Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Finecables(FC)
-
Model Number:
-
Push pull connector-19-1
-
Connector series:
-
Push Pull Series
-
Connector insert:
-
PEEK
-
Connector contacts:
-
Brass with Gold plated
-
Coupling nut/screw:
-
Brass with Cr Plated
-
Locking Type:
-
Push Pull Self Locking
-
Contacts Type:
-
Solder/Crimp
-
Salt Spray Test:
-
>144H
-
Ambient Temperature:
-
-55°C ~ +250°C
-
Mating Endurance:
-
>2000
-
Certificate:
-
ULs/CE/ROHS/REACH/ISO13485
Quick Details
-
Type:
-
push pull connector
-
Application:
-
Power
-
Gender:
-
Male
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Finecables(FC)
-
Model Number:
-
Push pull connector-19-1
-
Connector series:
-
Push Pull Series
-
Connector insert:
-
PEEK
-
Connector contacts:
-
Brass with Gold plated
-
Coupling nut/screw:
-
Brass with Cr Plated
-
Locking Type:
-
Push Pull Self Locking
-
Contacts Type:
-
Solder/Crimp
-
Salt Spray Test:
-
>144H
-
Ambient Temperature:
-
-55°C ~ +250°C
-
Mating Endurance:
-
>2000
-
Certificate:
-
ULs/CE/ROHS/REACH/ISO13485
Specifications
|
Basic Product Information
|
|
|
|
Connector Series
|
B series K series
|
|
|
Gender
|
Male/Female
|
|
|
Coding
|
G KEY
|
|
|
Locking Type
|
Quick lock,Self Locking,Quick Release
|
|
|
Mounting Type
|
Cables Assembly,Panel mounted
|
|
|
Part No.
|
self locking connector
|
|
|
|
|
|
|
General Infomation
|
|
|
|
|||
|
Ambient Temperature
|
-55℃~250℃
|
Mating Endurance
|
>5000 cycles
|
|||
|
Insulator
|
PEEK
|
Connector Contacts
|
Brass with Gold Plated
|
|||
|
Coupling Nut/Screw
|
Brass with Nickel Plated
|
Housing
|
Brass with Cr Plated
|
|||
|
Seal/o-ring
|
///
|
Insulation resistance
|
≥100MΩ
|
|||
|
IP Rating
|
IP50 in locked condition
|
Shielding efficiency
|
at 10MHz>75dB / at 1GHz>40dB
|
|||
|
Salt spray
corrosion test
|
>144h
|
Certificate
|
UL/CE/ROHS/REACH/IP50
|
|||
