- Product Details
- {{item.text}}
Quick Details
-
Engine Brand:
-
Imported
-
Travel Speed:
-
2.84-9.1 km/h
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
E.P
-
Dimension(L*W*H):
-
1980x930x1580 mm
-
Drum diameter:
-
800 mm
-
Marketing Type:
-
Hot Product 2022
-
Product name:
-
Single Drum Road Roller Compactor
-
Keywords:
-
Mini Double Drum Vibration Roller
-
Vibration frequency:
-
50-70 Hz
-
Drive mode:
-
Variable Plunge Pump
-
Operating weight:
-
1ton
-
Drum Size:
-
500*700mm
-
Vibration:
-
One Key Vibration Electromagnetic Clutch
-
Application:
-
Road Base Compaction
-
Lead Time:
-
7-10 Work Days
Quick Details
-
Type:
-
Vibratory Roller
-
Power:
-
15 KW, 10 kW, 11 KW, 20 kw, 17.2 kw, 18.6 kW, 15.7 kw
-
Weight:
-
1 Ton
-
Engine Brand:
-
Imported
-
Travel Speed:
-
2.84-9.1 km/h
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
E.P
-
Dimension(L*W*H):
-
1980x930x1580 mm
-
Drum diameter:
-
800 mm
-
Marketing Type:
-
Hot Product 2022
-
Product name:
-
Single Drum Road Roller Compactor
-
Keywords:
-
Mini Double Drum Vibration Roller
-
Vibration frequency:
-
50-70 Hz
-
Drive mode:
-
Variable Plunge Pump
-
Operating weight:
-
1ton
-
Drum Size:
-
500*700mm
-
Vibration:
-
One Key Vibration Electromagnetic Clutch
-
Application:
-
Road Base Compaction
-
Lead Time:
-
7-10 Work Days
Products Description
Brief Introduction
Road rollers (sometimes called a road roller, or simply a road roller) are compactor-type construction vehicle used to compact soil, gravel, concrete or asphalt in road and foundation construction. Similar drums are also used in landfills or agriculture.
Road rollers use the weight of the vehicle to compress the surface being rolled (static) or take advantage of mechanical
advantages (vibration). Initial compaction of the base layer for road projects is done using pad feet or "sheep's feet" roller
rollers, which allow for higher compaction densities due to the smaller surface area of the pads.
Road rollers use the weight of the vehicle to compress the surface being rolled (static) or take advantage of mechanical
advantages (vibration). Initial compaction of the base layer for road projects is done using pad feet or "sheep's feet" roller
rollers, which allow for higher compaction densities due to the smaller surface area of the pads.
Product Paramenters
|
Model
|
MYL10A
|
MYL10
|
MYL10B
|
MYL10S
|
|||
|
Engine Model
|
HONGDA GX390
|
KIPOR 186FE
|
CHANGCHAI 186F
|
FUZHOU RD90N-1
|
|||
|
Engine Type
|
4-Strokes Gasoline
|
4-Strokes Diesel
|
|
|
|||
|
|
|
Air Cooled
|
|
Water Cooled
|
|||
|
Power
|
9.7 KW
|
6 KW
|
|
5.88 KW
|
|||
|
RPM
|
3600
|
|
|
2400
|
|||
|
Driving & Brake Mode
|
Variable Plunger Pump
|
|
|
|
|||
|
Weight
|
900 KG
|
920 KG
|
900 KG
|
930 KG
|
|||
|
Static Linear Loads
|
56/77 N/CM
|
57/77 N/CM
|
56/77 N/CM
|
58/77 N/CM
|
|||
|
Working Width
|
825 MM
|
|
|
|
|||
|
Turning Radius
|
2660 MM
|
|
|
|
|||
|
Roller Diameter & Width
|
500x700 MM
|
|
|
|
|||
|
Vibrating Roller
|
Front Roller
|
|
|
|
|||
|
Working Speed
|
0~40 KM/H
|
|
|
|
|||
|
Vibrating Frequency
|
70 HZ
|
|
|
65 HZ
|
|||
|
Vibrating Force
|
20 KN
|
|
|
|
|||
|
Water Spray System
|
Gravity Sprinkler System
|
|
|
|
|||
|
Steering Mode
|
Hydraulic Steering
|
|
|
|
|||
