Quick Details
-
Warranty:
-
20 years, 20 years
-
Brand Name:
-
TIANXIANG
-
Model Number:
-
550w
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
2278*1134*35mm
-
STC:
-
1000W/ ㎡
-
Vmp:
-
42.11V
-
Imp:
-
13.06A
-
Weight:
-
27kg
-
Efficiency of solar cells:
-
22.5%
-
Operating Temperature:
-
-40 ~ +85℃
-
NOCT:
-
45±2℃
-
Connector:
-
MC4 Compatible
Quick Details
-
Cell size:
-
182mmx182mm
-
Type:
-
Double-glass, All Black
-
Panel Efficiency:
-
22.5%
-
Warranty:
-
20 years, 20 years
-
Brand Name:
-
TIANXIANG
-
Model Number:
-
550w
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
2278*1134*35mm
-
STC:
-
1000W/ ㎡
-
Vmp:
-
42.11V
-
Imp:
-
13.06A
-
Weight:
-
27kg
-
Efficiency of solar cells:
-
22.5%
-
Operating Temperature:
-
-40 ~ +85℃
-
NOCT:
-
45±2℃
-
Connector:
-
MC4 Compatible
Product Description
Specification
|
Module Type
|
TX550W
|
|
|
Maximum Power-Pmax(w)
|
550
|
|
|
Open Circuit Voltage-Voc(V)
|
50.28
|
|
|
Short-Circuit Current-Isc(A)
|
13.90
|
|
|
Voltage at Pmax-Vmp(V)
|
42.11
|
|
|
Current at Pmax-lmp(A)
|
13.06
|
|
|
Module Efficiency -ηm(%)
|
22.5
|
|
|
STC: Irradiance 1000W/ ㎡ , Cell Temperature 25℃ , Air Mass 1.5
|
|
|
|
Power Tolerance(W)
|
(0,+4.99)
|
|
|
Maximum System Voltage(V)
|
1000
|
|
|
Maximum Series Fuse Rating(A)
|
20
|
|
Temperature Characteristics
Mechanical Specifications
Packing List
