Quick Details
-
Video Input(work in double):
-
HDMI1.4/3G-SDI
-
Audio Input:
-
HDMI Embeded/External 3.5mm
-
Video Codec:
-
H.265/H.264 AVC Base/Main/High
-
Audio Codec:
-
AAC/AAC+/AAC++/MP3/MP2/AC3/G.711A/U
-
Video Output:
-
Up to 2160P30(only in HDMI)
-
Video Bitrate:
-
0.16-40M
-
Audio Bitrate:
-
32-384Kbps
-
Protocol:
-
SRT/RTSP/RTMPs/UDP/UTP
-
Ethernet Port:
-
1000M Full Duplex
-
Power supply:
-
DC 12V 2A
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Unisheen
-
Model Number:
-
BM2700HS
-
Video Input(work in double):
-
HDMI1.4/3G-SDI
-
Audio Input:
-
HDMI Embeded/External 3.5mm
-
Video Codec:
-
H.265/H.264 AVC Base/Main/High
-
Audio Codec:
-
AAC/AAC+/AAC++/MP3/MP2/AC3/G.711A/U
-
Video Output:
-
Up to 2160P30(only in HDMI)
-
Video Bitrate:
-
0.16-40M
-
Audio Bitrate:
-
32-384Kbps
-
Protocol:
-
SRT/RTSP/RTMPs/UDP/UTP
-
Ethernet Port:
-
1000M Full Duplex
-
Power supply:
-
DC 12V 2A
Product Description
| Video | |
| Input/Output(LOOP) | 1x HDMI( 1.4) HDCP (2160p30)/1x3G-SDI(1080p60) |
| Resolution(SDI only up to 1080P60) | 2160P30,1920x1080@60P/50p,1920x1080@60i/50i/1280x720@60p/50p 720x576i/720x480i |
| Encoding | H.265 HEVC/H.264/AVC Baseline/Main/High Profile Level 4.2 |
| HDMI/SDI Input | Working in Double |
| Data Rate | 0.16Mbps~32Mbps |
| Rate Control | CBR/VBR/Strong CBR |
| GOP | 5-300 |
| Advanced Pretreatment | De-interlacing, Image Enhancement,Noise Reduction, Sharpening |
| Latency Time | 100ms |
| OSD | 4xImage or TXT or 1xscroll txt |
| Audio | |
| Input | 1xHDMI Embeded/1xSDI Embeded/1x3.5mm |
| Encoding | AAC/AAC+/AAC++/MP3/MP2/AC3/G.711A/G.711U |
| Sampling rate | 44100/48000 Hz |
| Bit-rate | 32K/48K/64K/96K/128K/160K/192K/384K |
| Sampling precision | 24 bit |
| System | |
| Ethernet | 1x1000 Base-T Ethernet interface |
| Protocol | UTP SRT HTTP RTSP RTMP(s) HLS FLV UDP RTP unicast/multicast Onvif |
| control interface | WEB Manager or CGI command |
| NTP | Support |
| Schedule to Restart | Support |
| General | |
| Rack Dimension (W×L×H) | 165x120x39mm |
| Net/Gross Weight | 0.5/1.0kg |
| Temperature | 0-45(work),-20-80(storage) |
| Power | 12V DC 2A |
| Consumption | 8W |
