Quick Details
-
Color:
-
full color
-
Panel Size:
-
960*960mm, 960*960mm
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
QC--960-T8
-
Brightness:
-
≥6000, ≥6000, ≥6000nits
-
Lifespan (hours):
-
100000 hrs, 100000 hrs
-
IP Rating:
-
IP65, IP65
-
HS Code:
-
8528591090
-
View Angle（H/V）:
-
160/140, 160/140
-
Certificate:
-
CE ROHS FCC
-
Warranty:
-
2 Years
-
Cabinet material:
-
Iron
-
Installation:
-
Stacking, hanging
-
Cabinet size:
-
960*960*135mm
-
IP rate:
-
IP65
-
Input Voltage:
-
AC100~240V 50 /60 HZ
-
Scan mode:
-
1/5
-
Keyword:
-
LED Display Screen Panels
Quick Details
-
Application:
-
Indoor, Outdoor
-
Type:
-
LED
-
Brand Name:
-
ABXLED
-
Color:
-
full color
-
Panel Size:
-
960*960mm, 960*960mm
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
QC--960-T8
-
Brightness:
-
≥6000, ≥6000, ≥6000nits
-
Lifespan (hours):
-
100000 hrs, 100000 hrs
-
IP Rating:
-
IP65, IP65
-
HS Code:
-
8528591090
-
View Angle（H/V）:
-
160/140, 160/140
-
Certificate:
-
CE ROHS FCC
-
Warranty:
-
2 Years
-
Cabinet material:
-
Iron
-
Installation:
-
Stacking, hanging
-
Cabinet size:
-
960*960*135mm
-
IP rate:
-
IP65
-
Input Voltage:
-
AC100~240V 50 /60 HZ
-
Scan mode:
-
1/5
-
Keyword:
-
LED Display Screen Panels
Product Paramenters
|
ITEM
|
UNIT
|
ABX96A-P3.076
|
ABX960A-P4
|
ABX960A-P5
|
ABX960A-P6.667
|
ABX960A-P8
|
ABX960A-P10
|
|||||
|
Pixel Pitch
|
mm
|
3.076
|
4
|
5
|
6.667
|
8
|
10
|
|||||
|
Pixel Matrix Per
|
Pixel/
sqm
|
105625
|
62500
|
40000
|
22500
|
15625
|
10000
|
|||||
|
Module Pixel structure
|
N/A
|
SMD1921
|
SMD1921
|
SMD1921
|
SMD3535
|
SMD3535
|
SMD3535
|
|||||
|
Brightness
|
nits
|
4500-5500Nits
|
4500-5500Nits
|
4500-5500Nits
|
5000-6000Nits
|
4500-6000Nits
|
4500-7200Nits
|
|||||
|
Scan
|
N/A
|
1/13
|
1/13
|
1/10
|
1/6
|
1/5
|
1/4,1/2
|
|||||
|
Cabinet Resolution
|
Pixel
|
240×240
|
192×192
|
160×160
|
144x144
|
120x120
|
96x96
|
|||||
|
Power Con. (Max / Avg)
|
W/sqm
|
600/180
|
600/180
|
600/180
|
600/180
|
600/180
|
600/180
|
|||||
|
Module Dimension
|
mm
|
320x160
|
320x160
|
192x192
|
320x160
|
320x160
|
320x160
|
|||||
|
Cabinet Dimension
|
mm
|
960x960
x138
|
960x960
x138
|
960x960
x138
|
960x960
x138
|
960x960
x138
|
960x960
x138
|
|||||
|
Cabinet Weight
|
kg
|
33kg
|
33kg
|
33kg
|
33kg
|
33kg
|
33kg
|
|||||
|
Service Access
|
N/A
|
Rear
|
Rear
|
Rear
|
Rear
|
Rear
|
Rear
|
|||||
|
View angle
|
℃
|
160°/ 140°
|
160°/ 140°
|
160°/ 140°
|
160°/ 140°
|
160°/ 140°
|
160°/ 140°
|
|||||
|
Refresh Rate
|
Hz
|
1920/3840/7680
|
1920/3840/7680
|
1920/3840/7680
|
1920/3840/7680
|
1920/3840
/7680
|
1920/3840
/7680
|
|||||
|
Grey Scale (bit)
|
bit
|
16
|
16
|
16
|
16
|
16
|
16
|
|||||
|
IP Rate
|
IP
|
IP65
|
IP65
|
IP65
|
IP65
|
IP65
|
IP65
|
|||||
|
Life span
|
hrs
|
100000 hrs
|
100000hrs
|
100000hrs
|
100000 hrs
|
100000 hrs
|
100000 hrs
|
|||||
|
Working Temperature
|
℃
|
-30-60 ℃
|
|
|
|
|
|
|||||
|
Storage Temperature
|
℃
|
-30-60 ℃
|
|
|
|
|
|
|||||
|
Power Supply
|
V
|
AC100-240V(50-60Hz)
|
|
|
|
|
|
|||||
|
Color temperature
|
N/A
|
3000-10000 K(adjustable)
|
|
|
|
|
|
|||||
