Quick Details
-
Type:
-
2.4 GHz
-
Country of Origin:
-
China
-
Brand:
-
Cansec Wireless
-
size:
-
11.8mm*18mm*2.8mm
-
Support Protocol:
-
BLE5.0 & Mesh
-
Frequency:
-
2.4GHz
-
Power supply:
-
1.8-3.6V
-
Current Draw(TX/RX/Standby):
-
17mA/10mA/3μA
-
TX Power/RX Sensitivity:
-
4.7dBm/-100dBm
-
Operating Temperature:
-
-20 - 70
-
Open Field Range:
-
110M
-
Date Rate:
-
2M
Quick Details
-
Model Number:
-
BLE9187
-
Chipset:
-
ING9187
-
Application:
-
IoT
-
Type:
-
2.4 GHz
-
Country of Origin:
-
China
-
Brand:
-
Cansec Wireless
-
size:
-
11.8mm*18mm*2.8mm
-
Support Protocol:
-
BLE5.0 & Mesh
-
Frequency:
-
2.4GHz
-
Power supply:
-
1.8-3.6V
-
Current Draw(TX/RX/Standby):
-
17mA/10mA/3μA
-
TX Power/RX Sensitivity:
-
4.7dBm/-100dBm
-
Operating Temperature:
-
-20 - 70
-
Open Field Range:
-
110M
-
Date Rate:
-
2M
|
Parameter
|
|
Min
|
Typ
|
Max
|
Unit
|
|||
|
Operating Voltage
|
|
1.8
|
3.3
|
3.6
|
V
|
|||
|
Operating Temperature
|
|
-20
|
-
|
+70
|
℃
|
|||
|
Current
Consumption |
Sleep Mode
|
-
|
3
|
|
uA
|
|||
|
|
Receive mode (MCU active):
|
-
|
10
|
-
|
mA
|
|||
|
|
Transmit Mode(CW)( @ +6.5 dBm ,+3.3V)
|
-
|
17
|
-
|
mA
|
|||
|
TX Power(CW)
|
|
-
|
4.7
|
|
dBm
|
|||
|
RX Sensitivity
|
|
-
|
-100
|
-
|
dBm
|
|||
|
Distance
|
|
110
|
|
|
m
|
|||
1.
ING9187 is a fully integrated Bluetooth
Low Energy SoC
targeting Bluetooth 5.0 specification. It integrates INGCHIPS inhouse BLE5.0 IP including Modem, Link Layer Controller and Host. It also integrates a high performance 32bit RISC MCU, 512KB embedded flash, low power PMU, rich Peripherals, high performance and low power BLE RF transceiver. The Transmitter output power ranges from -28dBm to +6.5dBm, while receiver sensitivity is -102dBm under BLE5 long range mode and -97dBm at 1M mdoe.
2.
ING9187 provides fully open SDK, supports many IDE platforms like Keil, IAR, Segger, supports several program languages like C, C++, Nim,
supports the major operation systems
like Windows, Linux and MacOS, supports graphical project guidline and data editing, and embeds more than 30 open-source software application examples.
3.
ING9187 hardware and software
can be tailored for different user application scenario
, such as extremely low power operation, accurate positioning, industrial interconnection, agricultural interconnection, mesh network, home sensing and so on.
