Quick Details
-
Brand Name:
-
Allmay
-
Model Number:
-
AM-XD-230Y12
-
Color Temperature(CCT):
-
2700K/6000K
-
Input Voltage(V):
-
AC85-265V
-
Lamp Luminous Efficiency(lm/w):
-
>70
-
Lamp Luminous Flux(lm):
-
>800lm
-
Working Temperature(℃):
-
-20 - 40
-
Application:
-
Balcony, Porch, Office Building, Living room, dinning room and Hotel lighting etc
-
Product name:
-
Indoor Motion Sensor Ceiling Light
-
Sensor distance:
-
6-8m Radius
-
Size:
-
Diameter 230 mm
-
Power:
-
12W
-
Power Factor:
-
0.5/0.9
-
Working Mode:
-
ON/OFF or Dimming (100%-20%)
-
Holding time:
-
15sec default
-
Installation:
-
Surface Mounted
-
Emergency:
-
available
-
CRI (Ra>):
-
70
-
Working Lifetime(Hour):
-
30000
Quick Details
-
Lamp Body Material:
-
Iron
-
Design Style:
-
Traditional
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Allmay
-
Model Number:
-
AM-XD-230Y12
-
Color Temperature(CCT):
-
2700K/6000K
-
Input Voltage(V):
-
AC85-265V
-
Lamp Luminous Efficiency(lm/w):
-
>70
-
Lamp Luminous Flux(lm):
-
>800lm
-
Working Temperature(℃):
-
-20 - 40
-
Application:
-
Balcony, Porch, Office Building, Living room, dinning room and Hotel lighting etc
-
Product name:
-
Indoor Motion Sensor Ceiling Light
-
Sensor distance:
-
6-8m Radius
-
Size:
-
Diameter 230 mm
-
Power:
-
12W
-
Power Factor:
-
0.5/0.9
-
Working Mode:
-
ON/OFF or Dimming (100%-20%)
-
Holding time:
-
15sec default
-
Installation:
-
Surface Mounted
-
Emergency:
-
available
-
CRI (Ra>):
-
70
-
Working Lifetime(Hour):
-
30000
- 12W Indoor Microwave motion sensor LED Ceiling light for Hallway Corridor Stairs Closet Depot Toilet
-
| Input Characteristics | |||||
| Model No. | AM-190XD04 | AM-190XD07 | AM-230XD12 | AM-300XD15 | AM-300XD18 |
| Mains voltage |
100-265 |
100-265V | 100-265V | 100-265V | 100-265V |
| Stand-by power | <0.5W | <0.5W | <0.5W | <0.5W | <0.5W |
| Rated Power | 4W | 7W | 12W | 15W | 18W |
| LED Qty | 18pcs/2B9C | 16pcs/2B8C | 24pcs/2B12C | 30pcs/2B15C | 36pcs/2B18C |
| LED Source | SMD2835 | SMD5730 | SMD5730 | SMD5730 | SMD5730 |
| Output Lumen | 200-250 lm | 320-430 lm | 600-840 lm | 900-1200 lm | 1100-1300lm |
| Color Temperature | 2700K/6000K | 2700K/6000K | 2700K/6000K | 2700K/6000K | 2700K/6000K |
| Power Factor | >0.9 | >0.9 | >0.9 | >0.9 | >0.9 |
| Lumen Efficiency | >50Lm/W | >50Lm/W | >50Lm/W | >50Lm/W | >50Lm/W |
| CRI (Ra) | >80 | >80 | >80 | >80 | >80 |
| Sensor Data | |||||
| Sensor principle | HF Microwave | HF Microwave | HF Microwave | HF Microwave | HF Microwave |
| Operation Frequency | 5.8GHz | 5.8GHz | 5.8GHz | 5.8GHz | 5.8GHz |
| Transmission power | <0.2mW | <0.2mW | <0.2mW | <0.2mW | <0.2mW |
| Detection range: Max(diameter*H) | 8m*6m | 8m*6m | 8m*6m | 8m*6m |
8m*6m |
| Detection angle | 30° ~150° | 30° ~150° | 30° ~150° | 30° ~150° | 30° ~150° |
| Hold time | 15+/-5s | 15+/-5s | 15+/-5s | 15+/-5s |
3s-160s (selectable) |
| Sensor Mode | On/Off ; Full/Dim | On/Off ; Full/Dim | On/Off ; Full/Dim | On/Off ; Full/Dim |
On/Off ; Full/Dim |
| Daylight sensor (on/off Mode) | <10 lux | <10 lux | <10 lux | <10 lux |
0-300lux (selectable) |
| Environment | |||||
| Operation Temperature(Ta) | -20~40°c | -20~40°c | -20~40°c | -20~40°c | -20~40°c |
| IP Rating | IP20 | IP20 | IP20 | IP20 | IP20 |
-
LED Ceiling Light with Motion Sensor
Product Feature:
- led Ceiling Light with microwave sensor
- Ceiling Mounted Suspended.
