Oil immersed high voltage step down current transformer

Quick Details

Quick Details

Oil immersed high voltage step down current transformer ：

The specifications of the oil immersed transformer :

COIL:

CORE:

OIL TANK AND ACCESSORIES:

Tchnical Parameters for S11 35kv 50-1600kva three phase oil immersed transformer :

Oil immersed high voltage step down current transformer

FOB Reference Price: Get Latest Price

≥1 Sets

US $950

Free Inquiry

Customized Request

Product Details

{{item.text}}

Model Number:: S9/S11/S13/15

Usage:: Power

Coil Structure:: TOROIDAL

Coil Number:: AUTOTRANSFORMER

Rated capacity:: 30kva to 10000kva

Rated voltage:: 11kv to 35kv

Type:: Oil Immersed

Frequency:: 50/60Hz

Vector group:: Dyn11 / Yyn0

Certification:: ISO9001

Standard:: IEC60076

Material:: Copper /Aluminum Winding

Phase:: Three

Place of Origin:: Hebei, China

Brand Name:: Zhongyi

Model Number:: S9/S11/S13/15

Usage:: Power

Coil Structure:: TOROIDAL

Coil Number:: AUTOTRANSFORMER

Rated capacity:: 30kva to 10000kva

Rated voltage:: 11kv to 35kv

Type:: Oil Immersed

Frequency:: 50/60Hz

Vector group:: Dyn11 / Yyn0

Certification:: ISO9001

Standard:: IEC60076

Material:: Copper /Aluminum Winding

Product Description

In the transformer winding there is a zigzag oil guide structure so as to fully cool all areas inside the winding ,lower the temperature rise of the winding and the hot points of the winding and [rolong the service life of insulation.the HV and MV regulation system are independently provide with voltage regulating winding to balance the ampere turn of each winding effecticely lower the axial electrodynamic force generated at short circuit of transformer and improve abrupt short circuit withstanding capacity.

The core is made of high permeable grain orientated top quality coid rolled silicon sheet and the materical is cut with advanced germany geoge gmbh automatic shear line with the cut burrs controlled within 0.002mm.

The sillicon sheet fabrication adopts no-upper yoke lapped technology and all lapped joints of the sillicon sheet are 45 c full miters.the laminated core sheets are integrally pressed and adhered with epoxy resin to make the three leg two yoke core a strong and flat integral one with good verticality precision ,this effectively improves no ;oad performance and reduces noises.

The tank wall adopts wide steel sheet,which will be folded into corrugated structure without splicing,in this way welds are decreased and mechanical strength id enhanced ,meanwhile ,the corrugated wall has deverging effect ,and thus plays a role in dectease of noise .the routing troughs and control cabinets of the secondary circuit are all made of stainless steel.so the entire transformer has a simple and good looking .

All sealing surfaces use quality sealing material and are precision machined

Are you manufacturer or trading company?

Hebei ZHONGYI Group is a specialized manufacturer with over 20years production experience, and have our own
trade mark "ZHONGYI GROUP".

How do you control the quality ?

Professional QC team comply with TQM insure you the quality. Each step is in compliance to the standards,At
the same time ,we will take photos or shoot video for you.

What about lead or shipping time?

The lead time depends on the quantity you ordered, generally within 20-30 days upon receipt of advance payment.

Detailed Images

Packing & Delivery

For the product: Most value S13 type oil immersed three phase 30 kv transformer, we normally use wooden case or steel frame to pack , the packing size is up to the different models. As for very big transformers, we will order special containers to ship them. OR AS YOUR ORDER.

packing Details: Inner Plastic smocks or asphalt felt bag with desiccating agent,then wooden carton or frame steel .

Delivery Details: If you buy standard type product : 5-12 work days .If you buy Customized products: As your purchasing quantity to decide .

Why Choose Us

Baoding Zhongyi Electrical material Manufacturing Co., Ltd.mainly produces: oil-immersed power transformers, dry-type transformers, box-type substation, high and low voltage switchgear assembly and a variety of special-type transformers. The hoisting, tooling and testing equipments are complete. Our company has passed the ISO9001-2015 international standard quality management system certification. All performance indicators of the products have reached the relevant national standards and international standards.

Baoding Zhongyi Electrical material Manufacturing Co., Ltd. follows the enterprise purpose of the "details determine the success or failure, integrity casts the future", abides by the business philosophy of the "integrity based, to be innovative ambitious", we’ll warmly treat our customers as always and continuously provide quality products and services to your satisfaction.
