- Product Details
- {{item.text}}
Quick Details
-
Controller:
-
60V Inbol Intelligent Controller
-
input voltage:
-
220V / 110V as your customize
-
Warranty:
-
3 Year
-
Max speed:
-
20-30km/h
-
Brakes:
-
≤5km
-
wheelbace:
-
1680
-
weight:
-
500KG
-
wheel:
-
10/12/14 or customize
Quick Details
-
Tire Size:
-
10/12/14
-
motor:
-
3.5KW AC Motor
-
Battery:
-
60V100A *5
-
Controller:
-
60V Inbol Intelligent Controller
-
input voltage:
-
220V / 110V as your customize
-
Warranty:
-
3 Year
-
Max speed:
-
20-30km/h
-
Brakes:
-
≤5km
-
wheelbace:
-
1680
-
weight:
-
500KG
-
wheel:
-
10/12/14 or customize
Product Paramenters
|
Electrical system
|
|
Electric control
|
|
60V full intelligent electric control
|
|
|
|
|
|
|||||||
|
|
|
Battery
|
|
12V100AH/pc, 5pcs/60V(Maintenance-free battery)
|
|
|
|
|
|
|||||||
|
|
|
Motor
|
|
3.5KW AC motor
|
|
|
|
|
|
|||||||
|
|
|
Charger
|
|
Car smart charger
|
|
|
|
|
|
|||||||
|
|
|
Charge Time
|
|
8--9hours
|
|
|
|
|
|
|||||||
|
|
|
Charging input voltage
|
|
220V
|
|
|
|
|
|
|||||||
|
Technicial Data
|
|
Rated occupant
|
|
6
|
|
|
|
|
|
|||||||
|
|
|
L * w * h
|
|
3900*1200*1850mm
|
|
|
|
|
|
|||||||
|
|
|
Driving Mileage
|
|
70-110km
|
|
|
|
|
|
|||||||
|
|
|
System voltage
|
|
60V
|
|
|
|
|
|
|||||||
|
|
|
Minimum turning radius
|
|
5.6m
|
|
|
|
|
|
|||||||
|
|
|
Climbing Ability
|
|
≥ 20%
|
|
|
|
|
|
|||||||
|
|
|
Braking distance
|
|
≤ 5m
|
|
|
|
|
|
|||||||
|
|
|
Max speed
|
|
30Km/h
|
|
|
|
|
|
|||||||
|
|
|
Power of motor
|
|
3.5KW
|
|
|
|
|
|
|||||||
|
|
|
Curb Weight
|
|
590Kg
|
|
|
|
|
|
|||||||
|
|
|
Wheel base
|
|
3100mm
|
|
|
|
|
|
|||||||
|
|
|
Front Rear Tracks
|
|
900/1000mm
|
|
|
|
|
|
|||||||
|
Body system
|
|
Seat Material
|
|
Joint seat (leather fabric + high rebound PU seat)
|
|
|
|
|
|
|||||||
|
|
|
Car body
|
|
Steel frame + injection molded housing / ABS engineering plastic molding parts
|
|
|
|
|
|
|||||||
|
|
|
Instrument Panel
|
|
Digital display LCD instrument(including voltage, speed, mileage, light, front and rear direction signals)
|
|
|
|
|
|
|||||||
|
|
|
Steering wheel
|
|
Car steering wheel
|
|
|
|
|
|
|||||||
|
|
|
Lights and signals
|
|
LED combination headlight, turn signal, combination taillight, brake lamp, electric horn
|
|
|
|
|
|
|||||||
|
|
|
Switch System
|
|
Start the switch, light, advance and retreat switch
|
|
|
|
|
|
|||||||
|
|
|
Frame
|
|
Steel structure frame
|
|
|
|
|
|
|||||||
|
|
|
Steering wheel
|
|
Polyurethane foam steering wheel
|
|
|
|
|
|
|||||||
|
chassis system
|
|
Power transmission system
|
|
Stepless variable speed system with climbing function
|
|
|
|
|
|
|||||||
|
|
|
Steering system
|
|
Gear and tooth rack-type direction machine
|
|
|
|
|
|
|||||||
|
|
|
Braking System
|
|
Four-wheel drum hydraulic brake, double-circuit hydraulic brake, parking brake device
|
|
|
|
|
|
|||||||
|
|
|
Front bridge and suspension
|
|
The front bridge is semi-floating
|
|
|
|
|
|
|||||||
|
|
|
Rear bridge and suspension
|
|
Overall rear axle + high-strength steel plate spring + cylinder hydraulic shock absorption
|
|
|
|
|
|
|||||||
|
|
|
Tire Details
|
|
205 / 50-10 Vacuum tires
|
|
|
|
|
|
|||||||
Our Advantages
1,Our unique vehicles are not only for the car enthusiast, but are often used in the fields of resorts/campgrounds, golf courses, race tracks, warehouses, marinas, airports, assisted living centers, neighborhoods around town and so much more.
2,Build your car to your specifications and preferences with completely customizable according options including color, seats, wheels and more!
4，Featuring integrated battery power management, your Onward HP will automatically go into sleep mode when unattended to help extend battery charge. Worry less and drive longer as our enhanced technology puts your worries at ease.
5，Our high performance vehicle provides you with impressive torque and acceleration, with smart technology that will assist you in making sure your vehicle is always healthy and ready to drive.
6，Vehicle warranty 3 years, let you buy and use are at ease。
7，Standard LED headlights, turn signals, and running lamps light your drive, make you more visible to traffic, and help to keep the fun going after sundown.
8，Our new tires are smooth and quiet. With a sleeker tread, Our tire is perfect for fragile golf turf and neighborhood roads.Feel the difference in the Onward HP with a quiet AC drivetrain, premium comfort seating, and boosted acceleration. Cruise down any back road or
neighborhood with your favorite tunes playing on our Bluetooth sound system.