- Auto Switch on/off when motion activated/ motionless
- High sensitivity within 6-8 meters distance
- Energy efficient, Eco friendly, Easy to install.
- Low power consumption.
- Emergency function optional. for more information, please contact us.
-
The Motion Detector can turn on the light based on movement, with this detector built in, light is automatically on/off.
Two Optional Sensing Type:
-
Sensor Type A: When detect movement lighting 100% 12w
No movement, standby status light off
-
Sensor Type B: When detect movement lighting 100% 12w
No movement, standby status light 20% 2-3 watts.
-
Daylight sensor < 10lux ( you can choose with/without daylight sensor)
With Daylight sensor, means motion sensor only work at night.
Even if there is movement at daytime, the light don't work.
-
-
-
- Motion sensor ceiling light Installation
- 5. Motion sensor PK PIR sensor
-
-
-
Contact and Company
♥ ♥ ♥ CUSTOMER FEADBACK ♥ ♥ ♥
- nd original products.
- If have any question for our products
- Welcome to contact me at any time
-
Sensor Ceiling light
Input Characteristics Model No. AM-190XD04 AM-190XD07 AM-230XD12 AM-300XD15 AM-300XD18 Mains voltage 100-265
100-265V 100-265V 100-265V 100-265V Stand-by power <0.5W <0.5W <0.5W <0.5W <0.5W Rated Power 4W 7W 12W 15W 18W LED Qty 18pcs/2B9C 16pcs/2B8C 24pcs/2B12C 30pcs/2B15C 36pcs/2B18C LED Source SMD2835 SMD5730 SMD5730 SMD5730 SMD5730 Output Lumen 200-250 lm 320-430 lm 600-840 lm 900-1200 lm 1100-1300lm Color Temperature 2700K/6000K 2700K/6000K 2700K/6000K 2700K/6000K 2700K/6000K Power Factor >0.9 >0.9 >0.9 >0.9 >0.9 Lumen Efficiency >50Lm/W >50Lm/W >50Lm/W >50Lm/W >50Lm/W CRI (Ra) >80 >80 >80 >80 >80 Sensor Data Sensor principle HF Microwave HF Microwave HF Microwave HF Microwave HF Microwave Operation Frequency 5.8GHz 5.8GHz 5.8GHz 5.8GHz 5.8GHz Transmission power <0.2mW <0.2mW <0.2mW <0.2mW <0.2mW Detection range: Max(diameter*H) 8m*6m 8m*6m 8m*6m 8m*6m 8m*6m
Detection angle 30° ~150° 30° ~150° 30° ~150° 30° ~150° 30° ~150° Hold time 15+/-5s 15+/-5s 15+/-5s 15+/-5s 3s-160s
(selectable)
Sensor Mode On/Off ; Full/Dim On/Off ; Full/Dim On/Off ; Full/Dim On/Off ; Full/Dim On/Off ; Full/Dim
Daylight sensor (on/off Mode) <10 lux <10 lux <10 lux <10 lux 0-300lux
(selectable)
Environment Operation Temperature(Ta) -20~40°c -20~40°c -20~40°c -20~40°c -20~40°c IP Rating IP20 IP20 IP20 IP20 IP20 -
