Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
SUPT
-
Model Number:
-
MLCD-0055-075-00
-
Torque:
-
Requests
-
Peak force(N)::
-
165
-
Peak current(Amps)::
-
4.5
-
dc motor(mh)::
-
2.85
-
Continuous force(N)::
-
55
-
Continuous current(Amps)::
-
1.5
-
Weight rotor(kg)::
-
0.38
Quick Details
-
Speed(RPM):
-
High Speed
-
Continuous Current(A):
-
1.5Amps
-
Efficiency:
-
IE 1
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
SUPT
-
Model Number:
-
MLCD-0055-075-00
-
Torque:
-
Requests
-
Peak force(N)::
-
165
-
Peak current(Amps)::
-
4.5
-
dc motor(mh)::
-
2.85
-
Continuous force(N)::
-
55
-
Continuous current(Amps)::
-
1.5
-
Weight rotor(kg)::
-
0.38
dc motor:
Our Services
Almost any requirement can be successfully fulfilled
Satisfactory after-sales service
Product range
Product Description
| D Series--MLCD(Dynamic) MLFD(Stator) | |||||||
| Model/Par | MLCD-0055-075-00 | MLCD-0120-135-00 | MLCD-0200-255-00 | ||||
| Peak force(Fp) | N | 165 | 360 | 600 | |||
| Peak current(lp) | Amps | 4.5 | 4.5 | 7.8 | |||
| Continuous force(Fc) | N | 55 | 120 | 200 | |||
| Continuous current(lc) | Amps | 1.5 | 1.5 | 2.6 | |||
| Actuator constants(DC motor conversion/3p)(Ka) | N/W | 11.1 | 16.9 | 21.9 | |||
| Constant Thrust(L-L)(Kf) | N/Amps | 39.1 | 80.5 | 80.5 | |||
| Back EMF constant(L-L)(Kb) | V/m/sec | 22.6 | 47.2 | 44.8 | |||
| Electrical constant(Te) | ms | 0.35 | 0.35 | 0.35 | |||
| Resistance(L-L)(R) | @25℃Ω | 8.2 | 16.1 | 8.2 | |||
| Inductance(L-L)(l) | mh | 2.85 | 5.7 | 2.86 | |||
| Heat transfer coefficient(Rth) | ℃/W | *2.6 | **1.5 | **0.88 | |||
| Coil maximum temperature(Tmax) | ℃ | 120 | 120 | 120 | |||
| Magnet Pole pitch(2T) | mm | 30 | 30 | 30 | |||
| Mover weight | Kg | 0.38 | 0.68 | 1.3 | |||
Packaging & Shipping
Main port:Shanghai/Shenzhen/Guangzhou or as require.
Leading time:Normally goods can be ready within in 7days.
Express company:DHL,TNT,UPS,FEDEX,etc.
