Quick Details
-
Power:
-
8.4KW/ 9.9KW
-
Place of Origin:
-
shandong
-
Brand Name:
-
JM
-
Maximum Digging Height:
-
2520MM
-
Maximum Digging Depth:
-
1690MM
-
Machine Weight:
-
1200 kg
-
Max Digging Radius:
-
1800MM
-
Rated Speed:
-
1.8KM/H
-
Marketing Type:
-
2023 Latest Design
-
Easy Fuel:
-
Yes
-
Swing Boom:
-
Optional
-
Adjustable Tracks:
-
Optional
-
Hydraulic Joystick Control:
-
Optional
-
Customized Color:
-
Yes
-
Customized LOGO:
-
Yes
-
USA EPA Certification:
-
Yes
-
Europe EURO5 Emissoin/CE:
-
Yes
Quick Details
-
Operating Weight:
-
1ton, 0.8 TON, 1.2ton, 1.5ton
-
Bucket capacity:
-
0.038CBM
-
Engine Brand:
-
KOOP/ KUBOTA
-
Power:
-
8.4KW/ 9.9KW
-
Place of Origin:
-
shandong
-
Brand Name:
-
JM
-
Maximum Digging Height:
-
2520MM
-
Maximum Digging Depth:
-
1690MM
-
Machine Weight:
-
1200 kg
-
Max Digging Radius:
-
1800MM
-
Rated Speed:
-
1.8KM/H
-
Marketing Type:
-
2023 Latest Design
-
Easy Fuel:
-
Yes
-
Swing Boom:
-
Optional
-
Adjustable Tracks:
-
Optional
-
Hydraulic Joystick Control:
-
Optional
-
Customized Color:
-
Yes
-
Customized LOGO:
-
Yes
-
USA EPA Certification:
-
Yes
-
Europe EURO5 Emissoin/CE:
-
Yes
1. Product Parameters
| Main Dimentions | |
| Operating Weight | 1200kg |
| Bucket Capacity | 0.025cbm/120kg |
| Bucket Width | 380 |
| Boom Length | 1390 |
| Arm Length | 750 |
| Travel Speed | 3.1M/H |
| Overall Length | 2680 |
| Overall Width | 940 |
| Overall Height | 1350 |
| Superstructure width | 930-1200 |
| Counterweight ground clerance | 400 |
| Total track length | 1200 |
| Track shoe width | 180 |
| Total track width | 930 |
| Min.Front Swing radius | 1800 |
| Dozer blade width | 930 |
| Max.Diiging radius | 2590 |
| Max.Digging Depth | 1690 |
| Max.Digging Height | 2520 |
| Max.Dumping Height | 1765 |
| Grade Ability | 35° |
| Ground Pressure | 25KPA |
| Bucket digging force | 870KN |
| Arm digging force | 665KN |
| Engine KOOP / KUBOTA | |
| Fuel consumption | 1.5-1.8L/H |
| Engine Oil | 5L |
| Engine brand | KOOP KD192 / KUBOTA D722 |
| Rated Power | 8.4kw / 9.9kw /2500r/min |
| Displacement | 1.216L/CC |
| Cylinders | 1 / 3 |
| Cooling type | Air–cooling / Water-cooling |
| PARTS | |
| Main pump | Gear pump - BEIFANG |
| Rated Pressure | 18MPA |
| Main pump Max.Flow | 6L/Min |
| Walking hydraulic motor type | BEIFANG China |
| Swing hydraulic motor | BEIFANG China |
| Auxiliary Piping for Hammer | YES |
| Fuel Tank | 11L |
