Quick Details
-
Throat Depth (mm):
-
400 mm
-
Width of Working Table (mm):
-
1920 mm
-
Dimension:
-
4250mm*1600mm*3120mm
-
Place of Origin:
-
Hubei, China
-
Brand Name:
-
HGTECH
-
Year:
-
2023
-
Weight (KG):
-
8500
-
Motor Power (kw):
-
22 kw
-
Marketing Type:
-
New Product 2023
-
Product name:
-
Automatic Panel Bender Center Bending 15 Aixs Aluminum Composite Panel
-
Application:
-
Stainless Plate Bending
-
Slider return speed:
-
100
-
Max Nominal Pressure:
-
3000
-
Usage:
-
Metal Sheet Rolling Cutting Bending
-
CNC or not:
-
CNC Bender Machine
-
Color:
-
Red + White
-
Function:
-
Sheet Metal Metal Bending
-
Feature:
-
High Precision
-
Item:
-
Stainless Steel Bending Folding
Quick Details
-
Machine Type:
-
bending machine
-
Length of Working Table (mm):
-
4000
-
Slider Stroke (mm):
-
250 mm
-
Throat Depth (mm):
-
400 mm
-
Width of Working Table (mm):
-
1920 mm
-
Dimension:
-
4250mm*1600mm*3120mm
-
Place of Origin:
-
Hubei, China
-
Brand Name:
-
HGTECH
-
Year:
-
2023
-
Weight (KG):
-
8500
-
Motor Power (kw):
-
22 kw
-
Marketing Type:
-
New Product 2023
-
Product name:
-
Automatic Panel Bender Center Bending 15 Aixs Aluminum Composite Panel
-
Application:
-
Stainless Plate Bending
-
Slider return speed:
-
100
-
Max Nominal Pressure:
-
3000
-
Usage:
-
Metal Sheet Rolling Cutting Bending
-
CNC or not:
-
CNC Bender Machine
-
Color:
-
Red + White
-
Function:
-
Sheet Metal Metal Bending
-
Feature:
-
High Precision
-
Item:
-
Stainless Steel Bending Folding
Automatic Panel Bender Center Bending 15 Aixs Aluminum Composite Panels Bending Machine For Sale
CNC bending machine is an innovative and efficient product that uses advanced technology to provide precise and reliable bending solutions for metal fabrication. Our cnc bending machine product stands out for its high-quality construction, outstanding performance, and easy operation. With CNC technology, this bending machine is capable of handling complex and intricate shapes with precision and accuracy. The machine can also be easily customized to suit diverse applications and production requirements. Its user-friendly interface and intuitive controls make it easy for operators to adjust the bending parameters and achieve the desired results quickly. Overall, CNC bending machine is a reliable and cost-effective solution for metalworking businesses looking to enhance their productivity and profitability.
| No | Configuration | Numerical value | unit | Remark | |
| 1 | Nominal pressure | 1350 | KN | ||
| 2 | Foldable plate width | 3200 | mm | ||
| 3 | Slide stroke | 200 | mm | ||
| 4 | Maximum opening height | 420 | mm | ||
| 5 | Column spacing | 2700 | mm | ||
| 6 | throat depth | 400 | mm | ||
| 7 | Fast down speed | 160 | mm/ s | ||
| 8 | Return speed | 130 | mm/ s | ||
| 9 | Working speed | 10 | mm/ s | ||
| 10 | Main motor power | 11 | Kw | servo motor | |
| 11 | CNC system | DA53T | Netherlands | ||
| 12 | X-axis travel of rear stopper | 500 | mm | ||
| 13 | Number of control axes | 4+ 1 Axis (Y1 ,Y2 ,X ,R+V) | |||
| 14 | Machine tool accuracy | Slider repeat accuracy | ≤±0.01 | mm | |
| 15 | Slide positioning accuracy | ≤±0.02 | mm | ||
| 16 | Workpiece straightness | 0.3 / m | mm | ||
| 17 | Bending angle error | <±30 | ′ | ||
| 18 | Raster scale resolution | 0.005 | mm | ||
| 19 | Rear retaining material | X-axis travel | 500 | mm | |
| 20 | X-axis speed | 200 | mm/s | ||
| 21 | positioning accuracy | ±0.05 | mm | ||
| 22 | Repetitive positioning accuracy | ±0.015 | mm | ||
| 23 | Machine wight | 10 T | T | ||
| 24 | Machine diamentions | L 3500 / W 1580 /H 2500 | mm | ||
CNC bending machines are commonly used in the steel fabrication and metalworking industries. They are particularly useful for producing precision bends in sheet metal, pipes, and tubing. CNC bending machines are essential in industries such as automotive, aerospace, construction, and manufacturing, where precise and efficient metal bending is a critical component of the production process. The advanced computer controls of these machines allow for accurate and consistent bending results, which can help improve overall product quality and reduce manufacturing costs. CNC bending machines are also widely used in the fabrication of household appliances, furniture, and other consumer goods.
Airframe adopt fission steel plate welded structure, the large tempering furnace equipment tempering treatment, eliminate the welding stress and stress caused by variable form, ensure the accuracy of machine tool stability
CNC bending machines are widely used in the metalworking industry for various purposes such as metal fabrication, automotive and aerospace manufacturing, and construction. The machine operates by bending metal sheets and plates into complex shapes and angles with high precision and repeatability. The CNC technology allows for automated programming and control, reducing the need for manual labor and minimizing errors. This product is essential for industries that require high-quality metal components and parts, as it improves productivity, efficiency, and accuracy. CNC bending machines can handle a wide range of materials such as aluminum, steel, titanium, and copper, ensuring versatility and adaptability to different applications. Overall, CNC bending machines play a crucial role in shaping the modern manufacturing industry by enabling cost-effective, reliable, and high-performance metal bending solutions.
