Quick Details
-
Model Number:
-
LDF -20
-
Weight (KG):
-
1600 kg
-
Size:
-
1600*1200*1700mm
-
Size of the waste filling entrance:
-
380mm*480mm
-
Application:
-
Hospital Medical waste
-
Raw material:
-
Carbon steel Stainless steel
-
After Warranty Service:
-
Video technical support
-
Chimney:
-
Height 6m
-
Air Blower:
-
0.37kw
-
Color:
-
White
-
Operation voltage:
-
220V50HZ
Quick Details
-
Production Capacity:
-
15-20kg/hour
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
LongMedtech
-
Model Number:
-
LDF -20
-
Weight (KG):
-
1600 kg
-
Size:
-
1600*1200*1700mm
-
Size of the waste filling entrance:
-
380mm*480mm
-
Application:
-
Hospital Medical waste
-
Raw material:
-
Carbon steel Stainless steel
-
After Warranty Service:
-
Video technical support
-
Chimney:
-
Height 6m
-
Air Blower:
-
0.37kw
-
Color:
-
White
-
Operation voltage:
-
220V50HZ
Products Description
Features:
* With temperaturemonitoring function
* insulated and refractory lined chamber, and with thickness of refractory more than 200mm
* Low temperature outside when incineration
* Minimum installation and start up time * Factory assembled, no installation required. Connect electricity and the unit is ready to operate
* Monitors, recorders and other accessory equipment available.Easy and safe operation
* Automatic control system provides preset burn times and shut off.
* Temperature monitoring as standards
* Safety fan run on timer
* Low energy consumption levels
* Programmable digital temperature controls maintain temperature, assuring complete combustion while conserving fuel.
* Secondary burner with temperature activated modulating control provides fast preheat and sustains high temperature performance at low energy consumption levels.
* insulated and refractory lined chamber, and with thickness of refractory more than 200mm
* Low temperature outside when incineration
* Minimum installation and start up time * Factory assembled, no installation required. Connect electricity and the unit is ready to operate
* Monitors, recorders and other accessory equipment available.Easy and safe operation
* Automatic control system provides preset burn times and shut off.
* Temperature monitoring as standards
* Safety fan run on timer
* Low energy consumption levels
* Programmable digital temperature controls maintain temperature, assuring complete combustion while conserving fuel.
* Secondary burner with temperature activated modulating control provides fast preheat and sustains high temperature performance at low energy consumption levels.
|
Technical Specifications for LDF-20
|
|
|
|
Applicable hospital size (number of beds)
|
50
|
|
|
Burning Ability
|
15-20kg/hour (daily incineration 3-6 times）
|
|
|
Size of the incinerator
|
1600㎜×1200㎜×1700㎜
|
|
|
Volume of incinerator
|
Gasification room 0.2m3，secondary burning chamber 0.14m3 , mix burning chamber 0.02m3
|
|
|
Size of the waste filling entrance
|
380㎜×480㎜
|
|
|
Auxiliary burner
|
Power 0.11kw，oil consumption volume 4-6㎏/h
|
|
|
Operation voltage
|
220V50HZ
|
|
|
Re-burning burner
|
Power 0.11kw，oil consumption volume 6-10㎏/h
|
|
