20 years Quality Guarantee, No yellowing outside
-
VST:
-
103℃ Vicat Softening Temperature
-
Certificate:
-
Pass CE, SVHC, US-CA65, CPSIA Test
-
Installation:
-
On-site Waterproof and Installation Guidance and Service
-
Annealing:
-
All machined acrylic products is annealed to relieve stress
-
Packing:
-
PE Film, EVA, Plywood and Metal Framework
Quick Details
-
Type:
-
Pool
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
grandview
-
Model Number:
-
acrylic swimming pool
-
Materials:
-
100% Purity Acrylic, Plexi glass, PMMA
-
Color:
-
Clear, 93% Light transmission
-
Shape:
-
Flat, L-Shape, U-Shape, Curved, Cylinder
-
Application:
-
Pool Side, Pool Window, Pool Floor, acrylic Pool
-
Warranty:
-
20 years Quality Guarantee, No yellowing outside
-
VST:
-
103℃ Vicat Softening Temperature
-
Certificate:
-
Pass CE, SVHC, US-CA65, CPSIA Test
-
Installation:
-
On-site Waterproof and Installation Guidance and Service
-
Annealing:
-
All machined acrylic products is annealed to relieve stress
-
Packing:
-
PE Film, EVA, Plywood and Metal Framework
Your Acrylic Panels Solution Provider & Factory
Premium Acrylic for Pool and Aquarium
Find Partner in Pool Builder and Contractor
Pools Swimming Outdoor acrylic panel swimming pool above ground plastic round acrylic swimming pool for sale
Specifcation
|
Product Name
|
Cast Acrylic Sheet
|
|
Thickness
|
40-50-60mm, 80-90-100mm,
120-150-200mm, Max 1000mm
|
|
Size
|
Custom out or bond into any size
Max 3 x 9 meter in stock
|
|
Materials
|
100% purity Acrylic, Piexglass PMMA
|
|
Shape
|
Flat, L-Shape, U-Shape, Curved, Cylinder
|
|
Warranty
|
20 years Quality Guarantee
No yellowing outside
|
|
VST
|
103℃ Vicat Softening Temperature
|
|
Certificate
|
Pass CE, SVHC, US-CA65, CPSIA Test
|
|
Installation
|
On-site Waterproog and installation Guidance and Service
|
Feature
Feature 1 ：A Grade Cast Acrylic Sheet, SGS conducts factory inspections on more than 20 properties of acrylic sheets
Properties Values of Grandview Acrylic Sheet
|
PROPERTIES
|
VALUES
|
RULES
|
|
Rockwell Hardness
|
112L
|
ISO 2039-2:1999
|
|
Tensile Modulus
|
3150MPa
|
EN ISO 527:2012
|
|
Tensile Strength
|
80.0MPa
|
EN ISO 527:2012
|
|
Tensile Strain at Break
|
3.2%
|
EN ISO 527-1:2012
|
|
Water Absorption
|
0.20%
|
ISO 62:2008 Method 1
|
|
Total Luminous Transmittance
|
92.5%
|
ISO 13468-1:1996
|
|
Vicat Softening Temperature
|
103℃
|
ISO 306:2013 Method B50
|
|
Light Ageing Test- UV Exposure
|
Grey scale: 5
|
ISO 4892-3:2016 Cycle 1
|
|
Mean Coefficient of Linear Thermal Expansion
|
72×10-6 K-1
|
ISO 11359-1:2014
|
|
Compressive Stress at Yield
|
129MPa
|
EN ISO 604:2003
|
|
Flexural Strength
|
120MPa
|
ISO 178:2013
|
|
Izod Notched Impact Strength
|
101J/m
|
ASTM D256-10 Method A
|
|
Compressive Yield Strength
|
111MPa
|
ASTM D695-15
|
|
Compressive Modulus
|
3450MPa
|
ASTM D695-15
|
|
Shear Strength
|
59.7MPa
|
ASTM D732-17
|
|
Deflection Temperature under Load
|
100.2℃
|
ASTM D648-18 Method B
|
|
Modulus Elasticity
|
2810MPa
|
ASTM D695-15
|
Feature 2 ：Strong Production Capacity, Huge stock, Fast delivery. Lead time in 7-10 days for normal flat panels.
Acrylic Panel size & thickness in stock
|
L*W mm
|
T mm
|
L*W mm
|
T mm
|
L*W mm
|
T mm
|
L*W mm
|
T mm
|
|
1300*2500
|
20-70
|
1650*3150
|
20-100
|
5000*1800
|
30-150
|
8200*3000
|
80-250
|
|
1350*2650
|
20-100
|
3200*2200
|
20-110
|
5500*2100
|
30-150
|
8700*3000
|
80-250
|
|
1450*2700
|
20-100
|
3500*1650
|
20-110
|
6200*3000
|
50-250
|
9150*3000
|
100-250
|
|
1600*2600
|
20-100
|
4250*2750
|
30-110
|
6700*3000
|
50-250
|
8100*3700
|
120-300
|
Feature 3: 3D Drawing and FEA Report
3D drawings intuitively express the structure and effect of acrylic sheets in the project before completion
Finite element analysis (FEA) Report showing predicted loading and deflections
Feature 4 : Installation Guide
Install by yourself, we have Installation Guide
We give full support for you of self-installation. Including the structure and size of the rabbet, pre-install inspection, waterproof, acrylic panel use attention and maintenance.
ShopDrawing for installation guide
Install by Grandview team, installation on site
Our company
Production line
Case studies and reviews
Project:
Acrylic swimming for Homestay in China
Main Products:
200mm Acrylic Side Panel
Local :
Zhejiang China
Project:
Acrylic Sky Pool
Main Products:
250mm Acrylic 4 sides pool
Local : Da Nang Vietnam
Local : Da Nang Vietnam
Project:
Water Pool in Villa
Main Products:
100mm Acrylic Floor
Local :
Oman
Project:
Acrylic Swimming Pool For Uni
Main Products:
80mm Acrylic Panel and Floor Panel
Local : Tbilisi Georgia
Local : Tbilisi Georgia
Exhibition
Certificate
We have established a comprehensive quality control system according to ISO 9001:2000
standards.We have obtained ROHS, CE certification, and follow the international
standard quality system, and strictly check each process.
FAQ
Handy hints and FAQs
The following information may prove useful when it comes time to get a quotation. Feel free to send us email if you need help gathering the information needed to obtain a quotation.
1. What is the viewing area and how do I measure it?
The “viewing area” is the part of the acrylic panel that can be seen. The panel is bigger than the viewing area, because some of the acrylic is goes into the rebates around the outside of the windows.
2. How do I measure the depth of water to the bottom of the viewing area?
To specify an appropriate panel for your pool, we’ll need to know the depth of water it is in.
Measure from the water surface to the lowest point of the panel.
Measure from the water surface to the lowest point of the panel.
3. How do I measure the distance from the waterline to the top of the viewing area?
The top of the viewing area is above the water in some cases, and below the water in other cases.
For “dry-edge” panels, with the top of the panel above the waterline, simply measure from the waterline to the top of the panel.
For “dry-edge” panels, with the top of the panel above the waterline, simply measure from the waterline to the top of the panel.
