Quick Details
-
Output Power:
-
7kW/9.6kW/11kW
-
Input Voltage:
-
200 - 240V
-
OCPP:
-
OCPP 1.6J/OCPP 2.0.1
-
Current:
-
32A; 40A; 50A
-
Function:
-
screen display, Voltage Monitoring, leakage protection,
-
Network:
-
Ethernet, Wifi, 4G(optional)
-
Application:
-
Home Use/Commercial Use
-
Efficiency:
-
≥94%
-
Protection level:
-
Type 3R
-
Warranty:
-
2 years
-
Color:
-
Black
-
Certificate:
-
IEC; CE; ISO;
Quick Details
-
Place of Origin:
-
Fujian, China
-
Model Number:
-
IOCAH10
-
Brand Name:
-
IoCharger
-
Output Power:
-
7kW/9.6kW/11kW
-
Input Voltage:
-
200 - 240V
-
OCPP:
-
OCPP 1.6J/OCPP 2.0.1
-
Current:
-
32A; 40A; 50A
-
Function:
-
screen display, Voltage Monitoring, leakage protection,
-
Network:
-
Ethernet, Wifi, 4G(optional)
-
Application:
-
Home Use/Commercial Use
-
Efficiency:
-
≥94%
-
Protection level:
-
Type 3R
-
Warranty:
-
2 years
-
Color:
-
Black
-
Certificate:
-
IEC; CE; ISO;
Product Advantages
Products Description
Specification
|
Model
|
IOCAH10-32 / IOCAH10-40/ IOCAH10-50
|
IOCAH10-22S / IOCAH10-22T
|
|
|
Application
|
Residental / Commercial
|
|
|
|
Voltage and Wiring
|
Single Phase 200-240V
|
Three Phase 400V
|
|
|
Frequency (Hz)
|
50/60Hz
|
|
|
|
Current Output
|
Single Phase 32A 40A 50A Max
|
Three Phase 32A Max
|
|
|
Charging Connector
|
SAE J1772 Type-1
|
|
|
|
RCD
|
30mA AC & 6mA DC
|
|
|
|
Electrical Protection
|
Over current, Under voltage,
Over voltage, Over temperature,
Surge protection, Short circuit, Ground fault
|
|
|
|
Button
|
1 x Physical Button
|
|
|
|
Indicators
|
Standby(Blue), Charging(Flashing Blue), Fault(Red), Warning(Flash Red)
|
|
|
|
Network Connectivity
|
Ethernet, WLAN, Celluar
|
|
|
|
RFID
|
ISO 14443 A/B
|
|
|
|
Display
|
2.8' LCD
|
|
|
|
Data Protocol
|
OCPP1.6J, OCPP2.0.1, ISO15118
|
|
|
|
DLB
|
Dynamic Load Balancing
|
|
|
|
Operation Temp.
|
-30 °C ~ 50 °C / -22 °F ~ 122 °F
|
|
|
|
Storage Temp.
|
-40 °C ~ 70 °C / -40 °F ~ 158 °F
|
|
|
|
Working Humidity
|
5%~95% without condensation
|
|
|
|
Mounting Type
|
Wall Mounted (default) / Floor post (optional accessory)
|
|
|
|
Ingress Protection
|
Type 3R
|
|
|
|
Mobile App
|
iOS/Android
|
|
|
|
Certification
|
CE, IEC 61851-1, IEC 62196-2,
UL
|
|
|
