Quick Details
-
Application:
-
Villa
-
Type:
-
Electric Gate Lock
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Chisung
-
Model Number:
-
EL102 Electric lock, EL102 Electric lock
-
Power supply:
-
AC220V±10V 50/60HZ,AC110V±10V, 60Hz
-
Product used for:
-
Smart Electric lock Security for automatic gate opener
-
Output:
-
DC24V
-
Product used for 2:
-
DC12V/24v black lock for swing gate opener
-
Certificate:
-
CE Approved
-
Weight:
-
2kg
-
Dimension:
-
124 x 67 mm
-
Double coil:
-
Powder coated finish.
-
Usage:
-
Driveway Electric Gate Lock
Quick Details
-
Warranty:
-
1 Year
-
After-sale Service:
-
Online technical support
-
Project Solution Capability:
-
NONE
-
Application:
-
Villa
-
Type:
-
Electric Gate Lock
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Chisung
-
Model Number:
-
EL102 Electric lock, EL102 Electric lock
-
Power supply:
-
AC220V±10V 50/60HZ,AC110V±10V, 60Hz
-
Product used for:
-
Smart Electric lock Security for automatic gate opener
-
Output:
-
DC24V
-
Product used for 2:
-
DC12V/24v black lock for swing gate opener
-
Certificate:
-
CE Approved
-
Weight:
-
2kg
-
Dimension:
-
124 x 67 mm
-
Double coil:
-
Powder coated finish.
-
Usage:
-
Driveway Electric Gate Lock
Product Description
24V DC Electric Gate Lock with rotating deadbolt
Electric lock with a revolutionary rotating bolt is ideally suited for driveway gates (single gate and double gates), pedestrian
entry gates and garage and shed swing doors.Can be operated in conjunction with most gate openers and access control systems.The
spring loaded tongue goes into lock mode when the gate is pushed close and when energized with 24V DC the tongue rotates by 45
degrees causing the gate to move away from the striker plate, it can be mounted on double or single gates.
Features:
Horizontal or vertical mounting.
24V DC powered collapsible lock when activated.
Solid brass rotating deadbolt.
Extra strong rotating bolt.
Unlocks when energized and locks again when energizing ceases.
Double coil.Powder coated finish.
Dimension: 124 x 67 mm.
Single gate installation: Gate to post.
Double gate installation: Gate to ground or gate to gate (recommended, if a gate stop is in use).
Supplied with galvanized striker.
Usage:
Driveway Electric Gate Lock
Pedestrian Electric Gate Lock
Suitability:
The EL-24V is suitable for pull to open gates application (gates swinging inwards), other push to open locks are available on
request.
Electric lock with a revolutionary rotating bolt is ideally suited for driveway gates (single gate and double gates), pedestrian
entry gates and garage and shed swing doors.Can be operated in conjunction with most gate openers and access control systems.The
spring loaded tongue goes into lock mode when the gate is pushed close and when energized with 24V DC the tongue rotates by 45
degrees causing the gate to move away from the striker plate, it can be mounted on double or single gates.
Features:
Horizontal or vertical mounting.
24V DC powered collapsible lock when activated.
Solid brass rotating deadbolt.
Extra strong rotating bolt.
Unlocks when energized and locks again when energizing ceases.
Double coil.Powder coated finish.
Dimension: 124 x 67 mm.
Single gate installation: Gate to post.
Double gate installation: Gate to ground or gate to gate (recommended, if a gate stop is in use).
Supplied with galvanized striker.
Usage:
Driveway Electric Gate Lock
Pedestrian Electric Gate Lock
Suitability:
The EL-24V is suitable for pull to open gates application (gates swinging inwards), other push to open locks are available on
request.
Product Paramenters
|
Type
|
Electric Gate Lock
|
|
Power supply
|
AC220V±10V 50/60HZ,AC110V±10V, 60Hz
|
|
Model Number
|
EL102 Electric lock
|
|
Product used for
|
Smart Electric lock Security for automatic gate opener
|
|
Output
|
DC24V
|
|
Product used for 2
|
DC12V/24v black lock for swing gate opener
|
|
Certificate
|
CE Approved
|
|
Weight
|
2kg
|
|
Dimension
|
124 x 67 mm
|
|
Double coil
|
Powder coated finish.
|
|
Usage
|
Driveway Electric Gate Lock
|
