High Quality Isobaric Stable Soda Bottling Machine Soda Water Filling Making Machine
High Quality Isobaric Stable Soda Bottling Machine Soda Water Filling Making Machine
High Quality Isobaric Stable Soda Bottling Machine Soda Water Filling Making Machine
High Quality Isobaric Stable Soda Bottling Machine Soda Water Filling Making Machine
High Quality Isobaric Stable Soda Bottling Machine Soda Water Filling Making Machine
High Quality Isobaric Stable Soda Bottling Machine Soda Water Filling Making Machine
High Quality Isobaric Stable Soda Bottling Machine Soda Water Filling Making Machine
High Quality Isobaric Stable Soda Bottling Machine Soda Water Filling Making Machine

High Quality Isobaric Stable Soda Bottling Machine Soda Water Filling Making Machine

FOB Reference Price: Get Latest Price
≥1 Pieces
US $66000
Free Inquiry
Customized Request
  • Product Details
  • {{item.text}}

Quick Details

Filling Accuracy:
5mm
Voltage:
380V
Place of Origin:
Jiangsu, China
Brand Name:
EQS
Dimension(L*W*H):
4050*2385*2850mm
Weight:
8000 KG
Washing heads:
32
Filling heads:
32
Capping heads:
10
Available bottle height:
180-310mm
Available bottle diameter:
50-90mm
CO2 Consumption:
18g/100L
Capacity:
8000-9000BPH
Filling range:
Soda Water, Soda drinks
Marketing Type:
Ordinary Product
After-sales Service Provided:
Service Machinery Overseas

Quick Details

Machinery Capacity:
8000BPH
Packaging Material:
Glass
Filling Material:
Carbonated Drinks
Filling Accuracy:
5mm
Voltage:
380V
Place of Origin:
Jiangsu, China
Brand Name:
EQS
Dimension(L*W*H):
4050*2385*2850mm
Weight:
8000 KG
Washing heads:
32
Filling heads:
32
Capping heads:
10
Available bottle height:
180-310mm
Available bottle diameter:
50-90mm
CO2 Consumption:
18g/100L
Capacity:
8000-9000BPH
Filling range:
Soda Water, Soda drinks
Marketing Type:
Ordinary Product
After-sales Service Provided:
Service Machinery Overseas
Product Description

High Quality Isobaric Stable Soda Bottling Machine Soda Water Filling Making Machine
Click here to get more information

Product Application
The DCGF Series is for the soda water making machine . It realizes the rinsing bottle, filling bottle and
capping in a unit machine with complete automation. The carbonated drinks soda water making machine is designed and manufactured by Italian technology, and the capping machine is adopted with the most advanced French "ZALKIN " capping machine technology, and improved by our domestic famous university’s professor and engineers together. The main machine adopts the advanced PLC control, and the key electrical elements are with abroad famous brand. Such as: SIEMENS, SCHNEDIER, MITSUBISHI, OMRON, AUTONICS, ...
1. This can realize automatic washing and filling and capping function in united machine.
2. The bottle type is for glass bottle and aluminum screw cap. And available bottle volume can be 200ml, 330ml, 500ml, 750ml,... It can be several kinds of bottle size to share- use a same filling machine via change parts. Please keep the same diameter of bottle mouths.
3. Its rated capacity is 8000-9000BPH for 500ml.

Rinsing Part of Soda Water Making Machine

The washing pipe is stainless steel washing pipe with long term using life.

Filling Part of Soda Water Making Machine

The filling method is the isobaric type with stable running performance.

