Acoustical Panels Smooth Texture Fiberglass Acoustic Hanging Baffles

Acoustical Panels Smooth Texture Fiberglass Acoustic Hanging Baffles

FOB Reference Price: Get Latest Price

≥100 Pieces

US $7

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Application:: Office Building

Design Style:: Modern

Place of Origin:: Jiangsu, China

Brand Name:: Degoaoustic

Model Number:: B1200

Material:: Fiberglass wool (Mineral fiber )

Size:: 600*1200mm 300*1200mm 200*1200mm

Thickness:: 30mm 40mm 50mm

Color:: White RAL color

Edge:: SStraight painted edge

Surface:: Factory painted

Function:: Fireproof, Heat Insulation, Sound-Absorbing

Install:: Spring Wire rope kit

model:: Rectangular linear wave curved

Hs code:: 7019399000

Quick Details

Warranty:: 2 years

After-sale Service:: Online technical support

Project Solution Capability:: graphic design

Application:: Office Building

Design Style:: Modern

Place of Origin:: Jiangsu, China

Brand Name:: Degoaoustic

Model Number:: B1200

Material:: Fiberglass wool (Mineral fiber )

Size:: 600*1200mm 300*1200mm 200*1200mm

Thickness:: 30mm 40mm 50mm

Color:: White RAL color

Edge:: SStraight painted edge

Surface:: Factory painted

Function:: Fireproof, Heat Insulation, Sound-Absorbing

Install:: Spring Wire rope kit

model:: Rectangular linear wave curved

Hs code:: 7019399000

DEGOFON Acousticl Baffle Ceilings

Fiberglass NRC0.85 The DEGO Baffle ™ is a vertically suspended lightweight acoustical panel made of high-density fiberglass Vinylon made of wool board, the surface is coated with white elegant EXSOUND sound transmission sound absorption felt, excellent sound absorption. The size of standard sound-absorbing pendant is 1200 × 600 × 40mm and 1200 × 300 × 40mm.Modern None The panels is designed to provide a pleasing aesthetic alternative to the ceiling system.Ensures good light reflection and is used in noisy environments with high sound absorption by DEGO Baffle ™. The tab provides excellent acoustic performance and can be installed directly on top of the exposed concrete to Realize energy-saving natural cross ventilation cold and hot airflow.Can also be used for ordinary mineral wool board, gypsum board top. The DEGO Baffle ™ high sound-absorbing tab is the ideal acoustic solution for open, bare,Internal and thermal mass cooling is especially suitable for areas where suspended ceilings cannot be applied,

MATERIAL	Fiberglass wool panels with acoustically transparent membrane
SURFACE FINISHE D	DEGOACOUSTIC factory applied acrylic latex paint,
COLOR	White .black ，Custom
SOUND ABSORPTION	NRC：0.85-0.9
SIZE(s）	Item606012(600mm×1200mm×40mm),Item60120(600mm×1200mm×30mm),
		Item 60180(600mm×1800mm×40mmItem6018015(600mm×1800mm×40mm)
		Item6024020(600mm×2400mm×50mm),Item6024025(600mm×2400mm×75mm)
		Item2024040(200mm×2400mm×40mm),tem3012040(300mm×1200mm×30mm),
EDGE	·Square L
WEIGHT	4.55kgs/m 40mm Thick
LIGHT REFLECTANCE	LR 0.85
MOISTURERESISTANCE	RH99
FIRE CLASS	(ASTM E1264) Class A1 per CN，lame Spread: 25 or less Smoke Developed: 50 or less
MILDEW RESISTANC	Fiberglass substrate is inherently resistantto the growth of mold and mildew.
RECOVERABLE	71%
WARRANTY	15Year ，	Useful life 50Y

Details Images

Product Description

· Material：100K Fiberglass wool ·Clour：White (WH) ·Edge：Painted on edges

Size:600X1200mm 600x1800mm 600x2400mm

300X1200mm 300x1800mm 300x2400mm

4 00X1200mm 400x1800mm 400x2400mm

200X1200mm 200x1800mm 200x2400mm

Thick:30/40/50/75mm

*Other Size available on special request.

Performance Advantage

·Beautiful frameless innovative sound-absorbing independentceiling. ·Elegant white surface or RAL color custom.Give full play to the design freedom. ·Vertical installation, especially suitable for areas where suspe nded ceilings cannot be applied. ·High sound absorption performance, ·Dimensional stability up to 100% relative humidity。

Clour

DEGO FACTORY

DEGO develops, manufactures and markets acoustic panels baffles and ceiling tiles systems.18 years of experience in many projects through architects, designers, agents, OEMs of famous brand companies

Our acoustic products cover glass fiber, rock wool, mineral wool, gypsum materials .
Customized surface textures, colors, shapes and modular standard products ，High quality products to serve many customers
We offer a wide range of acoustic ceilings for all purposes. Explore our comprehensive product systems.
