Quick Details
-
Warranty(Year):
-
1-Year
-
Product Weight（kg）:
-
3
-
Input Voltage(V):
-
AC 100-240V, 50/60Hz
-
Lamp Luminous Flux(lm):
-
5000
-
CRI (Ra>):
-
90
-
Working Temperature(℃):
-
-20 - 45
-
Working Lifetime(Hour):
-
50000
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Wincode Optronics
-
Emitting Color:
-
RGBWA+UV
-
Lithium Battery:
-
Capacity 8800mAH
-
Charger:
-
Voltage and Current 12V 3A
-
Charging Time:
-
5hours
-
2.4G Transceiver:
-
TX Power +23dbm
-
Body Material:
-
Aluminum Die-casting
-
Commnication Distance:
-
-94dbm
-
Optical: Lens Angle:
-
25/35
-
Lens Size:
-
42mm
-
Channel Mode:
-
6CH/8CH
Quick Details
-
Color Temperature(CCT):
-
RGBWA+UV
-
Type:
-
Projection Lights
-
Application:
-
Hotel
-
Warranty(Year):
-
1-Year
-
Product Weight（kg）:
-
3
-
Input Voltage(V):
-
AC 100-240V, 50/60Hz
-
Lamp Luminous Flux(lm):
-
5000
-
CRI (Ra>):
-
90
-
Working Temperature(℃):
-
-20 - 45
-
Working Lifetime(Hour):
-
50000
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Wincode Optronics
-
Emitting Color:
-
RGBWA+UV
-
Lithium Battery:
-
Capacity 8800mAH
-
Charger:
-
Voltage and Current 12V 3A
-
Charging Time:
-
5hours
-
2.4G Transceiver:
-
TX Power +23dbm
-
Body Material:
-
Aluminum Die-casting
-
Commnication Distance:
-
-94dbm
-
Optical: Lens Angle:
-
25/35
-
Lens Size:
-
42mm
-
Channel Mode:
-
6CH/8CH
Product Presentation
|
Protection:
|
Real Time Temperature Monitoring & Over Temperature Protection
|
|
|
|
Other Features:
|
32bit ARM Cotex MCU, Constant Current Drived,
|
|
|
|
Warranty:
|
1-year Limited Warranty
|
|
|
|
Net Weight:
|
2.7Kgs
|
|
|
|
Product Dimension:
|
140x140x200mm
|
|
|
|
Product GW:
|
3.2Kgs
|
|
|
|
caton packing Size:
|
230x220x200mm
|
|
|
|
Packaging Method:
|
Chargeable flight case option
|
|
|
Detailed Images
|
Light Source:
|
4pcs 18W 6in1(RGBAW+UV) LEDs
|
|
|
|
|
6pcs 18W 6in1(RGBAW+UV) LEDs
|
|
|
|
Lithium Battery:
|
Capacity
|
8800mAH
|
|
|
Charger:
|
Voltage and Current
|
12V 3A
|
|
|
|
Charging Time
|
5hours
|
|
|
2.4G Transceiver:
|
TX Power
|
+23dbm
|
|
|
|
Sensitivity:
|
#VALUE!
|
|
|
|
Channel No:
|
June 8th
|
|
|
|
Commnication Distance:
|
-94dbm
|
|
|
Optical:
|
Lens Angle:
|
25/35
|
|
|
|
Lens Size:
|
42mm
|
|
|
Control Singal:
|
Protocol:
|
USITTT DMX-512 / RDM Compatible
|
|
|
|
Channel Mode:
|
6CH/8CH
|
|
|
Operating Modes:
|
Standalone, Master/Slave, Sound Active, DMX-512, RDM
|
|
|
|
Programs:
|
Preset Colors, Auto Chase Effect, Auto Fade Effect, Customs
|
|
|
|
Dimmer Mode:
|
Linear/Exponential/Logarithmic/Hyperbolic
|
|
|
|
PWM Dimming:
|
16bit Dimming with 1000HZ Frequency
|
|
|
|
Body Material:
|
Aluminum Die-casting
|
|
|
|
Cooling Method:
|
Intelligent Cooling System with Heat Sink and Fan Both
|
|
|
Project Case
Our Advantages
What We Can Do For You:
* Support ODM & OEM &RTS
* Appearance Designs: concept design--Sketch--Color--3D Modeling--
Rendering
* Structure Designs: Pro/E--Parts--assembly drawing--PrototypeSoftware Design
* Integrated Circuit Design
* 100% inspection before packing
* 0 complaint in Alibaba order for 15 years
* 15 years' experience in making stage lighting
Company Introduction
Professional Moving Head Light Supplier-Wincode Optronics
Guangzhou Wincode Optronics Co.,Limited is a professional OEM,ODM,OBM manufacturer and exporter which specialized in manufacturing and marketing varietystage lights, PRO Lights,Architectural Lights, Commercial Lights. With much experiencesand strict ISO9001 international standards.
Guangzhou Wincode Optronics Co.,Limited is a professional OEM,ODM,OBM manufacturer and exporter which specialized in manufacturing and marketing varietystage lights, PRO Lights,Architectural Lights, Commercial Lights. With much experiencesand strict ISO9001 international standards.
We are running our own brand
"
WincodeOptronics
" in the global market for lighting. our products are suitable for variousentertainment and recreation place, such as theatre, TV showroom, multimedia hall,square show, organ hall, recreational city, Disco club,Bar, KTV and so on.
