Quick Details
-
Engine Brand:
-
famous brand
-
Travel Speed:
-
4km/h
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
liebty
-
Dimension(L*W*H):
-
5610*2280*3000mm
-
Exciting Force:
-
260KN
Quick Details
-
Type:
-
Tire Roller
-
Power:
-
110kw
-
Weight:
-
10ton
-
Engine Brand:
-
famous brand
-
Travel Speed:
-
4km/h
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
liebty
-
Dimension(L*W*H):
-
5610*2280*3000mm
-
Exciting Force:
-
260KN
Contact
Sales Manager: Ryann
Huang
WhatsApp/WeChat/mobile: +86 19858195297
E-mail: ryann@liebty.com
Company: Liebty Machinery Technology (Hangzhou) Co.,Ltd
Address: Room 208, Building 3, No.1866, Binxing Road, Changhe Street, Binjiang District, Hangzhou, Zhejiang, China
Product Description
Hot Selling LUTONG LTC210 10 ton Hydraulic Double Drum Vibratory Road Roller Asphalt Road Roller Compactor with Factory Price
* Remarkable compacting performance
Dual frequency and dual amplitude vibrating system and scientific and reasonable static linear load and excitation force ensure the effective compaction of different materials and layers with different thicknesses.
* Outstanding power train Hydraulic drive system
Adopt the closed anti-slip hydraulic drive system composed by imported heavy-load variable pump and motor, ensuring the good driving performance and high grade ability.
* Reliable Electrical System
The electrical system adopts imported water-proof, dust-proof, vibration-resistant electric connectors for increased
reliability.Imported maintenance-free battery has high start-up current and good
Product Parameters
|
MODLE
|
|
LTC210
|
|
Operating mass
|
kg
|
10000
|
|
Front axle load
|
kg
|
5000
|
|
Rear axle load
|
kg
|
5000
|
|
Static linear load
|
N/cm
|
289
|
|
Form of frame
|
|
Fork-type
|
|
Water tank capacity
|
L
|
2×450
|
|
Fuel tank capacity
|
L
|
134
|
|
Hydraulic tank capacity
|
L
|
75
|
|
Vibration frequency
|
mm
|
|
|
High ampl.
|
|
0.67
|
|
Low ampl.
|
|
0.34
|
|
Vibration frequency
|
Hz
|
|
|
High ampl.
|
|
40
|
|
Low ampl.
|
|
46
|
|
Centrifugal force
|
kN
|
|
|
High ampl.
|
|
160×2
|
|
Low ampl.
|
|
90×2
|
|
Travel speed
|
km/h
|
0-10
|
|
Turning radius
|
mm
|
6000
|
|
Grade ability
|
%
|
30
|
|
Steering angle
|
°
|
±30
|
|
Drum diameter
|
mm
|
1150
|
|
Drum width
|
mm
|
1730
|
|
Transverse swing angle of the vibrating wheel
|
°
|
±8
|
|
Type of water spray
|
mm
|
Pressure
|
|
Wheelbase
|
mm
|
3217
|
|
Overall length
|
mm
|
4558
|
|
Overall width
|
mm
|
1840
|
|
Overall height
|
mm
|
2674
|
|
Ground clearance
|
mm
|
258
|
|
Diesel model
|
|
QSB3.9
|
|
Diesel power
|
kw
|
74
|
|
Diesel speed
|
r/min
|
2400
|