Capping Part of Soda Water Making Machine

It's for aluminium screw cap, the capping part will be customized according to client's cap samples.
More Production Capacity of Soda Water Making Machine for Choice
Technical Parameters
Model
DCGF14-12-4
DCGF18-18-6
DCGF24-24-8
DCGF32-32-10
DCGF40-40-12
Rinsing Heads
14
18
24
32
40
Filling Heads
12
18
24
32
40
Capping Heads
4
6
8
10
12
Capacity(BPH)
2500
4000
6000
9000
14000
Bottle Size
Bottle Height: 180-310mm; Bottle Diameter: 50-90mm;
18G/100L
18G/100L
18G/100L
18G/100L
CO 2 Consumption
18G/100L
18G/100L
18G/100L
18G/100L
18G/100L
Hopper Motor(KW)
0.18
0.37
0.37
0.37
0.75
Blowing(M 3 /H)
0.3
0.3
0.6
0.6
0.6
Main Motor(kw)
2.2
3.0
4.0
5.0
6.0
Dimension(mm)
2000*1740*2750
2360*1880*2750
2760*2280*2750
4050*2385*2850
4030*3100*2850
Weight(KG)
2500
3500
5000
7000
9500
Other Equipment of Complete Soda Water Making Machine Filling Line For Reference

RO Water Treatment System


Carbonation Machine


Bottle Warmer Tunnel


Bottle Dryer


Inkjet Printer


Laser Printer


Self-adhesive Labeling Machine


Conveyor


Carton Packing Machine


More Details Of Material

* High level humanized customization service to customize the most suitable products and services for you individually according to your specific needs, budget and actual situation.
* Through more than ten years of experience in mechanical production and investigation of customer feedback, we constantly improve products, improve product details and improve machine quality in the spirit of ingenuity. Each unique design is designed to ensure the best user experience for customers.
* Absolute real material and unique design greatly increase the service life of the machine, ensure the stable output of the machine and long-term efficient working ability.
Turnkey Project
About us

1.Factory

Our company is a public company in China with over 15 subsidiaries.And we are famous in the field of dairy, dairy, beverage,condiment, wine, daily chemicals. And we focus on providing the global customer with complete sets of intelligent equipment and turnkey solutions such as water treatment, pre-allocation, bottle blowing, filling, secondary packaging, robotic palletizing, intelligent equipment workshops, etc.
Cooperation Partner
Our equipment has been exported to abroad and domestic market. Such as Mengniu, MasterKong, Nongfu Spring, PANPAN, CoCa Cola, Yili, Comfort, Pepsi, Robust, Sanyuan, Tsingtao Beer, SnowBeer, RedBull, Jianlibao,C’setbon, Nestle Waters, Lotte, Malee, Safeguard, Kinsell, Perrier, Evian, Wahaha, New Hope, Hengshun,... who are all our cooperated partners.

Production & Processing

We have a strong technology technology resources development and production team, which has two lead engineers with twenty years of experience, fifteen senior electrical engineers, ten overseas installation engineers over 30 years, about hundreds assembly workers with 5-20 practical production experience.

2.Exhibition

We had attended the Germany Nuremberg Exhibition, Poland Warsaw Exhibition, Indonesia Packing Exhibition,...
3. Certification
Why Choose Us

Pre-Sales Service

* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
* Design product layout

After-Sales Service

* Training how to install the machine, training how to use the machine.
* Engineers available to install and debug machinery overseas.
* 15 months quality guarantee.

Packaging

The normal package is wrapping shrink film first,after that wooden box(Size: L*W*H). We also can pack it according to customers special request.
FAQ
Q1: Are you a trading company or a manufacturer?
A1: We are a manufacturer, we supply the factory price with good quality,our Engineer Team with over 20 year's experience,welcome to visit!
Q2.How can I know your machine has good quality?
A2:We will send the video of testing the machine working condition for you before delivery,so you can send us your bottle samples for a trial.
Q3:What's your guarantee or the warranty of the quality if we buy your machines?
A3: We offer you high quality machines with 15 months guarantee and supply life-long technical support.
Q4: When can I get my machine after I paid?
A4: The delivery time is based on the exact machine you confirmed.
Q5: How can I install my machine when it arrives?
A5: We will send our engineers to your factory to install the machines and train your staff how to operate the machines.
Q6: How about the spare parts?
A6: After we deal down all the things, we will offer you a spare parts list for your reference.
