Quick Details
-
protection:
-
IP66
-
Optical zoom:
-
4X Optical zoom
-
IR Distance:
-
25M
-
TF Card:
-
(max 128GB )
-
ONVIF:
-
Support
Quick Details
-
Special Features:
-
Waterproof / Weatherproof
-
Resolution:
-
1920*1080P
-
Focus:
-
2.8-12 mm
-
protection:
-
IP66
-
Optical zoom:
-
4X Optical zoom
-
IR Distance:
-
25M
-
TF Card:
-
(max 128GB )
-
ONVIF:
-
Support
Camera Features:
-
Support AP connection
- Supports Both Wi-Fi and wired connectivity
- Supports micro SD cards up to
128GB
(not included)
- Supports ONVIF, works with third-party NVR
- Supports mobile video surveillance (iOS, Android) via Yoosee
- Motion Detection & Email Alert functions
Specifications:
System Structure :
Dual-core 32-bit DSP HI3518EV200
Video Compression : H.264
Sensor : 2MP CMOS Sensor
Video Resolution : 1920*1080P
adjustable ;support frame rate from 1 to 15 frames/sec adjustable
Lens :
2.8-12
mm
(
4X
Zoom)
IR Cut Filter : Yes
Wireless : wifi 802.11b/g/n
Motion Detect & Email Alert : Supports
Connector :1PCS LAN Port,1PCS Power Connector,1PCS Reset Button
Mobile Monitoring : Support IOS & Android With APP Yoosee
IR LED : 6pcs IR LED With 25Meters IR Distance
Woring Temperature : -20 to 60 degree
Power : 12V 1A-2A
TF Card Slot : Support (
Max 128Gb TF Card
)
Specs :
Model | |||
camera | Audio | sensor | 1/2.8" CMOS |
Image | 1080P(1920X1080) | ||
shutter | 1/25s ~ 1/100000s | ||
Iris | F2.0 | ||
Day&Night | ICR | ||
Illumination | 0.01Lux @(F2.0,AGC ON) ,0 Lux with IR | ||
Video | Video compression | G.711-u law | |
Image enhance |
Image setting |
AWB, AGC adjust | |
Exposure
Mode
Manual /auto |
|||
Adjust , Sharpness, Saturation, Brightness & Contrast Adjustable ;white balance , | |||
3D Position | not support | ||
DWR | D-WDR | ||
D-Noise | 2D/3D-DNR | ||
Image Orientation | Mirror/Flip | ||
Privacy Zone | support | ||
motion detection | support | ||
OSD | Chinese &English | ||
compression Standard | Chip | GM 8135 | |
Video compression | H.264/ H265 | ||
Frame |
50HZ:25fps(1920x960) 60HZ:30fps(1920x960) |
||
Bit Rate |
32kbps-.3.5Mbps | ||
rate control mode | VBR/CBR | ||
image effect | VBR:5 adjustable mode CBR: Can adjustable freely | ||
Cover/Housing | Focus | 2.8-12 mm | |
Iris | F 1.2 | ||
lens connector | M12 connector | ||
protection | IP66 | ||
Bracket | wall bracket ,pend bracket | ||
size | 168mm×68mm×68mm(length ,wide ,high | ||
Gross | 360g | ||
PTZ | Optical zoom | 4X Optical zoom | |
IR Distance | 25 M | ||
Pan speed range | 0°~200° | ||
Tilt speed range | 0°~60° | ||
Pan speed | 0.1°~20°/ s | ||
Tilt speed | 0.1°~12°/ s | ||
Preset | Not support | ||
communication interface | network | RJ45 | |
Power | DC 12V | ||
TF Card | (max 128GB ) | ||
Cloud storage | Not support | ||
Audio | one Audio in ,one audio out ( optional) | ||
Alarm | not supprot | ||
network | Remote control | Mobile APP :YOOSEE | |
Phone client | Support with Windows Mobile,iPhone,iPad,Android | ||
User |
Supports simultaneous monitoring for up to 4 users with multi-stream real time
|
||
network protocol | TCP/IP, UDP, DHCP, NTP, RTSP, PPPoE, DDNS, SMTP, FTP | ||
ONVIF | Support | ||
Ethernet | 100Mbps | ||
Wifi | support | ||
PoE | not support | ||
others | Power | DC12V | |
Work Environment | -30ºC~60ºC , humidity range : 10%~90% |
