Quick Details
-
Market Segement:
-
Engineering transportation
-
Engine Capacity:
-
4 - 6L
-
Gross Vehicle Weight:
-
15-20T
-
Drive Wheel:
-
4X2
-
After-sales Service Provided:
-
Onsite Installation, Video technical support, Overseas Call Centers, Return and Replacement, No after-sales service, Field installation, commissioning and training, Online support, Free spare parts, Field maintenance and repair service
-
Place of Origin:
-
China
-
Cargo Tank Dimension:
-
5410x2300x800mm
-
Wheelbase:
-
4600mm
-
Engine Model:
-
WD615.47
Quick Details
-
Condition:
-
New
-
Horsepower:
-
371HP(273Kw/rpm)
-
Emission Standard:
-
Euro 2
-
Market Segement:
-
Engineering transportation
-
Engine Capacity:
-
4 - 6L
-
Gross Vehicle Weight:
-
15-20T
-
Drive Wheel:
-
4X2
-
After-sales Service Provided:
-
Onsite Installation, Video technical support, Overseas Call Centers, Return and Replacement, No after-sales service, Field installation, commissioning and training, Online support, Free spare parts, Field maintenance and repair service
-
Place of Origin:
-
China
-
Cargo Tank Dimension:
-
5410x2300x800mm
-
Wheelbase:
-
4600mm
-
Engine Model:
-
WD615.47
Contact Way
SINOTRUK HOWO 4X2 Light Duty Dump Truck 6 Tyres Tipper Truck
Product Overview
HOWO Tipper truck 4×2, Euro Ⅱ, standard cab
Product Paramenters
|
Typical truck model
|
|
ZZ3167M3811
|
|
|
ZZ3167M4611
|
|
|||||
|
Cab
|
Model
|
HW70
|
|
|
|
|
|||||
|
|
Type
|
HW70 Standard cab, no berth, with A/C all-steel forward control, 55°hydraulically tiltable to the front,2-arm windscreen wiper
system with 3 speeds, laminate windscreen, with casted-in radio aerial, hydraulically damped adjustable driver’s seat and rigid adjustable co-driver’s seat, heating & ventilation system, adjustable roof flap, with stereo radio/cassette recorder, sun visor, and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorber with transverse stabilizer, safety belt. |
|
|
|
|
|||||
|
Engine
|
Model
|
WD615.87
|
WD615.69
|
|
|
WD615.47
|
|||||
|
|
Rated power
|
290HP(213Kw/rpm)
|
336HP(247Kw/rpm)
|
|
|
371HP(273Kw/rpm)
|
|||||
|
|
Displacement
|
4 stroke direct injection diesel engine
|
|
|
|
|
|||||
|
|
Type
|
6 cylinder in-line with water cooling, turbo-charging & inter cooling
|
|
|
|
|
|||||
|
Wheelbase
|
|
3800mm
|
|
4600mm
|
|
|
|||||
|
Cargo body size
|
|
4190x2300x800mm
|
|
5410x2300x800mm
|
|
|
|||||
|
Clutch
|
|
Single- plate dry diaphragm spring clutch, diameter 430(C) mm, hydraulically operating with air assistance
|
|
|
|
|
|||||
|
Transmission
|
|
SINOTRUK HW series 10/12/16 speed transmission, 10 forward and 2 reverse
|
|
|
|
|
|||||
|
Front axle
|
|
Steering axle with double T-cross section HF9
|
|
|
|
|
|||||
|
Drive axle
|
|
Pressed axle housing, central single reduction HC16
Ratio:5.73 |
|
|
|
|
|||||
|
Chassis
|
|
Frame: U-profile parallel ladder type with section of 320×90×8 mm, all cold riveted cross members and reinforced subframe
Front suspension: 9 semi-elliptic leaf springs with hydraulic telescopic double-action shock absorbers and stabilizer Rear suspension: 9+6 semi-elliptic leaf springs with hydraulic telescopic double-action shock absorbers and stabilizer Spare wheel carrier: with one spare wheel Aluminum fuel tank: with 400 L fuel tank with locking fuel cap |
|
|
|
|
|||||
|
Steering
|
|
Germany brand, hydraulic steering with power assistance
|
|
|
|
|
|||||
|
Brakes
|
|
Service brake: dual circuit compressed air brake
Parking Brake(emergency brake): spring energy, compressed air operating on rear wheels Auxiliary brake: engine exhaust brake Option: ABS |
|
|
|
|
|||||
|
Wheel & Types
|
|
Rims: 8.0-20, 10 hole-steel
Types 11.00-20 tube; Option: 12.00-20 tube, 12.00R20 tube |
|
|
|
|
|||||
|
Electrics
|
|
Operating voltage:24V, negative grounded; Starter: 24V, 5.4KW
Alternator: 28V, 1540W; Batteries: 2×12, 165Ah Cigar-lighter, horn, headlamp, fog light, brake lights, indicators and reverse lamp |
|
|
|
|
|||||
