Quick Details
-
2.4G Wi-Fi Transmission Rate:
-
300 Mbps
-
Type:
-
Wireless
-
Brand Name:
-
KuWFi
-
Place of Origin:
-
guangdong,china
-
Antenna:
-
7dBi Antennas
-
SIM card slot:
-
1 SIM Card Support
-
Wireless Speed:
-
150Mbps Download
-
User:
-
64 user
-
wifi Distance:
-
5-50m
-
Power supply:
-
24v (POE Supply)
-
RJ45:
-
1*LAN/WDS
-
Outdoor Protection Level:
-
IP67
-
feature:
-
EU/USA/AS band
-
Warranty:
-
2 Years
Quick Details
-
Max. LAN Data Rate:
-
100Mbps
-
With Modem Function:
-
Yes
-
Wi-Fi Supported Frequency:
-
4G
-
2.4G Wi-Fi Transmission Rate:
-
300 Mbps
-
Type:
-
Wireless
-
Brand Name:
-
KuWFi
-
Place of Origin:
-
guangdong,china
-
Antenna:
-
7dBi Antennas
-
SIM card slot:
-
1 SIM Card Support
-
Wireless Speed:
-
150Mbps Download
-
User:
-
64 user
-
wifi Distance:
-
5-50m
-
Power supply:
-
24v (POE Supply)
-
RJ45:
-
1*LAN/WDS
-
Outdoor Protection Level:
-
IP67
-
feature:
-
EU/USA/AS band
-
Warranty:
-
2 Years
Specification
|
|
CPF909
|
QC300K
|
|
Chipset
|
MT7628
|
MTK7628KN
|
|
Network Type
|
4G:LTE-TDD /FDD 3G ：WCDMA
|
4G:LTE-TDD /FDD 3G ：WCDMA
|
|
Port
|
1*WAN/LAN;
|
1*WAN;
1*LAN |
|
4G/5G transmission Rate
|
Up to 150M DL and 50M bps UL
|
Up to 150M DL and 50M bps UL
|
|
Standard
|
IEEE 802.11b/g/n
|
IEEE 802.11b/g/n
|
|
Frequency
|
2.4GHZ
|
2.4GHz
|
|
Wireless data rate
|
300Mbps
|
300Mbps
|
|
Interface
|
SIM Card Slot*1;
POE adapter Supply; |
SIM Card Slot*1;
DC port POE adapter Supply |
|
PoE Power
|
24V POE
|
24V 0.5A POE
|
|
Basic Feature
|
1.2.4G internal 5dBi x 1, 4G external 5dBi x 1
2. Max 64users 3. support VPN optional 4. IP65 waterproof 5. Watchdog
6. 4G to LAN
7. PPPoE work mode
|
1.build inantenna
2. Max 32users 3. support POE 4. IP65 waterproof
5. 4G to LAN
6. PPPoE work mode
|
|
Accessory
|
1x Outdoor 4G LTE Router;
2x Antenna; 1x 24V/0.5A POE Power Adapter; 1x RJ45 Cable; 1x User Manual; |
1*4G WIFI Router;
1*24V POE Adapter; 1*English Manual; 1*RJ45 lan Cable; 1*Fixing Ring; |
Feature:
1. KuWFi CPF909 is 2.4G 300Mbps Outdoor 4G LTE Router, With 1*WAN/LAN port.
2. With built-in 4G modem and SIM slot.
3. Support IP67 waterproof, can connetct 64 device at the same.
4. 4* 5dBi high-gain antennas to provide wide Wi-Fi Coverage.
5. widely used in outdoor, such as ip camera.
About version:
Can support the United States, Latin American. Europe, the Middle East, Asia, Africa frequency band!!
EU Band:
B1/B3/B7/B8/B20/B28(/B5)@FDD-LTE;
B38/B39/B40/B41@TDD-LTE;
B1/B5/B8@WCDMA;
US Band:
B2/B4/B5/B12/B13/B14/B66/B71@FDD-LTE;
UMTS/HSDPA/HSPA+ B2/B4/B5
Latin American band:
B1 B2 B3 B4 B5 B7 B8 B28 B40 B66
if you have any question about frequency band, please click here!!
Can support the United States, Latin American. Europe, the Middle East, Asia, Africa frequency band!!
EU Band:
B1/B3/B7/B8/B20/B28(/B5)@FDD-LTE;
B38/B39/B40/B41@TDD-LTE;
B1/B5/B8@WCDMA;
US Band:
B2/B4/B5/B12/B13/B14/B66/B71@FDD-LTE;
UMTS/HSDPA/HSPA+ B2/B4/B5
Latin American band:
B1 B2 B3 B4 B5 B7 B8 B28 B40 B66
if you have any question about frequency band, please click here!!
Product Description
Real Picture
