- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
China
-
Dimension(Long * Breadth * High):
-
2800*1000*1230mm
-
Machine Weight:
-
500 kg
-
Marketing Type:
-
New Product 2024
-
Warranty of core components:
-
15 months
-
Product name:
-
electric dumper tricycle
-
Speed:
-
45km
-
Box size:
-
1450*900*400 mm
-
Working time:
-
10-12h
-
Driving motor:
-
2500W(Brushless motor)
-
LIfting motor:
-
1000W
-
Net weight:
-
500kg
-
Loading capacity:
-
1000kg
-
Mining tires:
-
4.00/12 ,5.00-14
-
Driving type:
-
Customized
Quick Details
-
Engine Brand:
-
LIANKE
-
Power:
-
2.5KW
-
Brand Name:
-
Lianke
-
Place of Origin:
-
China
-
Dimension(Long * Breadth * High):
-
2800*1000*1230mm
-
Machine Weight:
-
500 kg
-
Marketing Type:
-
New Product 2024
-
Warranty of core components:
-
15 months
-
Product name:
-
electric dumper tricycle
-
Speed:
-
45km
-
Box size:
-
1450*900*400 mm
-
Working time:
-
10-12h
-
Driving motor:
-
2500W(Brushless motor)
-
LIfting motor:
-
1000W
-
Net weight:
-
500kg
-
Loading capacity:
-
1000kg
-
Mining tires:
-
4.00/12 ,5.00-14
-
Driving type:
-
Customized
Product Descriptions
LK135
Hot Selling 1.5Ton Electric Mini Dumper Accept Customized
Electric wheel loader
is one of our main products, using electric as power source in mining, sanitation and cleaning. It is also widely used in mine, concentrator, quarries, refractory factory, flour mill, brick factory, furnace charge factory, forest, farm and so on.
(There is a difference between the product price and the main image product price.For the final quotation,please send an inquiry or click on the TM on the right for consultation.You can also find my Whatsapp consultation at the end of the article.)
Delivery & Feedback
FCL DELIVERY
For the order quantities more than 8 units, normally we advise to adopt full container load, full container shipment without any demolition, it‘s more convenient transportation and cost savings.
One 20GP can hold 8 to 12 sets. One 40HC can hold 16 to 24 sets.
Feedback
We have our
sample base and after-sales service point in Peru
to solve after-sales problems for customers and provide necessary accessories.
Now we have exported to Peru, Chile, Bolivia, Ecuador, Africa, Europe, United states, and North American.
Factory Show
The frame and hopper are completely developed and produced independently by us,
supporting various modifications and customization.
The frame and hopper are both shot blasted and polished, and we have our own spray paint production line.
|
Model
|
LK200
|
LK270
|
LK135
|
|||
|
Loading capacity
|
2000kg
|
2500kg
|
1500kg
|
|||
|
Front tire
|
4.50-14 (Huanyan tire)
|
4.50-14 (Huanyan tire)
|
4.00-12 (Huanyan tire)
|
|||
|
Rear tire
|
6.00-16 (Huanyan tire)
|
6.00-16 (Huanyan tire)
|
5.00-14 (Huanyan tire)
|
|||
|
Dimension(L*W*H)
(can be customized)
|
3300*1100*1350mm
|
3300*1150*1400mm
|
2800*1000*1250mm
|
|||
|
Cargo box size (L*W*H)
(can be customized)
|
1800*1100*450mm
|
1800*1150*500mm
|
1450*900*400mm
|
|||
|
Driving motor power
(can be customized)
|
3000W/60V
|
4000W/72V
|
2000W/48V
|
|||
|
Driving motor type
|
Brushed motor
|
Brushless motor
|
Brushed motor
|
|||
|
Lifting motor power
|
1000W-1300W
|
|
|
|||
|
Lifting motor type
|
Brushed motor
|
|
|
|||
|
Thickness of Cargo box
(can be customized)
|
5mm,6mm,8mm
|
|
3mm,5mm,6mm,8mm
|
|||
|
The quotation is for reference, and the actual price is subject to the specific configuration of the order.
|
|
|
|
|||
Product operation video
Customized item
1.UPRIGHTS FOR HOPPER AND COLOR
1.Color can be customized.
2.The standard numbers of the upright for
LK135 hopper is one
, but if you want add one upright, we can produce for you,
and it is free.
2.FRONT SHOCK ABSORPTION TYPE
1.Old version shock absorber(No longer used, f
ree upgrade to the second option）
2.New version Single row bigger type front shock absorber
(LK135 standard configuration)
3.Double row front shock absorber(Customization with additional payment)
3.Double row front shock absorber(Customization with additional payment)
3.SEAT
Standard configuration is a regular seat (right image),can be customized luxury seat (left image)
4.HINGE OF SIDE BOX PLATE
The hinge can be opened during manual loading,
reducing the height of the cargo box and saving manpower.
