Quick Details
-
After-sales Service Provided:
-
Online support
-
Place of Origin:
-
Taiwan, China
-
Brand Name:
-
SHYUAN YA
-
Model Number:
-
A12C38T-IU
-
Voltage:
-
115, 230V
-
Air Flow:
-
85 ~ 97 CFM
-
Housing:
-
Die-Cast Aluminum
-
Impeller:
-
Thermoplastic PBT, UL94V-0
-
Motor:
-
Shaded-Pole Motor
-
Bearing:
-
Ball or Sleeve
-
Termination:
-
Terminals or Lead Wire
-
Insulation:
-
Class "B" or "F"
-
Safety:
-
Impedance Protected
-
Operating Temperature:
-
-10°C to + 80°C
Quick Details
-
Applicable Industries:
-
Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Home Use, Retail
-
Electric Current Type:
-
AC
-
Mounting:
-
Wall Fan
-
After-sales Service Provided:
-
Online support
-
Place of Origin:
-
Taiwan, China
-
Brand Name:
-
SHYUAN YA
-
Model Number:
-
A12C38T-IU
-
Voltage:
-
115, 230V
-
Air Flow:
-
85 ~ 97 CFM
-
Housing:
-
Die-Cast Aluminum
-
Impeller:
-
Thermoplastic PBT, UL94V-0
-
Motor:
-
Shaded-Pole Motor
-
Bearing:
-
Ball or Sleeve
-
Termination:
-
Terminals or Lead Wire
-
Insulation:
-
Class "B" or "F"
-
Safety:
-
Impedance Protected
-
Operating Temperature:
-
-10°C to + 80°C
|
Specification
|
|
|
|
Air Flow
|
103 ~ 117 CFM
|
|
|
Housing
|
Die-Cast Aluminum
|
|
|
Impeller
|
Thermoplastic PBT, UL94V-0
|
|
|
Motor
|
Shaded-Pole Motor
|
|
|
Bearing
|
Ball or Sleeve
|
|
|
Termination
|
Terminals or Lead Wire
|
|
|
Insulation
|
Class “B” or “F”
|
|
|
Safety
|
Impedance Protected
|
|
|
Operating Temperature
|
-10°C to + 80°C
|
|
|
Certification
|
ce, RoHS, CUL, UL
|
|
Related Products
|
Product Name
|
|||||
|
Air Flow
|
18 ~ 22 CFM
|
26 ~ 31 CFM
|
30 ~ 36 CFM
|
||
|
Housing
|
Die-Cast Aluminum, Painted Black
|
|
|
||
|
Impeller
|
Thermoplastic PBT, UL94V-0
|
|
|
||
|
Motor
|
Shaded-Pole Motor
|
|
|
||
|
Insulation
|
Class “B” or “F”
|
|
|
||
|
Operating Voltage Range
|
85VAC to 125VAC for 115V Type / 185VAC to 245VAC for 230V Type
|
|
|
||
|
Operating Temperature
|
-10°C to +70°C for Sleeve Type / -20°C to +80°C for Ball Type
|
|
|
||
|
Product Name
|
|||||
|
Air Flow
|
42~49 CFM
|
61 ~ 72 CFM
|
103 ~ 117 CFM
|
||
|
Housing
|
Die-Cast Aluminum, Painted Black
|
|
|
||
|
Impeller
|
Thermoplastic PBT, UL94V-0
|
|
|
||
|
Motor
|
Shaded-Pole Motor
|
|
|
||
|
Insulation
|
Class “B” or “F”
|
|
|
||
|
Operating Voltage Range
|
85VAC to 125VAC for 115V Type / 185VAC to 245VAC for 230V Type
|
|
|
||
|
Operating Temperature
|
-10°C to +70°C for Sleeve Type / -20°C to +80°C for Ball Type
|
|
|
||
|
Product Name
|
|||||
|
Air Flow
|
107 ~ 123 CFM
|
198 ~ 229 CFM
|
178 ~230 CFM
|
||
|
Housing
|
Die-Cast Aluminum, Painted Black
|
|
|
||
|
Impeller
|
Thermoplastic PBT, UL94V-0
|
|
|
||
|
Motor
|
Shaded-Pole Motor
|
Capacitor Start Motor
|
Capacitor Start Motor / Shaded-Pole Motor
|
||
|
Insulation
|
Class “B” or “F”
|
|
|
||
|
Operating Voltage Range
|
85VAC to 125VAC for 115V Type / 185VAC to 245VAC for 230V Type
|
|
|
||
|
Operating Temperature
|
-10°C to +70°C for Sleeve Type / -20°C to +80°C for Ball Type
|
-20°C to + 90°C
|
-20°C to + 80°C
|
||
|
Product Name
|
|||||
|
Air Flow
|
261 ~ 307 CFM
|
342 ~ 394 CFM
|
100 ~ 225 CFM
|
||
|
Housing
|
Die-Cast Aluminum, Painted Black
|
|
|
||
|
Impeller
|
Injection Molded of Flame Retardant Polycarbonate, Black
|
Thermoplastic PBT, UL94V-0
|
Thermoplastic PBT, UL94V-0
|
||
|
Motor
|
Capacitor Start Motor
|
|
|
||
|
Insulation
|
Class “B” or “F”
|
|
|
||
|
Operating Voltage Range
|
85VAC to 125VAC for 115V Type / 185VAC to 245VAC for 230V Type
|
|
|
||
|
Operating Temperature
|
-20°C to + 80°C
|
|
|
||
|
Product Name
|
|||
|
Air Flow
|
376 ~ 434 CFM
|
443 ~ 529 CFM
|
|
|
Housing
|
Die-Cast Aluminum, Painted Black
|
|
|
|
Impeller
|
Injection Molded of Flame Retardant Polycarbonate, Black
|
Thermoplastic PBT, UL94V-0
|
|
|
Motor
|
Capacitor Start Motor
|
|
|
|
Insulation
|
Class “B” or “F”
|
|
|
|
Operating Voltage Range
|
85VAC to 125VAC for 115V Type / 185VAC to 245VAC for 230V Type
|
|
|
|
Operating Temperature
|
-20°C to + 80°C
|
-30°C to + 80°C
|
|
Questions & Answers
Q: What information do you need to provide in order to get a quotation?
A: Generally, information about Size,Air Flow,Voltage of required fans
is needed in order to select a right fan for you and provide you a quotation.
Q: Can I have samples for testing before ordering products?
A: Yes, we sincerely suggest that customers should have some samples
of required fans for testing because the truly performance of fans can be
fully demonstrated after testing is conducted.
Q: Can I have a discount for the quoted price?
A: The quoted price is based on annual usage quantity. If annual usage
quantities increase, please provide the information to our sales.
We will provide you a further discount.
Q: What is the warranty of products?
A: All of our products have 1 year warranty. Every product has its own
production code. This code is able to track the production time.
Q: Could you print our company LOGO on the nameplate and package?
A: Yes, we accept OEM orders.
