- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
PEGASUSWINGS
-
Model Number:
-
PG231116
-
Product Name:
-
High Density Foam EPDM/EVA/NEOPRENE/CR Foam for Sealiing
-
Density:
-
90-750kg/M3
-
Thickness:
-
1-52mm
-
Certification:
-
RoHS,REACH,EN71,ISO/TS16949
-
Adhesive Tape/PSA:
-
3M,Tesa,Nitto,Duplocoll
-
Colour:
-
Black,Grey,White,Red,Pink
-
Feature:
-
Eco-friendly,Shockproof,Waterproof,Moistureproof,Elasticity,Waterproof
-
Application:
-
Package,Buffer,Tools,Industry,Transpotation Protection
-
Product Performance:
-
Sealing, thermal insulation, heat resistance, fire prevention
-
Shape:
-
Strip,Slice,Sheet,Piece,Gasket and all kins of profile gasket
Quick Details
-
Material:
-
EPDM Foam
-
Type:
-
Edge Protector
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
PEGASUSWINGS
-
Model Number:
-
PG231116
-
Product Name:
-
High Density Foam EPDM/EVA/NEOPRENE/CR Foam for Sealiing
-
Density:
-
90-750kg/M3
-
Thickness:
-
1-52mm
-
Certification:
-
RoHS,REACH,EN71,ISO/TS16949
-
Adhesive Tape/PSA:
-
3M,Tesa,Nitto,Duplocoll
-
Colour:
-
Black,Grey,White,Red,Pink
-
Feature:
-
Eco-friendly,Shockproof,Waterproof,Moistureproof,Elasticity,Waterproof
-
Application:
-
Package,Buffer,Tools,Industry,Transpotation Protection
-
Product Performance:
-
Sealing, thermal insulation, heat resistance, fire prevention
-
Shape:
-
Strip,Slice,Sheet,Piece,Gasket and all kins of profile gasket
EPDM (Ethylene-Propylene-Diene Monomer), is classified into closed-cell foam and open-cell foam.
| Name | EPDM Foam | Compression Set(%) | <=3 |
| State | Close-cell & Open-cell | Certification | RoHS,SVHC,EN71,ISO/TS16949 |
| Odor | Slight plastic taste | MOQ | It depends |
| Color | Black, White, Grey, Red, Pink | Port | Shanghai or ... |
| Density(Kg/m3) | 90-750 | Useful Life | 7-10years |
| Hardness(Shore C) | 5-65 +/-5 | Product Performance | heat preservation,anti-seismic,anti-static,anti-aging,anti-compression, heat insulation, shockproof, sound absorption, sealing, and flame retardant. |
| Temperature Resistance(Cold Crack to High Intermittent)(C) | -45-200 | ||
| Tensile Strength(Kpa) | >=500 | ||
| Elongation(%) | >=250 | Application | HAVC, air-conditioning, automotive, building, railway, marine industry, construction, instrumentation, electronics, |
| Water Absorption(kn/m) |
<=1
|
EPDM Foam's Characteristic:
For EPDM Closed-cell
- Light and good tear strength
- Low co-efficiency of thermal conductivity
- Hight-Performance of water absorption
- Due to good cushioning, it can be used as shock shock-absorbing materials
- Excellent weather-resistance.EPDM model sponge showed no change under the Ozon Resistance Test(50pphmx38℃,20% expansion for 72hrs)
For EPDM Open-cell
- It is deformed easily by slight force, it recovers slowly when the pressure is released .
- Good tear resistance
- Excellent weather resistance and ozone resistance
- Excellent heat resistance
- Good water sealing property.
